N68S3+ BIOS Manual
BIOS Setup .................................................................................................1
1 Main Menu...............................................................................................3
2 Advanced Menu.......................................................................................7
3 PCIPnP Menu........................................................................................18
4 Boot Menu..............................................................................................23
5 Chipset Menu.........................................................................................26
6 Performance Menu...............................................................................30
7 Exit Menu...............................................................................................36
i
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Biostar N68S3PLUS - BIOS
Summary of Contents for Biostar N68S3PLUS - BIOS
- Page 1 N68S3+ BIOS Manual BIOS Setup ....................1 1 Main Menu....................3 2 Advanced Menu..................7 3 PCIPnP Menu..................18 4 Boot Menu....................23 5 Chipset Menu..................26 6 Performance Menu................30 7 Exit Menu....................36...
-
Page 2: Bios Setup
N68S3+ BIOS Manual BIOS Setup Introduction T he purpose of this manual is to describe the settings in the AMI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to CMOS RAM. T he power of CMOS RAM is supplied by a battery so that it retains the Setup information when the power is turned off. -
Page 3: Pci Bus Support
N68S3+ BIOS Manual PCI Bus Support T his AMI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component Interconn ect) local bus speci fication. DRAM S upport DDR3 SDRAM (Double Data Rate III Synchronous DRAM) is supported. Supported CP Us T his AMI BIOS supports the AMD CPU . - Page 4 N68S3+ BIOS Manual 1 Main Menu Once you enter AMI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system inform ation. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Chipset Performance Exit System Overview Use [ENTER], [TAB] or [SHIFT-TAB] to...
-
Page 5: Ide Configuration
N68S3+ BIOS Manual IDE Configuration T he BIOS will automatically detect the presence of ID E/SAT A devices. There is a sub-menu fo r each IDE/SAT A device. Select a device and press <Enter> to enter the sub-menu of detailed options. BIOS S ETUP UTILITY Main IDE C onfiguration... - Page 6 N68S3+ BIOS Manual nVidia RAID Setup BIOS S ETUP UTILITY Chips et RAID Setup Options nVidi a RAID Functi on [ Disabled] abled SATA 1 Raid [ Disabled] Enab led SATA 2 Raid [ Disabled] SATA 3 Raid [ Disabled] SATA 4 Raid [ Disabled] S elect Screen...
-
Page 7: Hard Disk Write Protect
N68S3+ BIOS Manual T he BIOS detects the information and values of resp ective devices, and these information and values are shown below to the name of the sub-menu. Type Select the type of the IDE/SAT A drive. Options: Auto (Default) / CDROM / ARMD / Not Installed LBA/Large Mode Enable or disable the LBA mode. -
Page 8: Advanced Menu
N68S3+ BIOS Manual 2 Advanced Menu T he Advanced Menu allows you to configu re the settings of CPU, Super I/O, Power Management, and other system devices. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. - Page 9 N68S3+ BIOS Manual GART Error Reporting T his option should remain disabled for the normal operation. T he driver eveloper may enable it for testing purpose. Options: Disabled (Default) / Enabled Microcode Update T his item allows you to enable or disable Microcode Update function. Options: Enabled (Default) / Disabled Secure Virtual Machine Mode...
-
Page 10: Super Io Configuration
N68S3+ BIOS Manual SuperIO Configuration BIOS S ETUP UTILITY Advanced Confi gure ITE8718 Super IO Chi pset Allo ws BIOS to E nable or D isable Flopp y Onboa rd Floppy Con troller [ Enabled] Cont roller Seria l Port1 Addre ss [ 3F8/IRQ4] Paral lel Port Addr ess [ 378]... - Page 11 N68S3+ BIOS Manual ECP Mode DMA Channel T his item allows you to select parallel port ECP DMA. Options: DMA3 (Default) / DMA0 / DMA1 Parallel Port IRQ T his item allows you to select the IRQ for the onboard parallel port. Options: IRQ7 (Default) / IRQ5 / Disabled Keyboard Pow erOn...
-
Page 12: Hardware Health Configuration
N68S3+ BIOS Manual Hardware Health Configuration T his item shows the system temperature, fan speed, and voltage information. BIOS SETUP UTILITY Advanced Hardware Health Configuration Enables Hardware Health Monitoring H/W Health Function [Enabled] Device. Shutdown Temperature [Disabled] CPU Temperature SYS Temperature CPU FAN Sytem1 FAN +12.0V... -
Page 13: Smart Fan Configuration
N68S3+ BIOS Manual Smart Fan Configuration BIOS SETU P U TILITY Advan ced Smart Fan Conf iguration When you choice [Auto] ,[3Pin] or [4Pin], CPU Smart Fan [Dis abled] please run the Smart Fan Cali bration calibration to define Control Mode the Fan parameters for Fan Ctrl OFF( C) Smart Fan control... -
Page 14: Power Configuration
N68S3+ BIOS Manual Fan Ctrl Start Value When CPU/System temperature arriv es to the set value, the CPU/System fan will work under Smart Fan Function mode. Options: 0~127 (With the interval of 1) Fan Ctrl Sensitive Increasing the value will raise the speed of CPU/System fan. Options: 1~127 (With the interval of 1) Power Configuration... - Page 15 N68S3+ BIOS Manual ACPI APIC support T his item is used to enable or disable the motherboard's APIC (Advan ced Programmable Interrupt Controller). T he APIC provides multiprocessor support, more IRQs and faster interrupt handling. Options: Enabled (Default) / Disabled AMI OEMB table Set this value to allow the ACPI BIOS to add a pointer to an OEMB table in the Root System Description T able (RSD T ) table.
- Page 16 N68S3+ BIOS Manual Resume PCIE Wake# Enable / Disable PCIE to generate a wake ev ent. Options: Disabled (Default) / Enabled Resume On LAN (MAC) Enable / Disable LAN (MAC) to generate a wake ev ent. Options: Disabled (Default) / Enabled Resume on Ring T his item allows you control the wake on ring function.
-
Page 17: Usb Configuration
N68S3+ BIOS Manual USB Configuration T his item shows the USB controller and using USB device information. BIOS S ETUP UTILITY Advanced USB C onfiguration Enab les support for lega cy USB. AUTO Modul e Version - 2 .24.5-13.4 opti on disables lega cy support i f USB D evices Enable d: no U SB devices a re... -
Page 18: Usb Mass Storage Device Configuration
N68S3+ BIOS Manual USB 1.1/2.0 Controller T his item allows you to enable or disable USB 1.1/2.2 Controller. Options: Enabled (Default) / Disabled USB Mass Storage Dev ice Configuration BIOS SETUP UTILITY Advanced USB Mass Storage Device Configuration Number of seconds POST waits for the USB Mass Storage Reset Delay [20 Sec] USB mass storage... -
Page 19: Pcipnp Menu
N68S3+ BIOS Manual 3 PCIPnP Menu T his section describes con figuring the PCI bus system. PCI, or Personal Computer Interconn ect, is a system which allows I/O devices to operate at speeds nearing the speed o f the CPU itself uses when communicating with its own special components. Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. - Page 20 N68S3+ BIOS Manual PCI Latency Timer T his item controls how long a PCI device can hold the PCI bus bef ore another takes over. T he longer the latency, the longer the PCI device can retain control of the bus before handing it over to another PCI device.
-
Page 21: Reserved Memory Size
N68S3+ BIOS Manual PCI Resource BIOS SETUP UTILITY PCIPnP PCI Resource Available: Specified IRQ is available to be IRQ3 [Available] used by PCI/PnP IRQ4 [Available] devices. IRQ5 [Available] Reserved: Specified IRQ7 [Available] IRQ is reserved for IRQ9 [Available] use by Legacy ISA IRQ10 [Available] devices. -
Page 22: Pci Express Configuration
N68S3+ BIOS Manual PCI Express Configuration BIOS SETUP UTILITY PCIPnP PCI Express Configuration Enable/Disable Pci Express Device Relaxed Ordering [Auto] Relaxed Ordering. Maximum Payload Size [Auto] Extended Tag Field [Auto] No Snoop [Auto] Maximum Read Request Size [Auto] Active State Power-Management[Disabled] Extended Synch [Auto] Select Screen... -
Page 23: Active State Power-Management
N68S3+ BIOS Manual Maximum Read Request Size T his item sets Maximum Read Request Size of Pci Express Devi ce or allows System BIOS to select the value. Options: Auto (Default) / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048 Bytes / 4096 Bytes Active State Power-Management T his item sets the ASPM configuration for the PCI Express devices b efore the... -
Page 24: Boot Settings Configuration
N68S3+ BIOS Manual 4 Boot Menu T his menu allows you to setup the system boot options. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Chipset Performance Exit Boot Settings Configure Settings during System Boot. > Boot Settings Configuration > Boot Device Priority >... -
Page 25: Boot Device Priority
N68S3+ BIOS Manual Full Screen LOGO Show T his item allows you to enable/disable Full Screen LOGO Show function. Options: Enabled (Default) / Disabled AddOn ROM Display Mode T his item sets the display mode for option ROM. Options: Force BIOS (Default) / Keep Current Bootup Num-L ock Selects the NumLock State after the system switched on. -
Page 26: Removable Drives
N68S3+ BIOS Manual Removable Drives T he BIOS will attempt to arrange the removable drive boot sequence automatically. You can also change the booting sequence. The number of device items that appears on the screen depends on the number of devices installed in the system. Options: Floppy Disks / Zip100 / USB-FDD0 / USB-FDD1 / USB-ZIP0 / USB-ZIP1 / LS120... -
Page 27: Chipset Menu
N68S3+ BIOS Manual 5 Chipset Menu T his submenu allows you to configure the speci fic features of the chipset installed on your system. T his chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. BIOS SETUP UTILITY Main Advanced... - Page 28 N68S3+ BIOS Manual Alternate VID T his item allows you to specify the alternate V ID while in low power states.. SouthBridge M CP68 Configuration BIOS SETUP UTILITY Chipset SouthBridge MCP61 Chipset Configuration Options PCI Express -> PCI -> Primary Graphics Adapter [PCI Express ->...
- Page 29 N68S3+ BIOS Manual AZALIA AUDIO T his item allows you to control the HD audio device. Options: Auto (Default) / Disabled Onboard Lan T his option allows you to control the onboard LAN controller. Options: Auto (Default) / Disable MAC ID Information T his item shows the MAC ID.
- Page 30 N68S3+ BIOS Manual MCP61 (SB) to K8 (CPU) Frequency T his option allows you to auto control MCP61 (SB) to K8 (CPU) Frequency. Options: 800 MHz (Default) / 200 MHz / 400 MHz / 600 MHz / 1000 MHz (Differed by CPU) MCP61 (SB) to K8 (CPU) LinkWidth T his option allows you to auto control MCP61 (SB) to K8 (CPU) LinkWidth.
-
Page 31: Performance Menu
N68S3+ BIOS Manual 6 Performance Menu T his submenu allows you to change voltage and clock of various devices. (Howev er, we suggest you use the default setting. Changing the voltage and clock improperly may damage the device.) Notice Beware of that setting inappropriate values in items of this menu may cause system to malfunction. - Page 32 N68S3+ BIOS Manual PCIE/S ATA Spread Spectrum T his item allows you to control PCIE/SA T A Spread Spectrum fun ction. Options: Enabled (Default) / Disabled CPU Voltage T his item allows you to select CPU Voltage Control. Chipset Voltage T his item allows you to select Chipset Voltage Control.
- Page 33 N68S3+ BIOS Manual Memclock Value T his item allows you to set the Memory Clock. Options: Auto (Default) / DDR3-800 / DDR3-1066 / DDR3-1333 / DDR3-1600 DRAM Timing Mode T his item allows you to choose to manually or automatically regul ate the DRAM T iming.
-
Page 34: Memory Configuration
N68S3+ BIOS Manual tWTR Options: Auto (Default) / 4~7 CLK tRFC0 / tRFC1 / tRFC2 / tRFC3 Options: Auto (Default) / 90ns / 110ns / 160ns / 300ns / 350ns Memory Configuration BIOS SETUP UTILITY Performance Memory Configuration Enable Bank Memory Interleaving Bank Interleaving [Auto]... - Page 35 N68S3+ BIOS Manual MemClk Tristate C3/ATLVID T his item enables or disables the MemClk T ristate function in C3 Mode. Options: Disabled (Default) / Enabled Memory Hole Remapping T his item allows you to enable or disable the remapping of the overlapped PCI memory above the total physical memory.
- Page 36 N68S3+ BIOS Manual Custom P-States T his item allows you to select the P-States controlling. Options: Disabled (Default) / Enabled Core FID T his item allows you to select the Ratio/Frequency of AM3 CPU. Options: x8.0 1600MHz ~ x14.5 2900MHz (Differed by CPU) Core DID T his is the Core Divider.
-
Page 37: Save Changes And Exit
N68S3+ BIOS Manual 7 Exit Menu T his menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. BIOS SETU P U TILITY Main Advan ced PCIPnP Boot Chipset Performance Exit Exit Options Exit system setup after saving the... -
Page 38: Change Supervisor Password
N68S3+ BIOS Manual Security T his sub-menu allows you to provide/revise supervisor and user password. BIOS SETU P U TILITY Exit Security Setti ngs Install or Change the password. Supervisor Pas sword :Not Installe d User Password :Not Installe d Change Supervi sor Password User Access Le vel [Ful l Access]... - Page 39 N68S3+ BIOS Manual Boot Sector Virus Protection T his option allows you to choose the VIRUS Warning feature that is used to protect the IDE H ard Disk boot sector. If this fun ction is enabled and an attempt is made to write to the boot sector, BIOS will display a warning message on the screen and sound an alarm beep.
