NAPCO ISEEVIDEO - BROCHURE 1-CHANNEL GATEWAY Brochure

iSeeVideo:
turn any camera into an IP camera
Front:
• Includes LED indicators for
Network, Active and Power
• Also BNC connections for Video
In and optional Video out which
enables, for example on-premises
TV viewing of the camera's video,
locally.
iSeeVideo's Single Channel Video Gateway (model no. SCHGW)
converts any analog CCTV camera into an internet-ready IP
camera. There's a configuration for use with any analog camera
brand of your choice or for use with Napco's award-winning iS-
eeVideo Ethernet over Power (EOP) homeplug kits that literally
plug into a premises' AC outlets and send video data wirelessly
- with no coax runs.
• Adaptive technology networking for easiest, most reliable
installation: Just plug the EOP module or CAT5 cable into
premises' router and the camera will automatically adapt to the
network regardless of service and modem type. Even in the
most inflexible corporate networks, the video camera will auto-
configure through the network to the VideoAlert.net server.
• High-res. video images of 704 x 480 lines of resolution, max.
using MPEG4 compression
• Fast 30FPS video viewing* on the Napco-provided iSeeVideo
VideoAlert server, accessible to your accounts on virtually any
computer or web-enabled device (cellphone, PDA, etc.) in the
world.
Specifications:
• 1 Video Input, NTSC/ PAL auto detect
• 1 Video Output
• Video Compression: MPEG-4/ M-JPEG Dual Stream simultaneously
• Resolution: 4CIF, CIF, QCIF
• Max: 704 x 480 (NTSC) / 704 x 576 (PAL)
• Default: 352 x 240 (NTSC) / 352 x 288 (PAL)
• Min: 176 x 120 (NTSC) / 176 x144 (PAL)
• Frame Rate*: Up to 30 frame per second in all resolution,
internet service dependent
• Audio Compression G.726 ADPCM, G.711 PCM
• Video Trigger Input
• Motion Detection: 4 Detection Areas with individual sensitivity controls
• LAN: DM9102D, 10/100BaseT, Auto-MIDX
• LED Indicators: Ready, Active, Network
• Connectors:
• Ethernet RJ-45, Power, Reset, Composite Video In, Composite
Video out, Audio In, Audio Out
• External Power Adapter: 12V/1A, 100~240 VAC, Switching
• Certification: CE/ FCC
• Dimensions: 90mm (W) x 30mm (H) x 140mm (L)
• Operation Environment
• Temperature: 0-40 ºC
• Humidity: 20-80% RH
1-channel
Back:
• ALARM INTEGRATION TRIG-
GER INPUT TERMINALS
(center) To initiate transmission
of video to the VideoAlert.net
server, for example on alarm or
other alarm event, a normally
closed relay is wired across
the DO and DI terminals. A momentary open across this connection will trigger video
(programmable).
• ETHERNET (left) Connection to CAT5 cable from broadband modem or network to
RJ-45 terminal.
• POWER (right) Plug in 12VDC transformer, supplied.
• Napco VideoAlert.net server can be customized by installation
companies with logos, contact info., phones etc. for greater
service, referral opportunities.
• Alarm integration option An input trigger can prompt the
transmission of video clips to the VideoAlert.net server, when it's
activated.
• Advanced pixel-based motion detection capability
• Video output for optional local TV viewing Gateway provides a
local video signal for connection to a monitor, or for local distri-
bution, using a video modulator.
Dynamic IP support (no extra charge) through the NAPCO pro-
•
vided iSeeVideo server
• Scalable video storage space, (50MB per camera) for accounts
wishing to store more video clips online in their password-pro-
tected account.
Ordering Information:
SCHGW-EOPKT/12 Single Channel Gateway/EOP (Ethernet Over Power)
kit, includes: (1) ISEE-SCHGW widescreen. VGA Res (704 x 480) at up to 30
FPS, MPEG4 compression, audio mic input and speaker output. (2) ISEE-EOP
MOD200 Homeplug ethernet over power modules for transmission of video
signals over existing power lines of home or business at 200Mbps, with AES
encryption.w/ CAT5 patch cable. Includes 12 months of iSeeVideo network
service, including NapcoIP.com DDNS service.
SCHGW-EOP/12 Add-on EOP Camera /1-Gateway EOP Kit for use with
above. Includes: (1) ISEE-SCHGW single channel gateway and (1) ISEE-EOP
MOD200 Homeplug ethernet over power module (and cable), as above.
Also includes 12 months of iSeeVideo network service, including NapcoIP.
com DDNS service
ISEE-SCHGW/12 Single Channel Gateway for more conventional CAT5
or Coax Installations: (1) ISEE-SCHGW widescreen. VGA Res (704 x 480) at
up to 30 FPS, MPEG4 compression, audio mic input and speaker output.
Includes 12 months of iSeeVideo network service, including NapcoIP.com
DDNS service.
Napco Security Technologies, Inc.
333 Bayview Avenue, Amityville, NY 11701
1.800.645.9445
Preliminary specifications subject to change. © Napco, 3/2009 A583
gateway
• www.napcosecurity.com
