TA890FXE BIOS Manual
BIOS Setup .................................................................................................1
1 Main Menu...............................................................................................3
2 Advanced Menu.......................................................................................6
3 PCIPnP Menu........................................................................................16
4 Boot Menu..............................................................................................19
5 Chipset Menu.........................................................................................21
6 T-S eries Menu........................................................................................27
7 Exit Menu...............................................................................................40
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TA890FXE - BIOS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Biostar TA890FXE - BIOS

Summary of Contents for Biostar TA890FXE - BIOS

  • Page 1 TA890FXE BIOS Manual BIOS Setup ....................1 1 Main Menu....................3 2 Advanced Menu..................6 3 PCIPnP Menu..................16 4 Boot Menu....................19 5 Chipset Menu..................21 6 T-S eries Menu..................27 7 Exit Menu....................40...

  • Page 2: Bios Setup

    TA890FXE BIOS Manual BIOS Setup Introduction T he purpose of this manual is to describe the settings in the AMI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM. T he power of CMOS RAM is supplied by a battery so that it retains the Setup information when the power is turned off.

  • Page 3: Pci Bus Support

    TA890FXE BIOS Manual PCI Bus Support T his AMI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component Interconn ect) local bus speci fication. DRAM S upport DDR3 SDRAM (Double Data Rate III Synchronous DRAM) is supported. Supported CP Us T his AMI BIOS supports the AMD CPU .

  • Page 4: System Memory

    TA890FXE BIOS Manual 1 Main Menu Once you enter AMI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system inform ation. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Chipset T-Series Exit System Overview Use [ENTER], [TAB] or [SHIFT-TAB] to...

  • Page 5: Ide Configuration

    TA890FXE BIOS Manual IDE Configuration T he BIOS will automatically detect the presence of ID E/SAT A devices. There is a sub-menu fo r each IDE/SAT A device. Select a device and press <Enter> to enter the sub-menu of detailed options. BIOS SETUP UTILITY Main IDE Confuguration...
  • Page 6 TA890FXE BIOS Manual Type Select the type of the IDE/SAT A drive. Options: Auto (Default) / CDROM / ARMD / Not Installed LBA/Large Mode Enable or disable the LBA mode. Options: Auto (Default) / Disabled Block (Multi- Sector Transfer) Enable or disable multi-sector trans fer. Options: Auto (Default) / Disabled PIO Mode...

  • Page 7: Advanced Menu

    TA890FXE BIOS Manual 2 Advanced Menu T he Advanced Menu allows you to configu re the settings of CPU, Super I/O, Power Management, and other system devices. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction.
  • Page 8 TA890FXE BIOS Manual Secure Virtual Machine Mode Virtualization T echnology can virtually separate your system resou rce into several parts, thus enhance the performance when running virtual machines or multi interf ace systems. Options: Enabled (Default) / Disabled PowerNow T his item allows you to enable or disable the PowerNow power saving technology. Options: Enabled (Default) / Disabled ACPI SRAT Table...

  • Page 9: Super Io Configuration

    TA890FXE BIOS Manual SuperIO Configuration BIOS SETUP UTILITY Advanced Configure ITE8721 Super IO Chipset Allows BIOS to Select Serial Port1 Base Serial Port1 Address [3F8/IRQ4] Addresses. OnBoard CIR Port [Disabled] CIR Port IRQ [IRQ10] Keyboard PowerOn [Disabled] Mouse PowerOn [Disabled] Restore on AC Power Loss [Power Off] Select Screen...

  • Page 10: Smart Fan Configuration

    TA890FXE BIOS Manual Stroke Keys Selected T his item will show only when Keyboard PowerOn is set “Stroke Key.” Options: Ctrl+F1 (Default) / Wake Key / Power Key / Ctrl+F2 / Ctrl+F3 / Ctrl +F4 / Ctrl+F5 / Ctrl+F6 Mouse PowerOn T his item allows you to control the mouse power on function.
  • Page 11 TA890FXE BIOS Manual Smart Fan C alibration Choose this item and then the BIOS will auto test and detect the CPU/System fan fun ctions and show CPU/System fan speed. Control Mode T his item provides several operation modes of the fan. Options: Quiet / Performan ce / Manual Fan Ctrl OFF(℃...

  • Page 12: Hardware Health Configuration

    TA890FXE BIOS Manual System1 Fan Limit of Start Fan spins in a start PWM value when termperature ex ceeds a start limit. 1~127 (℃) (With the interval of 1) Options: System1 Fan Start PWM T his item allows you to set Fan start PWM value. Options: 0~255 (With the interval of 1) System1 Fan PWM Control...

  • Page 13: Power Configuration

    TA890FXE BIOS Manual Power Configuration BIOS SETUP UTILITY Advanced ACPI Settings When EuP Enabled. System meets EuP EuP Control [Disabled] requirment. Suspend mode [S1 (POS)] All wake up events ACPI Version Features [ACPI v1.0] do not work except ACPI APIC support [Enabled] Power Button after AMI OEMB table...
  • Page 14 TA890FXE BIOS Manual AMI OEMB table Set this value to allow the ACPI BIOS to add a pointer to an OEMB table in the Root System Description T able (RSD T ) table. Options: Enabled (Default) / Disabled Headless mode T his is a server-speci f ic feature.

  • Page 15: Usb Configuration

    TA890FXE BIOS Manual USB Configuration T his item shows the USB controller and using USB device information. BIOS SETUP UTILITY Advanced USB Configuration Enables support for legacy USB. AUTO Module Version - 2.24.5-13.4 option disables legacy support if USB Devices Enabled: no USB devices are connected.
  • Page 16 TA890FXE BIOS Manual USB Mass Storage Dev ice Configuration BIOS SETUP UTILITY Advanced USB Mass Storage Device Configuration Number of seconds POST waits for the USB Mass Storage Reset Delay [20 Sec] USB mass storage device after start Device # unit command.

  • Page 17: Pcipnp Menu

    TA890FXE BIOS Manual 3 PCIPnP Menu T his section describes con figuring the PCI bus system. PCI, or Personal Computer Interconn ect, is a system which allows I/O devices to operate at speeds nearing the speed o f the CPU itself uses when communicating with its own special components. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction.

  • Page 18: Pci Latency Timer
