MDT1060/1065/865 Quick Start Guide
Accessories highlights
Item 4
Item 2
Item 3
Item 1
Item 8
Item 5
Item 6
Item 7
Item 9
1. Plastic Tape for cradle back connector if not used
2. Metal Stand (Be a desktop dock station)
3. Keys and Screws
4. Cable used for vehicle cradle, it can connect to cradle bottom side
5. Metal Mount
6. Type C cable for home adapter
7. NFC Card
8. Vehicle cradle or desktop dock station
9. Cradle extension cable (connected to new cable for power supply)
Advertisement
Related Manuals for Topicon MDT1065
Summarization of Contents
Accessories Highlights
Plastic Tape for Cradle Connector
Plastic tape for cradle back connector if not used.
Metal Stand for Desktop Use
Metal stand that functions as a desktop dock station.
Keys and Screws Included
Includes keys and screws for mounting or securing components.
Vehicle Cradle Cable
Cable used for the vehicle cradle, connecting to the bottom side.
Metal Mount Accessory
A metal mount accessory for securing the device.
Type C Charging Cable
Type C cable for home adapter charging.
NFC Card
NFC card for device interaction or identification.
Vehicle Cradle or Desktop Dock Station
The main device cradle, usable as a vehicle mount or desktop dock.
Cradle Extension Cable
Extension cable for the cradle, connected to the new cable for power supply.
Dual Functionality of 2-in-1 Cradle
Desktop Dock Station Configuration
Configuration for desktop use, featuring a metal plate and Type C connector.
Vehicle Cradle Configuration
Configuration for vehicle use, without a metal plate, utilizing the Molex connector.
Bottom Cable Features and Pin Assignments
Cradle Cable Types and Functions
Overview of cradle, extension, and camera hub cables and their capabilities.
Cable Pin Assignment Overview
Diagram illustrating connection points for various cables and functions.
Cable Specifications and Pinouts
P2 Power and Serial Port Connector Details
Pin definitions for the P2 power and serial port connector.
P3 Camera Hub Connector Details
Pin definitions for the P3 camera hub connector.
P5 GPIO Wire Definitions
Color-to-function mapping for P5 GPIO wires.
GPIO Demo APK and Cable Connections
GPIO Demo APK Overview
Information about the GPIO Demo application and its source code.
Power and Serial Extension Cable Wiring
Details on connecting power and serial extension cables (P6, P7, P8).
Serial Port Configuration and Demo
Serial Port Demo APK Overview
Information regarding the serial port demo application.
Device TTY Port Options
Configuration options for serial ports (ttyUser, ttyUSB0, ttyUSB1).
Vehicle Installation with Metal Parts
Purpose of Metal Parts
Using metal parts for cable routing and device support in vehicles.
Adjustable Length Feature
The metal parts allow for length adjustment between 50mm and 80mm.
Basic Vehicle Cradle and Cables
Basic Cradle Functionality
Describes the basic vehicle cradle with RS232, OTG, and power input.
Basic Cable Specifications
Details of the basic cradle cables (CAB-MB-BASIC, CAB-EX-BASIC).
Basic Cradle Connector Specifications
P2 Connector Pin Definitions
Pinout details for the P2 connector on the basic cradle.
P3 Connector Pin Definitions
Pinout details for the P3 connector on the basic cradle.
Extension Cable Wire Definitions
Color-to-function mapping for the extension cable wires.
Safety, Compliance, and RF Specifications
Operating Environment and Adapter Requirements
Guidelines for operating temperature, altitude, and required adapters.
Regulatory Compliance Statements
Declarations of compliance with EU directives and product classification.
2G, 3G, and 4G RF Specifications
Frequency ranges and output power for cellular bands.
Wireless Technology RF Specifications
4G LTE RF Output Power
Output power levels for various 4G LTE bands.
Bluetooth, Wi-Fi, NFC, LORA, GPS Specs
Frequency ranges and output power for Bluetooth, Wi-Fi, NFC, LORA, GPS.
FCC Compliance and RF Exposure
FCC Radiation Exposure Statement
Device compliance with FCC RF exposure guidelines and SAR limits.
FCC Part 15 Warning and Interference
Device compliance with FCC Part 15 and handling of interference.
Industry Canada (IC) Compliance
IC RF Exposure Guidelines
Device adherence to IC RF exposure guidelines for body-worn operation.
IC License-Exempt Transmitter Warning
Compliance with IC license-exempt transmitter requirements and interference.
