JRC NSVS1107 Manual

JRC SAW FILTER

Application

449.7MHz Low Power Transceiver
Electrical Specification: (Table 1)
The device characteristics are measured in the circuit shown in Fig.1.
Table 1. Electrical Specifications
Item
Input and Output Impedance
Nominal Center Frequency (f0)
Insertion Loss
Response Variation
Input and Output VSWR
Out of Band Rejection
(Relative to Through Level)
Maximum Rating: (Table 2)
Table 2. Maximum Ratings
Item
Maximum Input Power
Maximum DC Voltage
Operating Temperature Range
Storage Temperature
Mechanical Specifications: (Fig.2)
Package is designed as small as 3.0x3.0x1.15[mm
Notice:
This part is electrostatic discharge sensitive and may be damaged by improper handling.
Communications Equipment Marketing Department
http://www.jrc.co.jp/jp/product/device/saw/index.html (Japanese)
http://www.jrc.co.jp/eng/product/saw/index.html(English)
NSVS1107
449.2~450.2MHz
449.2~450.2MHz
449.2~450.2MHz
428.3 MHz
471.1 MHz
(Operating Temperature Range: -10~+60ºC)
Rating
+20dBm
7.5V
-10~+60ºC
-20~+70ºC
Communications Equipment Division
10-1, Nishi-Shinjuku 6-chome, Shinjuku-ku,
Tokyo, 160-8328 Japan
Tel. +81 3-3348-3845
Fax. +81 3-3348-3935
NSVS1107 Nov. 2004
Spec.
50Ω
449.7MHz
3.5dB max.
1.5dB max.
2.5 max.
50dB min.
40dB min.
3
] for SMD (Surface Mount Device) type.
Typ.
-
-
2.5dB
0.5dB
1.5
60dB
50dB
