Summarization of Contents
Installation Steps
Step 1: Base Component Assembly
Assemble base components using specified hardware and parts (700-005, 700-006).
Step 2: Frame Connection
Connect main frame elements using M8x45 bolts and part 700-002.
Step 3: Support Arm Attachment
Mount support arms using M8x45 bolts, M8 bolts, and WPIN-8.
Step 4: Main Frame Securing
Securely connect main frame sections using M8x45 bolts and part 700-007.
Step 5: Crossbar Installation
Attach crossbars using M8x45 bolts and WPIN-8 components.
Step 6: Chassis Fastening
Fasten chassis components using M8x45 bolts and part 700-010.
Step 7: Final Frame Assembly
Complete frame assembly by attaching parts using M8x45, WPIN-8, and 700-011.
Step 8: Wheel Bracket Mounting
Install wheel brackets using M6x25, M6x50, 9021-6, 700-013, 700-014.
Step 9: Axle and Handlebar Attachment
Attach axle and handlebar components using M6x35, M6, HGRR-20, LAM-V30, 700-011, 700-012.
Step 10: Overall Assembly Completion
Complete assembly with M8x45, M8, WPIN-8, LAM-V30, HGRR-20, 700-018.
Step 11: Wheel Mounting Procedure
Mount wheels using M10x25, 125-10, 160, 700-017.
Step 12: Final Component Installation
Install final components such as 11023-4, 125-21, POM-18, 200, 260/260-LU.
Safety Warnings
Restrictions and Prohibitions
Outlines usage restrictions, including no highway use, no commercial use, and no towing behind vehicles.
Operational Precautions
Advises against leaving people/animals in the boat during transport and notes potential tire discoloration.
Load and Deformation Warning
Warns about static load causing tire deformation on TR350 models, which reverts when unloaded.
Liability and Warranty Disclaimer
States user discretion for risk, disclaims liability for damages, and voids warranty upon non-compliance.
