- Page 1 Hollyland Solidcom C1 Pro - Hub8S User Manual V1.0.0...
- Page 3 Introduction Thank you for purchasing Hollyland Solidcom C1 Pro full-duplex wireless noise- cancelling intercom system. The Solidcom C1 Pro - Hub8S is a full-duplex wireless noise-cancelling intercom system engineered to provide clear audio and all-day wearing comfort in a truly wireless design with no beltpack required.
-
Page 4: Packing List
Packing List Solidcom C1 Pro - Hub8S Intercom Headset Package Remote Headset (With Blue Nameplate) 0B10 Wired Headset (With Red Nameplate) 8-Slot Charging Case Headset Battery Microphone Cushion 12V/2A DC Adapter Over-ear Leather Cushion On-ear Foam Cushion USB-A to USB-C Cable High-Gain Antenna Storage Case User Manual... - Page 5 Quick Guide Installing the Hub Antennas Powering on the Hub • Connect the 12V/2A DC adapter to • Switch on the Hub. the hub. Note: The hub can also be powered on by NP-F batteries, V-mount batteries, or G-mount batteries.
- Page 6 Quick Guide Pairing The hub and remote headsets that come from the same system will pair with each other automatically right out of the box. Manual pairing is only required when a new headset needs to be added or when a headset or the hub needs to be replaced. Connecting a Headset to the Hub Using a USB-C Cable A USB-C cable is required for pairing.
- Page 7 Quick Guide Configuring the Hub on the Web Server Turn on the hub, connect it to a computer using a network cable via the RJ45 interface on the hub and the network port on the computer, configure the same network segment for the computer and hub, open a browser on the computer, and then enter the following addresses (Check the corresponding addresses through the network menu on the hub): Default IP address of a master hub: 192.168.218.10...
- Page 8 Parameters Wired Headset RJ45 interface Power interface (DC interface) 4-wire audio interface (RJ45 socket) USB interface Interface USB-C interface 2-wire audio interface PGM audio interface USB-C interface 0B10 headset interface RF antenna interface Antenna External Built-in DC power, NP-F battery, Power Supply V-mount battery, G-mount 700mAh lithium polymer battery...
- Page 9 Frequency Response 150Hz–7kHz Signal-to-Noise Ratio >55dB Distortion <1% Input SPL >115dBSPL 0℃ to 45℃ (working condition) –10℃ to 60℃ (storage condition) Temperature Range Note: The highest working temperature is 40℃ when the adapter is used for the power supply.
-
Page 10: Safety Precautions
Safety Precautions Do not place the product near or inside heating devices (including but not limited to microwave ovens, induction cookers, electric ovens, electric heaters, pressure cookers, water heaters, and gas stoves) to prevent the battery from overheating and exploding. Do not use non-original charging cases, cables, and batteries with the product. - Page 11 Hollyland Support Team via the following ways: Statement All copyrights belong to Shenzhen Hollyland Technology Co., Ltd. Without the written approval of Shenzhen Hollyland Technology Co., Ltd., no organization or individual may copy or reproduce part or all of any written or illustrative content and disseminate it in any form.
-
Page 12: Fcc Requirement
FCC Requirement Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the device. This device complies with Part 15 of the FCC Rules. Operations are subject to the following two conditions: (1) This device may not cause harmful interference.
