Features and Technical Explanation
Product Features
Highlights key functionalities such as Anti Crease, Fuzzy Logic, Child-Lock, low noise control, Direct Drive, and built-in heater.
Fuzzy Logic Washing Time Determination
Explains how Fuzzy Logic determines optimal washing time based on sensed water temperature, selected temperature, and laundry amount.
Water Level Control
Details the water level control system using a pressure sensor and conditions for stopping water supply or proceeding with washing.
Door Operation Restrictions
Specifies when the door cannot be opened: during program operation or when the Door Lock light is on.
Parts Identification
Accessories
Lists included accessories such as inlet hoses and spanners.
Installation Guide
Installation Area Conditions
Ensures proper installation by checking ground level, humidity, and foreign objects under the unit's feet.
Unpacking and Appliance Check
Guides on opening the box, removing packing support and transit bolts, and checking the appliance's condition.
Leveling and Stability Check
Instructions for checking and adjusting the washing machine's level and stability using a spirit level and diagonal tests.
Operation Guide
Operation Options
Details on available options like Dry, Intensive, Pre Wash, and Medic Rinse for customizing wash cycles.
Wash Program Selection
Explains how to select wash programs using the program selector dial and its available cycles.
Start/Pause Button Function
Describes the function of the Start/Pause button for initiating, pausing, and auto power-off.
Child Lock Feature
Explains how to set and cancel the Child Lock feature by pressing specific buttons simultaneously.
Tub Clean Function
Details how to activate the Tub Clean cycle for cleaning the inside of the washer.
LED Display Information
Explains the LED display for remaining time, error indications, and troubleshooting references.
Time Delay and Beep Control
Describes setting time delay, canceling time delay, and controlling the beep sound ON/OFF function.
Power Button Function
Explains how to turn power on/off and cancel functions using the power button.
Spin Button Operation
Details how to select spin speed, including available options like Rinse Hold, No spin, 400/800/1400.
Water Temperature Selection
Explains how to select water temperature, noting 60°C is for specific cycles.
Wiring Diagrams and Program Chart
PCB Layout
Illustrates the layout of the main printed circuit board (PCB) and its component connections.
Program Chart
Provides a detailed chart showing wash cycles, water supply, spin, drain, and normal working times.
Troubleshooting
Pre-Service Checks
Steps to follow before servicing, including asking the customer, checking adjustments, and verifying operation.
Load Test Mode Operation
Guides on entering and operating the load test mode to check various functions and display statuses.
Water Level Frequency Check
Procedure for checking water level frequency by pressing the Pre Wash and Spin buttons simultaneously.
Thermistor Temperature Check
Method for checking thermistor temperature by pressing Medic Rinse and Spin buttons simultaneously.
Error Display Codes
Lists common error codes (IE, OE, FE, PE, dE, UE, tE, LE, AE, PF, dHE) with their symptoms and causes.
Water Inlet Error (IE) Troubleshooting
Troubleshooting steps for the Water Inlet Error (IE), covering tap closure, water level frequency, and connector checks.
Unbalanced Load Error (UE) Troubleshooting
Guides on resolving the Unbalanced Error (UE) by checking load distribution, laundry mix, and machine leveling.
Water Outlet Error (OE) Troubleshooting
Troubleshooting steps for Water Outlet Error (OE), focusing on drain hose kinks and pump filter clogs.
Overflow Error (FE) Troubleshooting
Steps to diagnose and resolve the Overflow Error (FE), involving inlet valve, air chamber, and pressure switch checks.
Pressure Sensor S/W Error (PE) Troubleshooting
Troubleshooting for Pressure Sensor S/W Error (PE), checking connectors, harness, pressure switch resistance, and air chamber.
Door Open Error (dE) Troubleshooting
Guides on resolving the Door Open Error (dE), checking door closure, assembly alignment, latch hook spring, and door switch.
Thermistor (Heating) Error (tE) Troubleshooting
Troubleshooting for Thermistor (Heating) Error (tE), checking connectors, thermistor, and heater resistance.
Motor Locked Error (LE) Troubleshooting
Steps to diagnose Motor Locked Error (LE), checking connectors, rotor, hall sensor, and stator resistance.
Dry Heater Error (dHE) Troubleshooting
Troubleshooting for Dry Heater Error (dHE), checking connectors, thermistor, dry heater, and dry fan motor.
Dry Heater Trouble Diagnosis
Diagnosing Dry Heater issues by checking resistance, thermostat status, and voltage on connectors.
Dry Fan Motor Trouble Diagnosis
Diagnosing Dry Fan Motor issues by checking connectors, terminal resistance, and voltage.
Troubleshooting Without Error Codes
No Power Troubleshooting
Steps to diagnose and resolve 'No Power' issues, checking power plug, voltage, multi-plug usage, and PCB connections.
Vibration and Noise During Spin
Guides on resolving vibration and noise issues by ensuring transit bolts and base packing are removed.
Water Leak Issues
Dispenser Drawer Water Leaks
Troubleshooting water leaks from the dispenser drawer, checking tray, compartment usage, and detergent condition.
Gasket and Door Water Leaks
Diagnosing water leaks from the gasket or door, checking cleaning, damage, inlet hoses, and drain hose.
General Water on Floor Issues
Addresses general water on floor issues by checking inlet hoses, washer leveling, and drain filter/hose status.
Disassembly Instructions
Control Panel Disassembly
Step-by-step instructions for disassembling the control panel and accessing the internal components.
Dispenser Assembly Disassembly
Detailed steps for disassembling the dispenser assembly, including the drawer, hose clamps, and bellows.
Inlet Valve Disassembly
Instructions for disconnecting the inlet valve wiring and unscrewing it for removal.
Lower Cover Removal
Procedure for opening the lower cover cap and removing the lower cover using a coin and screwdriver.
Door Assembly Removal
Steps for opening the door completely and removing the door assembly by unscrewing hinge screws.
Gasket Assembly Removal
Instructions for taking apart cabinet and tub gasket clamps, and removing the cabinet and lower covers.
Pump Disassembly
Steps for removing the pump, including disconnecting hoses, wiring, and unscrewing mounting screws.
Heater Removal
Procedure for removing the heater by loosening the M6 heater nut and ensuring proper insertion on reassembly.
Switch Assembly and Door Lock Disassembly
Instructions for disassembling the switch assembly and door lock, including checking operating times.
Foreign Material Removal from Drum/Tub
Procedure for removing foreign material stuck between the drum and tub by removing the heater.
Exploded Views
Cabinet Assembly Exploded View
Detailed exploded view of the washing machine's cabinet assembly, showing all external and structural components.
Control Panel & Dispenser Assembly Exploded View
Exploded view of the control panel and dispenser assembly, illustrating the layout of buttons, drawers, and related parts.
Drum & Tub Assembly Exploded View
Exploded view of the drum and tub assembly, detailing components like the drum, tub, motor, and suspension system.
Dryer Assembly Exploded View
Exploded view of the dryer components, showing the blower housing, fan, and related parts for the drying function.
