Summary of Contents for Fujiyama FHS 12000 E
- Page 1 ELITE SERIES -FHS 4000 - FHS 5000 -FHS 9000 - FHS 12000 1312...
- Page 2 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E INDEX Index Distinguished User Superior Features Gas Connection Assembly Instruction Installation Control Setting Of The Heater Operating Instructions Cleaning and Maintenance Tecnical Features Information About The Products Intended Use Of The Appliance Safety Warnings And Points To Be Careful Before Calling The Uthorised Service...
-
Page 3: Superior Features
FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E DISTINGUISHED USER We are proud of presenting such a excellent air tight heater that you can use every space of your home , work place or colosed area thanks to its economic, modern and elegant lines, practical dimensions and which provides you to profit from natural gas or LPG comforts by safety of Ersel and which also has lower expenses but higher efficiency in comparision with its rivals. -
Page 4: Gas Connection
– This appliances shall be installed in accordance with current regulations and only used in a well-ventilated space.Refer to the instructions before installing and using the appliance. – Use only Fujiyama specified vents and vent caps when installing your Heater insert All vent pipe sections must be tight and leak proof. - Page 5 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E A- Minimum spaces for outside chimney (display by pictures); – Space to balcony and garage is minimum 600 mm. – Space to sliding window is 300 mm. –...
- Page 6 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E...
- Page 7 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E POSITION MINIMUM SPACING Directly below an openable window, air vent or any other 300 mm 12 in. ventilation opening B Below gutter, drain/ soil pipe 75 mm 3 in.
- Page 8 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E ASSEMBLY OF THE HEATER → Bring out the heater from package carefully. → Unsrcew the 2 transport screws that are on the top of the galvanized back sheet in figure 1. →...
-
Page 9: Installation Control
FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E – Bore a chimney eye to the wall that the heater is assembled appropriate tothe dimensions in figure 3. – Put the chimney equipment system assembled into the heater to the hole in the wall. –... - Page 10 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E SETTING OF THE HEATER Burning settings of the heater is done according to natural gas in factory so don't change the settings. Adjusting of your heater not include other gases which is given in user manuel, don't use your heater other gases.
- Page 11 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E CONVERSION – For our heater's operation in all gas groups, it is required that an injector with the appropriate diameter for the corresponding gas group is used. Depending on the gas type the heater will work with, the injector is selected from the table and it is attached to heater's burner.
- Page 12 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E OPERATING INSTRUCTIONS IMPORTANT SUBJECTS – Assembly, control and LPG-natural gas conversion of the heater should be done by authorized service. – You heater adjustment is given data plate. –...
- Page 13 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E OPERATING THE HEATER Press the corners to open the lid. Position of button thermostate Room temperature ºC approximately Fan Button (Only FHS 12000-FHS 9000) Thermostat Button Ignition Button For Electronic Ignition (Battery) Model Knowledge on thermostate button :...
- Page 14 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E LIGHTENING THE PILOT – Turn on the gas gate from system or gas cylinder. – Take the thermostat tuning button to firing and pilot position. – Push the button down and at the same time push the pointed lighter button ( )a few times.
-
Page 15: Cleaning And Maintenance
FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E CLEANING AND MAINTENANCE MAINTANENCE: – All maintanence should be done when the heater is extinguished and cold. – Clean the heater with a soft dry or humid cloth when it is cold. –... -
Page 16: Technical Features
Thermostat Knob ğ —1 2 3 4 5 6 7 … Carton : corrugated cardboardfor costumer Carton and Dimention FHS 5000 : 295x885x710 mm straphor Dimention FHS 4000 : 295x755x710 mm Instruction FUJIYAMA user manuel with English and Turkish manuel -15-... -
Page 17: Intended Use Of The Appliance
FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E INTENDED USE OF THE APPLIANCE Gas valve Unenviable fuel is prevent by holding the request room temperature with 7 scale thermostat. BURNER Standing of high temperatures and heating stretch ,stainless steel material. - Page 18 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E SAFETY WARNINGS AND POINTS TO BE CAREFUL BEFORE CALLING THE AUTHORISED SERVICE 1- IF THE PILOT DOESN’T Regulator of gas cylinder or Turn on the regulator or the CATCH FIRE natural gas gate can be off gate...
- Page 19 FHS 4000 E - FHS 5000 E FHS 9000 E - FHS 12000 E UYGUNLUK BEYANI DECLARATION OF CONFORMITY (Gas Appliances Directive 2016/426) UYGUNLUK DEKLARASYONU (Gaz Yakan Cihazlar Yönetmeliği 2016/426) Our Company declare that its responsibility that the item of equipment specified below has been designed, manufactured, inspected and tested as required by the relevant provisions of the Gas Appliances Directive 2016/426.
