4. Insert nails into nail channel
through rear of nail chamber
(see Figure 4). Make sure nail
points are towards bottom of
tool.
Note: We recommend that you
only use Powerfast brad nails in
this tool. Wrong brad nails can
cause jamming.
5. Replace nail pusher into nail
chamber. Do this by inserting
flat metal end of nail pusher into
nail channel (see Figure 5).
Fully push nail pusher into nail
chamber. Push hook end of nail
pusher up and latch it to nail
chamber.

Operating Tool

Keep trigger lock in the OFF position and finger off trigger until
ready to drive nail.
Keep all body parts away from nail exit opening on tool.
1. Make sure trigger lock is in the OFF
position.
2. Plug tool into a 115 Volt/60 Hertz outlet.
3. Grip tool firmly and hold against work
surface. Use enough pressure to depress
safety lock. The safety lock is located on
nail exit of tool (see Figure 6).
IMPORTANT: The safety lock must be
depressed for this tool to operate. This
tool will not fire unless this is done.
Nail Channel
!
WARNING
WARNING ICON G 001
! WARNING
WARNING ICON G 001
6
Brad Nails
Figure 4
Figure 5
Nail Channel
Safety Lock
Figure 6
