- Page 1 Instruction manual MOJO 18' | DUDE 18' | AIRKAYAK 16' Edition: 12/2019...
- Page 2 Safety guidelines Rowing can be dangerous and physically demanding. Rowing can lead to dangerous situations developing that result in serious injury. The user of this product should have a basic understanding of the risks involved when rowing and be aware of consequences. Please observe the following safety standards when using this product: ...
-
Page 3: Table Of Contents
Table of Contents MOJO 18' ................1 Overview ................1 Assembly ................2 Folding away ................ 3 Additional information ............5 1.4.1 Positioning the Rowing Skid on the board ......5 1.4.2 Tying up & towing the board ..........6 DUDE 18' ................ -
Page 4: Mojo 18
1 MOJO 18' Overview 1……MOJO 18' 2……Transport strap 3……Repair kit 4……5.4" fin 5……Air pump with hose 6……Backpack... -
Page 5: Assembly
Assembly Step 1: Make sure the valve pin is in the correct position before inflating. Push the valve pin down and rotate anti-clockwise to ensure that the valve is in the correct position to inflate. Now connect the hose of the pump to the valve and pump up the board to a pressure of 1.4 bar. - Page 6 Slide the guide pin of the fin into the fin box rail and rotate the knob to secure the fin in place. Make sure the fin is securely fixed in the fin box. Note: Do not drag the board over the ground. Place it in the water to avoid damage.
-
Page 7: Folding Away
Folding away Step 1: Fold over the stern of the board once so that the fold line is at the side fold mark (black arrow). Then continue rolling up the board towards the bow. When the board is rolled up, place the transport strap around the rolled up board and tighten the strap. -
Page 8: Additional Information
Additional information 1.4.1 Positioning the Rowing Skid on the board The MOJO 18' rowing board can be used alone, or in pairs (with two rowing systems). To row on your own, place the rowing system on the large non-slip mat on the board. -
Page 9: Tying Up & Towing The Board
1.4.2 Tying up & towing the board To enable the boat to be tied up or towed, there is a larger D-ring on the bow of the rudder board. -
Page 10: Dude 18
2 DUDE 18' Overview 1……DUDE 18' 2……Transport strap 3……Repair kit 4……5.4" fin 5……Air pump with hose 6……Backpack... -
Page 11: Assembly
Assembly Step 1: Make sure the valve pin is in the correct position before inflating. Push the valve pin down and rotate anti-clockwise to ensure that the valve is in the correct position to inflate. Now connect the hose of the pump to the valve and pump up the board to a pressure of 1.4 bar. - Page 12 Slide the guide pin of the fin into the fin box rail and rotate the knob to secure the fin in place. Make sure the fin is securely fixed in the fin box. Note: Do not drag the board over the ground. Place it in the water to avoid damage.
-
Page 13: Folding Away
Folding away Step 1: Fold over the stern of the board once so that the fold line is at the side fold mark (black arrow). Then continue rolling up the board towards the bow. When the board is rolled up, place the transport strap around the rolled up board and tighten the strap. -
Page 14: Additional Information
Additional information 2.4.1 Positioning the Rowing Skid on the board The DUDE 18' rowing board can be used alone, or in pairs (with two rowing systems). To row on your own, place the rowing system on the large non-slip mat on the board. -
Page 15: Tying Up & Towing The Board
2.4.2 Tying up & towing the board To enable the boat to be tied up or towed, there is a larger D-ring on the bow of the rudder board. -
Page 16: Airkayak 16
3 AIRKAYAK 16' Overview 1……AIRKAYAK 16' 6……..Repair kit 2……8" fin 7……..Air pump with hose 3……Deck support strip 8……..2 kayak seats with cushions 4……2 bilge sponges 9……..Foot rests 5……Transport strap 10……Backpack... -
Page 17: Assembly
Assembly Step 1: Make sure the valve pin is in the correct position before inflating. Push the valve pin down and rotate anti-clockwise to ensure that the valve is in the correct position to inflate. Now connect the hose of the pump to the valve and pump up the three chambers of the kayak one after the other to a pressure of 0.7 bar. - Page 18 Step 3: Insert the bilge sponges on both sides of the boat between the side and the hull to soak up any water inside the boat. Step 4: Slide the fin into the fin box guide and lock the fin in place with the safety wedge.
-
Page 19: Folding Away
Folding away Step 1: When you have extracted all the air from the three air chambers, remove the deck support strip and fold the sides inwards. Then turn the boat over and fold it lengthwise down the centreline so that the sides are on top of each other. - Page 20 Step 2: Fold over the bow of the kayak once so that the fold line is at the end of the hard plastic section. Then continue rolling up the boat towards the stern. When the kayak is rolled up, place the transport strap around the rolled up kayak and tighten the strap.
-
Page 21: Additional Information
Additional information 3.4.1 Securing the kayak seat & the foot rests Securing the kayak seat: Connect the seat cushion to the backrest of the kayak seat using the zip fastener. Then hook the buckles into the corresponding D-rings on the sides. Tighten all four straps evenly to secure the seat in place. -
Page 22: Cleaning The Boat
3.4.2 Cleaning the boat Step 1: Open the water drain holes at the front end and rear end of the kayak and remove both bilge sponges. Step 2: Rinse both cleaning openings in both directions (front and rear) to remove any dirt. Step 3: Place the kayak at an angle so the water can drain through the drain valves. - Page 24 +43 7239 202 75 office@rowandsail.com Row&Sail GmbH Gewerbezeile 9 | 4040 Lichtenberg/Linz | Austria www.rowandsail.com...
