Summarization of Contents
SET UP
TRANSPORT POSITION
Procedure for setting the cutter in transport position.
WORK POSITION
Procedure for setting the cutter in work position.
ANGULAR POSITIONING
How to set the cutter angle between 0° and 45°.
FAST MAGNET OPERATIONAL SYSTEM
STOP
Demonstrates the stop function of the fast magnet system.
SCORE
Illustrates the scoring action using the fast magnet system.
UNLOCK BREAKER
Shows the procedure for unlocking the breaker.
BREAK
Depicts the tile breaking action with the system.
STRAIGHT CUT
THIN STRIPES
Procedure for cutting thin stripes from a tile.
LOCK BREAKER
Steps to lock the breaker for cutting.
SCORE
Demonstrates scoring the tile.
BREAK
Illustrates breaking the tile after scoring.
DIAGONAL CUT
LOCK BREAKER
Procedure to lock the breaker for diagonal cuts.
SCORE
Demonstrates scoring the tile for diagonal cutting.
BREAK
Illustrates breaking the tile for diagonal cuts.
MAINTENANCE AND REPAIRS
CHANGE SCORING WHEEL
Procedure for replacing the scoring wheel.
LUBRICATION
Shows lubrication points for maintenance.
ADJUSTMENT
Illustrates adjustment points for maintenance.
