HIPERS HEATERS
▶Thank you for purchasing the HIPERS Heater.
Please read this user manual carefully before you operate this heater.
▶It is recommended that you put this manual where the user can easily find
it. It is obligatory that the user read "Notice for Safety" carefully before
using, and they should be aware of this notice whenever using this heater.
▶This heater is designed for your country only. If you use it in another coun
try, you have to check the electricity first, and if the electricity condition is
the same, you can use it.
▶A warranty card is enveloped in this manual.
▶The contents (features and specifications) in this manual are subject to
change without notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the DHOE-350 and is the answer not in the manual?

Questions and answers

Related Manuals for Hipers DHOE-350

Summary of Contents for Hipers DHOE-350

  • Page 1 HIPERS HEATERS ▶Thank you for purchasing the HIPERS Heater. Please read this user manual carefully before you operate this heater. ▶It is recommended that you put this manual where the user can easily find it. It is obligatory that the user read "Notice for Safety" carefully before using, and they should be aware of this notice whenever using this heater.
  • Page 2 • NOTICE FOR SAFETY • STRUCTURE & DESCRIPTION - STRUCTURE & DESCRIPTION - REMOTE CONTROLLER - CONTROL 8~14 •HOW TO USE - OPERATION & STOP - TEMPERATURE CONTROL - SELF DIAGNOSIS FOR THE SAFETY DEVICE • CLEANING & MAINTENANCE • DAILY CHECK POINTS & ADJUSTMENT 16~17 18~19 •...
  • Page 3 This is for protecting the user's safety and preventing any property damage. Please read carefully and follow the instructions in this manual.It is classified as "Warning" and "Caution" by the contents. In cases of misuse, it may cause serious wounds or death. In cases of misuse, it may cause a slight injury or property damage.
  • Page 4 It is dangerous to use this heater for a long You must ventilate well while you are using the time in a closed room, especially if there heater, and do not use it in a stuffy area where are children, the elderly, or the weak. ventilation is not possible.
  • Page 5 Do not put this heater on an unstable surface of When storing this heater, be sure that you store the ground, such as an inclined or bumpy it in a dry place indoors instead of in a hot and surface. humid environment.
  • Page 6 ※ This design may be changed for improved efficiency. When the heater turns ON or OFF, you can press this button. Every time you press this button, the heater repeats set-up and cancels. To select the time control mode To select the temperature control mode. To set or change the temperature or time Connect the power cord of the heater to the outlet.
  • Page 7 To select the time control mode. To select the time control mode. To select whether off-timer mode is operated or not. DHOE-90 To select the temperature control mode. To select the time control mode. To select the time control mode.
  • Page 8 DHOE-120~DHOE-350F 1. Connect the power plug (you can see the current temperature), 2. Select the desired operation type using the "TEMP or TIME" then press the on/off button. (Check "SET tem/time," the number button. on the right side.) But if this heater operates in case it is first used from purchase, turn the air screw left around three times and then start by pressing the "ON/OFF"...
  • Page 9 This mode enables the user to set the desired temperature, and once it is fixed, this heater works automatically, running and stopping repeatedly to meet this temperature. (If power is on and the heater starts operation, the temperature control mode will be operated by default.) 2.

  • Page 10: Time Control

    This mode enables the user to set the desired time, and once it is fixed, this heater works automatically, running and stopping repeatedly to TIME CONTROL meet this time. (If power is on and the heater starts operation, the temperature control mode will be operated by default.) 1.
  • Page 11 DHOE-90 1. Connect the power plug (you can see the current temperature), 2. Select the desired operation type using the "TEMP or TIME" button. then press the on/off button. (Check "SET tem/time," the number on the right side.)But if this heater operates in case it is first used from purchase, turn the air screw left around three times and then start by pressing the "ON/OFF"...
  • Page 12 This mode enables the user to set the desired temperature, and once it is fixed, this heater works automatically, running and stopping repeatedly to meet this temperature. (If power is on and the heater starts operation, the temperature control mode will be operated by default.) 1.
  • Page 13 This mode enables the user to set the desired temperature, and once it is fixed, this heater works automatically, running and stopping repeatedly to meet this temperature. (If power is on and the heater starts operation, the temperature control mode will be operated by default.) TIME CONTROL 2.
  • Page 14 If the following error or trouble signs are displayed on the operation panel Displayed Description Items to check and required actions messages of troubles - The lack of fuel E1. No ignition The burner is misfiring - There is air in the fuel tube (▶air discharge). - Photocell pollution (▶cleaning) - Unpluged Photocell (▶plug), Phototube Trouble (▶exchange) Photocell trouble Detrction...
  • Page 15 To pull out the front grille, please raise it a little and pull it out. (Assembly is the opposite way.) In case you keep the heater for a long time and you want to maintain its clean status, please power off and cool down the heater, pull out the plug as shown in the above picture, and clean according to the following instructions.
  • Page 16 CLEAN OF FLAME SENSOR (Photocell, CDS) - If the detection part of the photocell is contaminated by soot or other dirt, the performance can be lowered, which may cause a problem. - Please take out the photocell carefully, which is placed in the lower part of the burner. - Please clean the detection part of the photocell with soft clothes.

  • Page 17: Daily Check Points & Adjustment

    DAILY CHECK POINTS & ADJUSTMENT ADJUSTMENT ▶IN CASE OF SUDDEN STOP DURING OPERATION - Please check if now is operating in the time control operation? If so, the heater can be rest for 5min. - Please check if now the setting temp, is less than the current temp. - Please check if the heater is stop by pressing On/Off switch by remote controller or front controller.
  • Page 18 Please check the points below before you think trouble has occurred. Check if the power supply is proper. No power supply? (ex. 220/230Vac, 50Hz) Check that the power Plug the power plug into the outlet. OPERATION plug is disconnected. Replace the fuse with a new one. Is the fuse short? (250Vac, 3.15A) Fill it up with kerosene from the diesel.
  • Page 19 "Lack of Fuel" light ON? Running out of fuel Fill up the fuel. Check if the fuel if It may cause less Drain the existing fuel and fill with Diesel of kerosene performance & trouble Diesel of kerosene only. Water of ant other It may cause less IMMEDIATE Replace the fuel with good quality one...

  • Page 20: Specification

    SPECIFICATION - 20 -...
  • Page 21 This HIPERS heater gives you more reliable performance, comfort, and durability the more you use it because it is produced under a strict quality assurance system, including various inspections during and after production, reliance tests, etc. In case you encounter any problems, please contact the local service agent or a distributor.
  • Page 22 Official distributor and importer in European Union: Veltron International OÜ , Reg. No: 14338106 Phone: +372 5693 7082 E-mail: info@hipersheaters.com; Address: Pärnu mnt 139e/11, 11317 Tallinn ESTONIA...
