MINIPLANE parachute rescue system.
Welcome to our team and congratulations, You have made an excellent choice!
SNIP L MINIPLANE and WAY RICHLY MINIPLANE are proportionally shaped double surface rescue chute
developed for paragliding and paramotoring.
They have extremely fast opening characteristics and a low weight, double cell design and short suspension lines.
Thanks to the very low weight WAY RICHLY MINIPLANE is designed as second spare rescue chute for acro and
cross country pilots. It has extremely fast opening characteristics. It was designed for situations involving
malfunction of reserve chute or cases when main reserve chute entangles with canopy itself.
Can also be used like main rescue parachute if the pilot / machine weight are very light.
Development was completed with successful passing of SHV flying tests and loading tests.
Before your first flight with MINIPLANE parachute rescue system as a safety system, please study this manual
thoroughly. It contains information critical to safe and easy operation of the system.
If you wish to be informed about the latest technical improvements and innovations as well as news about the
rescue system and related products visit the manufacturer EASY FLY web page
VOLO snc page :
www.miniplane.com
Manufacturer's free test durying the omologation
or
www.miniplane.it
, or your local dealer.
www.kitesurfing.cz
, the PER IL
Advertisement
Related Manuals for MINIPLANE SNIP L
Summary of Contents for MINIPLANE SNIP L
- Page 1 They have extremely fast opening characteristics and a low weight, double cell design and short suspension lines. Thanks to the very low weight WAY RICHLY MINIPLANE is designed as second spare rescue chute for acro and cross country pilots. It has extremely fast opening characteristics. It was designed for situations involving malfunction of reserve chute or cases when main reserve chute entangles with canopy itself.
- Page 2 Content: Technical specifications Technical description of reserve chute MINIPLANE parachute rescue system Applications Components Operational limits Maintenance Repairs Checks Conditions of warranty How to use it Canopy, suspension lines and bridles Outer and inner container Packing instructions Model WAY RICHLY...
- Page 3 The use of this paragliding safety system is at your own risk. Each pilot is responsible for his/ her own safety. SNIP L MINIPLANE and WAY RICHLY MINIPLANE are proportially shaped double surface rescue chute with forward speed, partially stearable.they have extremely fast opening characteristics thanks to the low weight, double cell design and short suspension lines.
- Page 4 Technical specifications SNIP L MINIPLANE and WAY RICHLY MINIPLANE comes with the front mount container. It consit in a 33cm cylinder , 13cm in diameter, with possibility to attach instruments on top of optional - a container designed as instrument panel with map holder and compact 5l ballast pocket.
- Page 5 - it is necessary to throw away the container with as much force as possible to shorten the opening time [it is mandatory to throw away the handle along with container] Important : if MINIPLANE parachute rescue system is in its original front mount container it is possible to throw it away on either side with either hand - immediately after opening of RC you have to pull the main canopy towards yourself, so the RC and main canopy won’t tangle together which could cause failure of RC...
- Page 6 aerodynamic wake. (RC’s opening in a wake can cause delayed inflating or sticking of RC to pilot’s body.). For these matters, change of inner container must be consulted with manufacturer! Outer container Outer container is designed for use with majority of modern harnesses. Reserve chute is attached to a chest strap through outer container’s plastic buckle and bridles are clipped into harness’s main hanging points - as shown on picture no.** ATTENTION!
- Page 7 3. condition of: inner container, handle, container’s elastic closing, rubber bands used for attaching lines Divide canopy gores evenly into right and left side, SNIP L MINIPLANE 9 by 9 gores, (WAY RICHLY MINIPLANE 8 by 8 gores) . Reserve canopy gores are not symmetrical and they are numbered. Always start...
- Page 8 Folding of left side starts with gore #10 (#9) and finish with gore #18 (#16) Loose the tension on bridles’ side. Separate the lines equally into right and left halves to prevent any tangles. Tension up the bridles again and check for any line crossings or entanglements.
- Page 9 Both halves fold longitudinally into thirds : make first 1/3 fold under RC and second one on the top of RC - see photo [ folding RC into thirds to make Z shape - one third on top and other on bottom - improve speed and symmetry of opening] Straighten out all wrinkles on RC (which is folded into thirds), press out air and start folding -as shown on pictures and in step 1.
- Page 10 Another fold is done around and on top of the first one - as shown in the steps 2 & 3 - and continue after that with ‘Z’ folding upwards. Insert folded canopy into inner container and fold up lines into loops and secure them with rubber bands and insert them into pocket of container until you reach approx.
- Page 11 Close container with rubber loops and secure them with approx. 3-4 cm loops made from lines. Force needed to open container (slip the loops of lines out of rubber loops) should be in range of 300-900 g. The rest of lines, approx.120 cm, fold up into ‘figure8’ loops and secure them with rubber bands on outside of the container.
- Page 12 ( Bridles’ span should be similar to width of harness chest strap plus approx. 7cm) .
- Page 13 PLEASE TAKE CARE TO THE BRIDDLE ORIENTATION as shown on the following pictures...
- Page 14 After, close container and secure it with two plastic pins. Folding of RC and closing of outer container have to be done carefully and slowly so that RC fits easily into outer container. Check the function of outer container. Attach RC to harness, and make practice toss in flying position. Force needed to pull out RC should not exceed 10 kg.
- Page 15 WARRANTY CERTIFICATE Filled out by dealer Type SNIP L MINIPLANE WAY RICHLY MINIPLANE Serial number Production date Checked by Filled by customer Date of purchase Name address - please keep the purchase receipt ( or a readable copy ) with this document -...
