- Page 1 RehaMed Aquatics The New Standard in Aquatic Lifts! OWNERS MANUAL...
-
Page 2: Table Of Contents
Product Overview………………………………………………… 4 A. Product Components – Standard to All Products……………………………………… 5 – PAL Base Assembly………………………………………….. 6 B. Unpacking & Assembly Instructions- PAL………………………. 7-9 Splash! / Splash! Hi-Lo / Splash! HD / Splash! Mariner Product Overview………………………………………………… 10 C. Product Components –... - Page 3 INTRODUCTION The purpose of this document is to provide information relating to the operation, care, and maintenance of RehaMed International’s line of Aquatic Lifting Products. Our goal is to provide our customers with the most advanced and innovative designs that offer exceptional quality at affordable prices. We design and manufacture our products so that all individuals with disabilities and mobility impairments can have access to, and enjoyment from the recreation activity of their choice.
-
Page 4: Pal / Pal Hi-Lo Product Overview
This design insures consistent operation and elimination of service problems that occur with water powered pool lifts. The PAL is available in a Hi-Lo version to accommodate facilities with both in-ground pools and above-ground spas. -
Page 5: Product Components
A– PRODUCT COMPONENTS REFER TO THE DIAGRAM ON PG.7 FOR COMPONENT IDENTIFICATION. All PAL and Splash! Products – Standard Components in all Units Control Box. Forms the bottom of the control console; this unit controls the mechanical operations of the lift. Three wire leads connect to the rear of the Control Box. -
Page 6: Pal Base Assembly
PAL / PAL Hi-Lo - Base Assembly Only The Base Assembly is made up of several components as described below: Casters. These are the wheels on which the PAL moves. The front wheels are rigid and the back wheels are swivel and locking casters to facilitate movement of unit. -
Page 7: Unpacking & Assembly Instructions- Pal
Contact RehaMed or dealer immediately to notify of missing or damaged parts. The PAL is shipped on a cardboard covered pallet. This pallet is VERY HEAVY. You will need to gather the following tools to begin the unpacking and assembly of your unit: •... - Page 8 IMPORTANT NOTE: Two people will be needed for completion of step 11. 1. Cut bands and remove long box containing mast from side of cardboard enclosure. 2. Remove the cardboard enclosure by removing the screws at the bottom and lifting off the enclosure. 3.
- Page 9 17. Insert actuator cable (with the “o” ring) into receptacle #1 on the control box. 18. Insert 24v motor cable into receptacle #2 on control box. 19. Return housing to normal position. 20. Insert handle into slots. 21. Attach actuator to actuator arm using hardware (2 3/4” bolt, nut and 2 plastic spacers) connected to actuator.
-
Page 10: Splash! / Splash! Hi-Lo / Splash! Hd / Splash! Mariner
THE SPLASH! – SEMI-PORTABLE AQUATIC LIFT SYSTEMS SPLASH!- Product Overview The Splash!-aquatic lifting system is a semi-portable lift system designed for swimming facilities seeking to provide universal access to their pools. The Splash! is battery powered and is operated by a screw driven actuator. This design insures consistent operation and elimination of service problems that occur with water powered pool lifts. -
Page 11: Product Components - Standard To All Products
C– PRODUCT COMPONENTS REFER TO THE DIAGRAM ON PG.13 FOR COMPONENT IDENTIFICATION. All PAL and Splash! Products – Standard Components in all Units Control Box. Forms the bottom of the control console; this unit controls the mechanical operations of the lift. Three wire leads connect to the rear of the Control Box. -
Page 12: Splash! Base Assembly
Splash! / Splash! Hi-Lo / Splash! HD / Splash! Mariner Base Assembly Only Base Assembly. The part of the Splash! that mounts to the pool deck or boat dock. The Base Assembly is made up of several components as described below: Rotation Motor Assembly. -
Page 13: Unpacking & Assembly Instructions- Splash
D. UNPACKING & ASSEMBLY INSTRUCTIONS Splash! – Semi-Permanent Aquatic Lifting Systems Mast Actuator Shaft Hand Control 73" Actuator Arm Chair Support Arm Actuator/ Support Arm Motor Cable Console Bracket Bolt Attachment Battery Cover Chair Assembly Housing Control Box 5" 5" Base Assembly (located under 4 1/2"... - Page 14 Important Note: Two people will be needed for completion of step #6. Move pallet to area where lift will be installed prior to opening. Remove the outer bands. 1. Remove the cardboard enclosure on the pallet by removing the screws at the bottom and lifting off the enclosure.
-
Page 15: Pool Deck Installation
Pool Deck Installation for the Splash! The Splash! is attached to the pool deck using any standard sleeve (round or square anchor) commonly used for starting blocks or backstroke flag stan- chions. We recommend a standard anchor with a 1.90 inside diameter and 6 inches of depth. -
Page 16: Battery Charging
F. CONTROL OPERATION All units perform the following operations: Rotate the seat. Either left or right in the direction of the arrows. Splash! total turning radius is 359º and PAL total turning radius is 240º. Raise the seat. Lower the seat. -
Page 17: Transferring
G. TRANSFERRING (For PAL and Splash! units): Once the unit is positioned for use, use the following procedure to transfer to the seat and into the water for desired aquatic activity: • Rotate the seat to either side of the lift that is the most comfortable position for transfer. -
Page 18: Maintenance
Positioning For PAL Only Four things to REMEMBER when positioning PAL for use. • The PAL is Heavy. It is easy to roll, but DO NOT roll too fast or it may be hard to stop. • Position the PAL in an area that allows plenty of room for transferring to and from a wheelchair. -
Page 19: Trouble Shooting
I. TROUBLE SHOOTING Unit does not Rotate Does unit raise or lower? Yes. Check hand control connection to battery for damaged pins. – Check connection to 12v motor at battery and at motor. Is battery charged? Is battery connected properly? –... -
Page 20: Dimensions/Capacity
SPECIFICATIONS Splash!/Hi-Lo/ HD /Mariner PAL/PAL-Hi-Lo 1. Dimensions/Capacity Overall Height 73 inches 73 inches Base Dimensions 18 inches Dia. Hgt. 23.5, lgth.37.25, width 29.25 inches Total Weight 140 lbs. HD-160 lbs. 845 pounds Overall Length (footprint) 70-76” (fully extended) 85-91” (fully extended) 53”... -
Page 21: Materials And Finish
44”- 58” total travel from highest to lowest point w/ standard actuator. Seat Depth: 18-20” below water line. Rotation: Splash! 359º, PAL 240º US Patent No. 5,790,995 PAL-Portable Aquatic Lift, the PAL logo, the Splash!, and the Splash! logo are registered trademarks of RehaMed International, LLC. -
Page 22: Standard/Optional Accessories
L. STANDARD ACCESSORIES/ OPTIONAL ACCESSORIES The following items are included with all Pool lift models: Console Cover: Protects battery and control unit from exposure to water. Seat Belt Assembly: Nylon, water resistant belt for added security. Battery/Charger: 24 volt rechargeable battery. Additional Accessories may be purchased for your Unit Stability Vest: Five point restraint for individuals who need higher degree of stability than provided with standard seat belt. -
Page 23: Parts List
Hub Assembly 100-5000 Mast Assembly 100-6000 Actuator Arm 100-7000 Support Arm 100-8000 Seat Arm 100-9000 Seat Assembly 110-1000 PAL Main Frame 110-2000 Stabilizer 110-3000 Counter Weight Plate 110-4000 Housing Assembly 110-5000 Handle Assembly 220-1000 Splash! Base Assembly 220-2000 Console Assembly... - Page 24 RehaMed International, LLC. 14008 SW 140th Street • Miami, FL 33186 800-577-4424 Toll Free • 305-255-1400 Phone • 305-969-2155 Fax info@poollifts.com http://www.poollifts.com...
