Domestic
Single Tank Systems
Model ST8
Model ST10
Owner's Instruction Manual
Ultra Clear
WASTEWATER TREATMENT SYSTEMS
Highland Tanks Pty Ltd trading as
Wastewater Treatment Systems
Factory: 16 Gantry Place, BRAEMAR NSW 2575
Postal: PO Box 1158, MITTAGONG NSW 2575
Phone: 02 4871 2156 or 0419 545 319 Fax: 02 4872 4109
Email: sales@highlandtanks.com.au
www.ultraclear.com.au
Ultra Clear
Advertisement
Table of Contents
Related Manuals for Ultra Clear ST10
Summarization of Contents
System Description and Function
Primary Treatment
Sewage treatment through sedimentation and anaerobic digestion.
Aerobic Treatment
Wastewater treated with oxygen and microbes in aeration chambers.
Sludge Return
Settling sludge returned to the primary inlet of the septic chamber.
Clarifier/Settling Chamber
Suspended solids settle, sludge returns to primary chamber.
Disinfection
Water chlorinated to remove pathogens, with 300L contact time.
Effluent Disposal
Treated effluent pumped to disposal area; owner maintains sprinklers.
Air Supply
Air blower supplies air for aeration and venturi air lift devices.
Electrical Control Unit
Control unit with alarm panel, green light for power, audio/visual fault warnings.
Operation and General
System operates automatically; power consumption similar to refrigerator.
Intended Use
System treats wastewater for up to 10 persons (ST10) or 8 (ST8).
Servicing Requirements
System serviced every 3 months by authorised agent for warranty.
Basic Operating Instructions
Ensure servicing, use correct products, respond to alarms, maintain power.
Troubleshooting
No Power Light
Check power failure or contact service technician if green light is off.
Air and Water Alarms
Red LEDs and audible alarms indicate blower or high water issues.
Odour Issues
Bad odours from system/sprinklers due to products or low aeration.
Blocked Drainage Lines
Plumbing issue from house to system; check inspection opening or call plumber.
Electrical Troubleshooting
Check circuit breakers, fuse, cabling. Electrical wiring not covered by warranty.
Landscaping and Site Management
Landscaping
Ensure drainage away from system; avoid pooling gardens. Warranty excludes storm water damage.
Desludging Requirements
Service technicians check sludge; desludging depends on household size/usage, 3-8 years.
Safety Information
Don't remove lids/covers except by technicians. Electrical wiring by electricians.
Spreading of Hydraulic Loads
Avoid using bath, washing machine, dishwasher simultaneously; spread loads.
Recommended Product Usage
Washing Powders & Liquids
Avoid bleach, whiteners, softeners. Use recommended dosage or less.
Fabric Softeners
Better not used; coats bacteria and hinders treatment.
Products Not to Be Used
Avoid antibacterial solutions, bleaches, toilet cleansers, ammonia.
Recommended Products
Use environmentally friendly and safe products for septic tanks.
Owner Responsibilities and Regulations
Responsibility
Owner must have maintenance agreement, follow manual, keep tank clear, ensure access.
Irrigation/Disposal Area
Owner responsible for installing and maintaining irrigation as required by Council.
NSW Health and Local Government Requirements
Follow council requirements, get approval, manage effluent, no fruit/veg irrigation.
Warranty and Service Life
Concrete Tanks Warranty
Warranty commencing on installation date for 15 YEARS.
Mechanical and Electrical Parts Warranty
2 YEARS warranty covering parts and labour (1st year), parts only (2nd year).
Statement of Service Life
Components have MINIMUM SERVICE LIFE of 15 years, mechanical/electrical 5 years.
