1.3 M
OTHERBOARD
Socket AM2+
AMD Athlon 64 / Athlon 64 FX / Athlon 64 X2 /
Sempron / Phenom processors
CPU
AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 3.0 and PowerNow
Support HyperTransport 3.0
FSB
Supports up to 5.2 GT/s Bandwidth
AMD 790GX
Chipset
AMD SB750
ITE IT8718
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Super I/O
Environment Control initiatives,
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
DIMM Slots x 4
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Max Memory Capicity 16GB
Main
Dual Channel Mode DDR2 memory module
Memory
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+ CPU)
Registered DIMM and ECC DIMM is not
supported
Radeon HD 3300
Onboard side port memory 128MB DDR2
Graphics Max Shared Video Memory is 512MB
DX10/UVD/HDCP support
Hybrid CrossFireX support (by ATI driver)
AMD SB750
IDE Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
AMD SB750
Data transfer rates up to 3 Gb/s.
SATA II
SATA Version 2.0 specification compliant.
RAID 0,1,5,1+0 support
2
F
EATURES
TA790GX XE TA790GX M2+/TA790GXB M2+
Socket AM2+
AMD Athlon 64 / Athlon 64 FX / Athlon 64 X2 /
Sempron / Phenom processors
AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 3.0 and PowerNow
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
AMD 790GX
AMD SB750
ITE IT8718
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control initiatives,
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
DIMM Slots x 4
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Max Memory Capicity 16GB
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+ CPU)
Registered DIMM and ECC DIMM is not
supported
Radeon HD 3300
Onboard side port memory 64MB DDR2 (for
TA790GX M2+ only)
Max Shared Video Memory is 512MB
DX10/UVD/HDCP support
Hybrid CrossFireX support (by ATI driver)
AMD SB750
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
AMD SB750
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 specification compliant.
RAID 0,1,5,1+0 support
