SERVICE MANUAL (UNIQUE)
ORIGINAL MANUAL ISSUE DATE:
(See next page for revision )
Conditions of Use:
(1) Please use this information only for the purpose of performing repair, maintenance and/or configuration services of the Sony products
(hereinafter the "Repair services") under the service agreement entered into with the Sony group company (hereinafter the "Service
agreement"). Using this information for any purpose other than the purpose described foregoing is forbidden.
(2) Only the Authorized Servicer's officers, employees or subcontractors (including their officers and employees) whose duties justify a
need-to-know and who have agreed to hold confidential this information (collectively hereinafter the "Permitted users") are permitted to
access and use this information. To disclose or disseminate to any person other than the Permitted users is forbidden.
(3) Destroy or erase any and all portion of this information promptly in an irrecoverable and secure fashion after achieving the purpose
described in Section (1) above.
(4) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information in whole or in part without the prior
written permission of the author.
(Notwithstanding foregoing, it is permitted to copy and distribute this information to the Permitted users.)
(5) Please notify immediately any leakage, loss, theft, misappropriation, or other misuse of this information by e-mail to the following
address:
somk-gcs-tissnexim-adm@jp.sony.com
(6) In addition to the above, the terms and conditions of the Service agreement shall be applied to using this information.
Revision of Information:
This information may be changed or updated at any time without any prior notice. Please confirm that this information is up-to-date before
using it.
2019.03
GN5TR CHASSIS
Segment : SN
9-888-765-A1
LCD TV
Sony EMCS (M) Sdn. Bhd., SVPM
© 2019.03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XBR-49X805G and is the answer not in the manual?

Questions and answers

Summary of Contents for Sony XBR-49X805G

  • Page 1 Conditions of Use: (1) Please use this information only for the purpose of performing repair, maintenance and/or configuration services of the Sony products (hereinafter the “Repair services”) under the service agreement entered into with the Sony group company (hereinafter the “Service agreement”).
  • Page 2 REVISION HISTORY Version Date Subject 2019.03 1. 1 Issue...
  • Page 3 MODEL LISTS MODEL REMOTE DESTINATION XBR-43X800G RMF-TX310U UC2, LA1 XBR-49X800G RMF-TX310U UC2, LA1 XBR-49X805G RMF-TX310B XBR-49X807G RMF-TX310U XBR-55X800G RMF-TX310U UC2/AUC2, LA1 XBR-55X805G RMF-TX310B XBR-55X807G RMF-TX310U XBR-65X800G RMF-TX310U UC2/AUC2, LA1 XBR-65X805G RMF-TX310B XBR-65X807G RMF-TX310U XBR-75X800G RMF-TX310U UC2/AUC2, LA1 XBR-75X805G RMF-TX310B XBR-75X807G...
  • Page 4: Table Of Contents

    TABLE OF CONTENTS Section Title Page DISASSEMBLY AND REMOVAL CAUTION 1-1. Rear Cover Disassemble Method DIAGRAMS 2-1. Circuit Board Location 2-2. Wire Dressing XBR-43X8*G XBR-49X8*G XBR-55X8*G XBR-65X8*G XBR-75X8*G Please refer Service Manual – Common for below EXPLODED VIEWS AND PARTS LIST information 3-1.
  • Page 5: Disassembly And Removal Caution

    SECTION 1 DISASSEMBLY AND REMOVAL CAUTION 1-1 Rear Cover Disassemble Method SN 43”/49” 1) Remove Rear Cover screws (Applies to SM and M)  Above picture is for M size Reference 43” (SM) 49” (M) Screw Type 4-167-019-22 SCREW, +PSW M3X8 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3 ...
  • Page 6 2) Unhook Rear Cover from bezel (Applies to SM and M) Rear Cover Bezel Rear Cover- Bezel hook area  Pinch rear cover bottom side and pull bezel slightly until hook is unlocked...
  • Page 7 Remove Rear Cover (Applies to SM and M)  After unhooking, pull upwards to remove rear cover...
  • Page 8 SN 55” Remove Rear Cover screws Reference 55” Screw Type 4-167-019-22 SCREW, +PSW M3X8 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3  Rear Cover can be dissembled without removing stand  Ensure all screws are removed before removing rear cover...
  • Page 9 Pull Rear Cover upward while push below area by finger (total = 4 locations) *Purpose : To release bottom internal hook structure between Rear Cover & Bezel Pull direction Internal hook *Note : To Refer to next page for the datum details...
  • Page 10 DATUM *Note : Hook location is symmetric for both side Hook 1 datum (align center between this screw boss & small oval hole) Hook 2 datum (align with this screw boss) Hook 1 pressing Hook 2 pressing location location...
  • Page 11 Pull up side area to release side internal hook (total = 2 locations) Pull direction Pull direction Internal hook...
  • Page 12 Carefully pull Rear Cover upward a bit to release bottom side *CAUTION : Please make sure angle lifting is not so high (if not, top hook will be stressed & broken) Pull direction Push Rear Cover to release top internal hook until fully disassembled (total = 5 locations) Slide direction Internal hook...
  • Page 13 SN 65”/75” Disassemble all screws from Rear Cover For 2L and 3L Total Screws : 2L – 11 pcs 3L – 11 pcs...
  • Page 14 2) Press Rear Cover bottom side and pull rear cover backwards to unhook bottom area. *Purpose : To release internal hook of Rear Cover & Bezel Internal hook For 2L and 3L Total Hooks (Bottom) : 2L – 2 pcs 3L –...
  • Page 15 Hold Rear Cover while unhook side area by using ruler or jig (start from bottom corner point) *Purpose : To release internal hook of Rear Cover & Bezel Internal hook For 2L Total Hooks (Side) : 2L – 7 pcs each side 3L –...
  • Page 16 Disassembly Datum for 2L Rear Cover Hook (side) RC opening pitch at top = 30mm Total Hooks (Side) : 2L – 7 pcs each side, symmetrical Opening Direction: Bottom -> Top RC opening pitch for others = 140mm For 2L <Start Here>...
  • Page 17 Disassembly Datum for 3L Rear Cover Hook (side) RC opening pitch at top = 30mm Total Hooks (Side) : 3L – 9 pcs each side, symmetrical Opening Direction: Bottom -> Top RC opening pitch for others = 110mm For 3L <Start Here>...
  • Page 18 Pull Rear Cover backward at below area until unhooked (click sound) *Purpose : To release internal hook of Rear Cover & Terminal Bracket Internal hook For 2L and 3L Total Hooks (Terminal Bracket) : 2L – 6 pcs 3L – 6 pcs...
  • Page 19 Hold side of Rear Cover while unhook top area by using ruler or jig (start from top corner point) *Purpose : To release internal hook of Rear Cover & Bezel Internal hook For 2L and 3L Total Hooks (Top) : 2L –...
  • Page 20 Disassembly Datum for 2L Rear Cover Hook (Top) RC opening pitch = 125mm <Start at both ends> for all First point = 125mm from bezel outline Total Hooks (Top) : 2L – 11 pcs Opening Direction: Towards RC center, symmetrical For 2L...
  • Page 21 RC opening Disassembly Datum for 3L Rear Cover Hook (Top) pitch = 142mm <Start at both ends> for all First point = 142mm from bezel outline Total Hooks (Top) : 3L – 11 pcs Opening Direction: Towards RC center, symmetrical For 3L...
  • Page 22 Disassemble Smart Core from Set BACK FRONT VIEW VIEW COVER, TOP 1. Remove screw in red box LIGHT, GUIDE PANEL, ORNAMENT H board CASE, BOTTOM 2. Remove harness...
  • Page 23 Disassemble Cover Top Disassemble Panel Ornament Pull up the cover top by the following order ② ① Pull up Pick up Panel Ornament Disassemble H board Disassemble Guide Light Hold this area and pick up H board Pull out with index finger...
  • Page 24: Diagrams

    SECTION 2 DIAGRAMS 2-1 Circuit Board Location 49” 43” SWITCH SWITCH UNIT UNIT UNIVERSAL LDK2 UNIVERSAL WLAN/BT LDK2 WLAN/BT B* BOARD SIL-TU BOARD B*BOARD SIL-TU MODULE BOARD MODULE 65” 55” SWITCH UNIT UNIVERSAL WLAN/BT SWITCH SIL-TU B*BOARD BOARD WLAN/BT UNIVERSAL MODULE UNIT B* BOARD...
  • Page 25 SECTION 2 DIAGRAMS 2-1 Circuit Board Location 75” SWITCH UNIVERSAL WLAN/BT BOARD UNIT SIL-TU MODULE BOARD Smart Core HCA_PONR_CZEN MOUNT...
  • Page 26 2-2 Wire Dressing : 43” CONNECT CONNECT 41P Overall View Overall View CONNECT INFORMATION Overall View...
  • Page 27 2-2 Wire Dressing : 43” CONNECT INFORMATION 1 Overall View INFORMATION 2 INFORMATION 3...
  • Page 28 2-2 Wire Dressing : 43” CONNECT INFORMATION Overall View TAPE CONNECT Overall View Overall View...
  • Page 29: Wire Dressing

    2-2 Wire Dressing : 43” WIRE DRESSING Overall View WIRE DRESSING Overall View...
  • Page 30 2-2 Wire Dressing : 43” WIRE DRESSING Overall View CONNECT CONNECT Overall View...
  • Page 31 2-2 Wire Dressing : 43” WIRE DRESSING Overall View TAPE Overall View...
  • Page 32 2-2 Wire Dressing : 43” TAPE Overall View TAPE Overall View...
  • Page 33 2-2 Wire Dressing : 43” TAPE Overall View TAPE Overall View...
  • Page 34 2-2 Wire Dressing : 43” TAPE Overall View TAPE Overall View...
  • Page 35 2-2 Wire Dressing : 43” CONNECT Overall View WIRE DRESSING Overall View...
  • Page 36 2-2 Wire Dressing : 43” CONNECT Overall View WIRE DRESSING Overall View...
  • Page 37 2-2 Wire Dressing : 43” INFORMATION...
  • Page 38 2-2 Wire Dressing : 49” CONNECT CONNECT Overall View Overall View CONNECT INFORMATION Overall View...
  • Page 39 2-2 Wire Dressing : 49” CONNECT INFORMATION 1 Overall View INFORMATION 2 INFORMATION 3...
  • Page 40 2-2 Wire Dressing : 49” CONNECT INFORMATION Overall View TAPE Overall View...
  • Page 41 2-2 Wire Dressing : 49” CONNECT Overall View WIRE DRESSING Overall View...
  • Page 42 2-2 Wire Dressing : 49” WIRE DRESSING Overall View WIRE DRESSING Overall View...
  • Page 43 2-2 Wire Dressing : 49” CONNECT CONNECT Overall View Overall View CONNECT Overall View...
  • Page 44 2-2 Wire Dressing : 49” TAPE Overall View TAPE Overall View...
  • Page 45 2-2 Wire Dressing : 49” TAPE Overall View TAPE Overall View...
  • Page 46 2-2 Wire Dressing : 49” TAPE Overall View TAPE Overall View...
  • Page 47 2-2 Wire Dressing : 49” CONNECT Overall View CONNECT Overall View...
  • Page 48 2-2 Wire Dressing : 49” WIRE DRESSING Overall View CONNECT Overall View...
  • Page 49 2-2 Wire Dressing : 49” WIRE DRESSING Overall View INFORMATION...
  • Page 50 2-2 Wire Dressing : 55” INFORMATION 1 CONNECT Overall View INFORMATION 2 INFORMATION 3...
  • Page 51 2-2 Wire Dressing : 55” CONNECT INFORMATION 4 Overall View TAPE CONNECT Overall View Overall View...
  • Page 52 2-2 Wire Dressing : 55” WIRE DRESSING Overall View INFORMATION CONNECT Overall View...
  • Page 53 2-2 Wire Dressing : 55” CONNECT Overall View WIRE DRESSING Overall View...
  • Page 54 2-2 Wire Dressing : 55” TAPE Overall View CONNECT CONNECT Overall View Overall View...
  • Page 55 2-2 Wire Dressing : 55” CONNECT TAPE Overall View Overall View TAPE TAPE Overall View Overall View...
  • Page 56 2-2 Wire Dressing : 55” TAPE TAPE Overall View Overall View WIRE DRESSING Overall View...
  • Page 57 2-2 Wire Dressing : 55” INFORMATION INFORMATION TAPE TAPE Overall View Overall View...
  • Page 58 2-2 Wire Dressing : 55” TAPE CONNECT Overall View Overall View WIRE DRESSING Overall View...
  • Page 59 2-2 Wire Dressing : 55” CONNECT WIRE DRESSING Overall View Overall View WIRE DRESSING INFORMATION INFORMATION...
  • Page 60 2-2 Wire Dressing : 65” INFORMATION CONNECT Overall View INFORMATION 1 INFORMATION 2...
  • Page 61 2-2 Wire Dressing : 65” INFORMATION 3 INFORMATION 4 CONNECT 51P TAPE Overall View...
  • Page 62 2-2 Wire Dressing : 65” TAPE CONNECT 30P Overall View Overall View CONNECT Overall View...
  • Page 63 2-2 Wire Dressing : 65” WIRE DRESSING Overall View CONNECT WIRE DRESSING Overall View Overall View...
  • Page 64 2-2 Wire Dressing : 65” CONNECT CONNECT Overall View Overall View CONNECT WIRE DRESSING Overall View...
  • Page 65 2-2 Wire Dressing : 65” INFORMATION TAPE Overall View TAPE TAPE Overall View Overall View...
  • Page 66 2-2 Wire Dressing : 65” INFORMATION TAPE Overall View TAPE Overall View...
  • Page 67 2-2 Wire Dressing : 65” WIRE DRESSING Overall View TAPE TAPE Overall View Overall View...
  • Page 68 2-2 Wire Dressing : 65” WIRE DRESSING CONNECT Overall View Overall View WIRE DRESSING Overall View...
  • Page 69 2-2 Wire Dressing : 65” WIRE DRESSING Overall View TAPE TAPE Overall View...
  • Page 70 2-2 Wire Dressing : 65” WIRE DRESSING INFORMATION...
  • Page 71 2-2 Wire Dressing : 75” INFORMATION CONNECT Overall View INFORMATION 1 INFORMATION 2...
  • Page 72 2-2 Wire Dressing : 75” INFORMATION 3 INFORMATION 4 CONNECT 51P TAPE Overall View Overall View...
  • Page 73 2-2 Wire Dressing : 75” CONNECT 30P Overall View TAPE Overall View...
  • Page 74 2-2 Wire Dressing : 75” TAPE CONNECT Overall View Overall View WIRE DRESSING Overall View...
  • Page 75 2-2 Wire Dressing : 75” CONNECT WIRE DRESSING Overall View Overall View CONNECT CONNECT Overall View Overall View...
  • Page 76 2-2 Wire Dressing : 75” CONNECT WIRE DRESSING Overall View Overall View TAPE Overall View...
  • Page 77 2-2 Wire Dressing : 75” TAPE Overall View TAPE INFORMATION Overall View...
  • Page 78 2-2 Wire Dressing : 75” TAPE TAPE Overall View Overall View TAPE TAPE Overall View Overall View...
  • Page 79 2-2 Wire Dressing : 75” TAPE CONNECT Overall View Overall View WIRE DRESSING Overall View...
  • Page 80 2-2 Wire Dressing : 75” WIRE DRESSING Overall View Overall View INFORMATION WIRE DRESSING TAPE Overall View...
  • Page 81: Xbr-43X8*G

    SECTION 3 EXPLODED VIEWS AND PART LISTS  (*) Parts are not stocked since they are seldom required for routine service. •Place the TV set facing downwards on a stable, level surface before disassembly and assembly of parts. • and shaded parts are critical for safety. Replace only with part number specified. Some delays should be anticipated when ordering these components.
  • Page 82 3-1. XBR-43X8*G Exploded View XBR-43X800G REF. NO PART NO. DESCRIPTION LABEL, REAR TERMINAL (FRE) *Not service part for America region 4-727-926-11 LABEL, UNDER TERMINAL (PPK) • 4-727-926-21 LABEL, UNDER TERMINAL (PPK) • LABEL, SIDE TERMINAL (FRE) *Not service part for America region...
  • Page 83 3-1. XBR-43X8*G Screws SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11...
  • Page 84 3-1. XBR-43X8*G Screws SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11...
  • Page 85 3-1. XBR-43X8*G Screws SCREW, +PSW M3X8 4-167-019-22 SCREW +BVTP 3X10 TYPE2 IT-3 7-685-647-79...
  • Page 86 3-1. XBR-43X8*G Connectors REF. PART NO. DESCRIPTION REMARKS 1-910-806-24 HARNESS ASSY CN1000(BCX2)-CN203(3KEY)-CN001(HCA)-WIFI/BT / CN4002(LDK2)-SP(1) 1-912-614-11 FLEXIBLE FLAT CABLE 51P CN3800(BCX2)-TCON(1) 1-912-520-11 FLEXIBLE FLAT CABLE 41P CN401(BCX2)-CN3001(LDK2)(1)
  • Page 87 3-1. XBR-43X8*G Others XBR-43X800G PART NO. DESCRIPTION 1-493-333-15 AC ADAPTOR (100W) • • *7-600-040-44 ADHESIVE (SV380C) 333CC GRY • • 4-535-064-14 ASSY,FALL LOCK,BELT LL • • 5-000-745-01 BAG, SCREW ASSY (M4L10) (*include SCREW, +PSW M4X10, 4-159-298-01 (4PCS)) • • 4-535-586-02 BADGE, XBR LOGO(H3.7)
  • Page 88: Xbr-49X8*G

    3-1. XBR-49X8*G Exploded View Stand...
  • Page 89: Xbr-49X8*G

    3-1. XBR-49X8*G Exploded View XBR-49X800G XBR-49X805G XBR-49X807G REF. NO PART NO. DESCRIPTION CO1. *Not service part for America region LABEL, DC IN TERMINAL (FRE) LABEL, REAR TERMINAL (FRE) *Not service part for America region 4-727-926-11 LABEL, UNDER TERMINAL (PPK) • 4-727-926-21 LABEL, UNDER TERMINAL (PPK) •...
  • Page 90 3-1. XBR-49X8*G Screws SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11...
  • Page 91 3-1. XBR-49X8*G Screws SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11...
  • Page 92 3-1. XBR-49X8*G Screws SCREW, +PSW M3X8 4-167-019-22 SCREW +BVTP 3X10 TYPE2 IT-3 7-685-647-79...
  • Page 93 3-1. XBR-49X8*G Connectors REF. PART NO. DESCRIPTION REMARKS 1-910-806-25 HARNESS ASSY CN1000(BCX2)-CN203(3KEY)-CN001(HCA)-WIFI/BT / CN4002(LDK2)-SP(1) 1-912-521-11 FLEXIBLE FLAT CABLE 41P CN401(BCX2)-CN3001(LDK2)(1) 1-912-615-11 FLEXIBLE FLAT CABLE 51P CN3800(BCX2)-TCON(1)
  • Page 94 3-1. XBR-49X8*G Others XBR-49X800G XBR-49X805G XBR-49X807G PART NO. DESCRIPTION CO1. 1-493-490-12 AC ADAPTOR (120W) • • • • *7-600-040-44 ADHESIVE (SV380C) 333CC GRY • • • • 4-535-064-13 ASSY,FALL LOCK,BELT LL • • • • 5-000-745-01 BAG, SCREW ASSY (M4L10) (*include SCREW, +PSW M4X10, 4-159-298-01 (4PCS)) •...
  • Page 95 3-1. XBR-55X8*G Exploded View Stand...
  • Page 96 3-1. XBR-55X8*G Exploded View XBR- XBR- XBR-55X800G 55X805G 55X807G REF. NO PART NO. DESCRIPTION AUC2 CO1. 4-728-861-11 LABEL, UNDER TERMINAL (BCH) • • • 4-728-861-81 LABEL, UNDER TERMINAL (BCH) • • 4-297-989-41 AC COVER • • • • • 1-849-274-11 POWER-SUPPLY CORD (WITH CONN.) •...
  • Page 97 3-1. XBR-55X8*G Screws SCREW, +PSW M3X8 4-167-019-22 SCREW, +PSW M3X6 W12 4-256-393-12 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11...
  • Page 98 3-1. XBR-55X8*G Screws SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11...
  • Page 99 3-1. XBR-55X8*G Screws SCREW, +PSW M3X8 4-167-019-22 SCREW, +PSW M4X10 4-159-298-01 SCREW +BVTP 3X10 TYPE2 IT-3 7-685-647-79 SCREW, +PSW M4X10 4-159-298-01...
  • Page 100 3-1. XBR-55X8*G Connectors REF. PART NO. DESCRIPTION REMARKS 1-910-806-27 HARNESS ASSY CN1000(BCX)-CN203(3KEY)-CN001(HCA-L)-WIFI/BT / CN3202(BCX)-SP(1) 1-912-616-11 FLEXIBLE FLAT CABLE 51P CN3800(BCX)-TCON(1) 1-910-806-29 CONNECTOR ASSY 30P CN400(BCX)-CN6401(GL6)(1)
  • Page 101 3-1. XBR-55X8*G Others XBR-55X800G XBR-55X805G XBR-55X807G PART NO. DESCRIPTION AUC2 CO1. *7-600-040-44 ADHESIVE (SV380C) 333CC GRY • • • • • 4-535-064-13 ASSY,FALL LOCK,BELT LL • • • • • BAG, SCREW ASSY (M4L14) (*include SCREW, +PSW M5X14, 4-694-261-11 5-000-746-01 •...
  • Page 102 3-1. XBR-65X8*G Exploded View Stand...
  • Page 103: Xbr-65X8*G

    3-1. XBR-65X8*G Exploded View XBR-65X800G XBR-65X805G XBR-65X807G REF. NO PART NO. DESCRIPTION AUC2 CO1. 4-728-861-11 LABEL, UNDER TERMINAL (BCH) • • 4-728-861-21 LABEL, UNDER TERMINAL (BCH) • • • 4-728-861-81 LABEL, UNDER TERMINAL (BCH) • • LABEL, REAR TERMINAL (FRE) *Not service part for America region LABEL, SIDE TERMINAL *Not service part for America region...
  • Page 104 3-1. XBR-65X8*G Screws SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 W12 4-256-393-12 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11...
  • Page 105 3-1. XBR-65X8*G Screws SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, M3X3.6 4-597-645-11 RIGHT LEFT Screw only on this 1 point SCREW, +PSW M3X6 4-472-518-11 This point for backup only (nearby hook)
  • Page 106 3-1. XBR-65X8*G Screws SCREW, +PSW M4X10 4-159-298-01 SCREW, +PSW M3X8 4-167-019-22 SCREW, ORNAMENTAL 4-268-126-02 SCREW, +PSW M5X14 4-694-261-11 M6X12...
  • Page 107 3-1. XBR-65X8*G Connectors REF. PART NO. DESCRIPTION REMARKS 1-001-402-11 HARNESS ASSY CN1000(BCX)-CN203(3KEY)-CN001(HCA-L)-WIFI/BT / CN3202(BCX)-SP(1) 1-001-404-11 CONNECTOR ASSY 30P CN400(BCX)-CN6401(GL91/GL95)(1) 1-001-420-11 FLEXIBLE FLAT CABLE 51P CN3800(BCX)-TCON(1)
  • Page 108 3-1. XBR-65X8*G Others XBR-65X800G XBR-65X805G XBR-65X807G PART NO. DESCRIPTION AUC2 CO1. *7-600-040-44 ADHESIVE (SV380C) 333CC GRY • • • • • 4-535-064-13 ASSY,FALL LOCK,BELT LL • • • • • 5-000-746-21 BAG, SCREW ASSY (M5L14) (*include SCREW, +PSW M5X14, 4-694-261-11 (4PCS)) •...
  • Page 109 3-1. XBR-75X8*G Exploded View Stand...
  • Page 110: Xbr-75X8*G

    3-1. XBR-75X8*G Exploded View XBR-75X800G XBR-75X805G XBR-75X807G REF. NO PART NO. DESCRIPTION AUC2 CO1. 4-728-861-11 LABEL, UNDER TERMINAL (BCH) • • 4-728-861-21 LABEL, UNDER TERMINAL (BCH) • 4-728-861-81 LABEL, UNDER TERMINAL (BCH) • • LABEL, REAR TERMINAL (FRE) *Not service part for America region LABEL, SIDE TERMINAL *Not service part for America region 4-745-608-01...
  • Page 111 3-1. XBR-75X8*G Screws SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 W12 4-256-393-12 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11...
  • Page 112 3-1. XBR-75X8*G Screws SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, M3X3.6 4-597-645-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 4-472-518-11 SCREW, +PSW M3X6 W12 4-256-393-12...
  • Page 113 3-1. XBR-75X8*G Screws SCREW, +PSW M3X8 4-167-019-22 SCREW, +PSW M4X10 4-159-298-01 SCREW, ORNAMENTAL SCREW, +PSW M5X14 4-694-261-11 4-268-126-02 M6X12...
  • Page 114 3-1. XBR-75X8*G Connectors REF. PART NO. DESCRIPTION REMARKS 1-001-405-11 HARNESS ASSY CN1000(BCX)-CN203(3KEY)-CN001(HCA-L)-WIFI/BT / CN3202(BCX)-SP(1) 1-001-407-11 CONNECTOR ASSY 30P CN400(BCX)-CN6401(GL92/GL94)(1) 1-001-424-11 FLEXIBLE FLAT CABLE 51P CN3800(BCX)-TCON(1)
  • Page 115 3-1. XBR-75X8*G Others XBR-75X800G XBR-75X805G XBR-75X807G PART NO. DESCRIPTION AUC2 CO1. *7-600-040-44 ADHESIVE (SV380C) 333CC GRY • • • • • 4-535-064-13 ASSY,FALL LOCK,BELT LL • • • • • 5-000-746-11 BAG, SCREW ASSY (M5L14) (*include SCREW, +PSW M5X14, 4-694-261-11 (6PCS)) •...
  • Page 116: Smart Core

    3-2 . Smart Core REF. PART NO. DESCRIPTION REMARK 4-690-016-04 COVER, TOP (CPN) 4-596-101-21 PANEL, ORNAMENT (FRE) 4-596-102-01 GUIDE, LIGHT (FRE) A-2199-558-B HCA_PONR_CZEN MOUNT For 43”/49” A-2199-646-B HCAL_PONR_CZEN MOUNT For 55”/65”/75” 4-596-103-02 CASE, BOTTOM (FRE) For 43”/49” 4-686-122-03 CASE, BOTTOM (SBT) For 55”/65”/75”...
  • Page 117 Sony EMCS (M) Sdn. Bhd. English SVPM 9-888-765-A1 © 2019.03...
