Summarization of Contents
Safety Symbols and Meanings
Danger Symbol Explanation
Defines the meaning of the Danger symbol for critical hazards.
Warning Symbol Explanation
Defines the meaning of the Warning symbol for serious hazards.
Caution Symbol Explanation
Defines the meaning of the Caution symbol for minor hazards.
Notice Symbol Explanation
Defines the meaning of the Notice symbol for informational purposes.
Hazard Signal Word Symbol
Explains the symbol indicating assigned signal words like WARNING or CAUTION.
The Refrigerant
R32 Refrigerant Properties
Explains R32 refrigerant as nonpolluting, good thermodynamic features, and energy efficiency.
Refrigerant Handling Warning
Caution against unauthorized repairs, improper defrosting, and storing near ignition sources.
Operation and Maintenance Precautions
User Safety and Maintenance Guidelines
Covers safe usage by children, cleaning rules, power handling, and filter maintenance.
Operational and Repair Precautions
Professional Maintenance and Unit Operation Safety
Stresses professional repairs, safe operation, and immediate actions for abnormal conditions.
Installation Safety Precautions
Electrical Safety and Installation Requirements
Details electrical safety, grounding, power supply, and circuit breaker requirements for installation.
General Installation and Grounding Safety
Wiring, Grounding, and Component Safety
Covers installation completion, cord replacement, wiring regulations, grounding, and component connections.
Usage and Placement Safety Guidelines
Safe Placement and Relocation Procedures
Details safe placement for children/pets, wall mounting, and relocation safety.
Identification of Parts
Indoor Unit Components
Identifies key components of the indoor unit, including filters, panels, and louvers.
Outdoor Unit Components
Identifies key components of the outdoor unit, including air intake, outlet, and connections.
Display Indicators
Plasma vs. Non-Plasma Display Symbols
Explains display symbols for models with and without Plasma feature.
Remote Controller Buttons
Button Functions Explained
Details the function of each button on the remote controller for operation.
Operating Modes
Auto Mode Operation
Explains how to select and operate the Auto mode for cooling or fan-only.
Cool Mode Operation
Details Cool mode settings, delay timers, temperature range, and fan speed control.
Dry Mode Operation
Describes Dry mode operation, fixed 24°C setting, and low fan speed.
Fan Mode Operation
Explains Fan mode, compressor status, fan speed selection, and room temperature display.
Convertible Operation Modes
Details Convertible operation for energy saving in Cool mode, listing tonnage capacities.
General Features and Battery Replacement
Remote Controller General Features
Highlights features like dual display, temperature settings, fan speeds, and timer functions.
Remote Controller Battery Replacement Guide
Provides instructions on when and how to replace remote controller batteries.
Emergency Operation and Maintenance
Emergency Operation Procedure
Details how to operate the unit using the auxiliary button when the remote is unavailable.
Indoor Unit Cleaning and Maintenance
Provides safety warnings and steps for cleaning the indoor unit's surface.
Additional Filters Installation Guide
Steps for Installing Additional Filters
Step-by-step instructions for installing additional filters into the air conditioner unit.
Filter Cleaning and Maintenance
Filter Cleaning Procedure
Details the process for cleaning the air filter, including safety warnings.
Seasonal Maintenance Checks and Recovery
Pre-Season and Post-Season Checks
Outlines checks for the air conditioner before and after the usage season.
Recycling and Disposal Notice
Provides information on recycling packing materials and proper disposal of the unit.
Troubleshooting: Error Signals
Inverter Model Error Codes
Lists error codes displayed on the unit and their corresponding abnormalities or protections.
Important Note on IDU Blower Operation
Explains the IDU blower's 45-second delay after shutoff for moisture removal.
Troubleshooting: Common Issues
Troubleshooting Unit Operation Issues
Addresses common phenomena like noise, unit not running, and efficiency problems with solutions.
Troubleshooting Remote and Leakage Issues
Covers issues with wireless remote control and water leakage in indoor/outdoor units.
Troubleshooting: Airflow and Noise
Troubleshooting Airflow and Moisture Issues
Solutions for indoor unit not blowing air and moisture appearing on the air outlet vent.
Immediate Actions for Critical Issues
Details critical situations requiring immediate shutdown and professional review.
Installation Dimension Diagram
Indoor and Outdoor Unit Spacing Requirements
Illustrates the necessary clearances around the indoor and outdoor units for installation.
Safety Precautions for Installation and Relocation
Refrigerant Handling During Installation
Details safety measures for refrigerant circuit, recovery, and handling during installation.
Electrical Connections and Wire Safety
Covers safe electrical connections, use of specified wires, and avoiding extension cords.
Installation Tools and Location Selection
Required Installation Tools
Lists the necessary tools required for the installation process.
Optimal Installation Location Guidelines
Provides criteria for selecting the best location for both indoor and outdoor units.
Requirements for Electric Connection
Electrical Safety and Connection Precautions
Details safety measures for electrical connections, including regulations and precautions.
Grounding Requirements and Specifications
Explains grounding requirements, wire usage, and circuit breaker capacity for the unit.
Installation of Indoor Unit
Indoor Unit Space and Height Considerations
Covers the space needed for indoor unit installation and maintenance, and height limitations.
Indoor Unit Piping and Connections
Outlet Pipe Routing and Connection
Details how to route the outlet pipe and connect indoor unit piping with correct torque.
Indoor Unit Drain Hose and Wiring
Drain Hose Installation and Insulation
Explains how to install the drain hose and use insulating pipe to prevent condensation.
Indoor Unit Wiring and Final Assembly
Power Wiring and Terminal Connections
Details connecting power wires to the terminal block and securing them with clips.
Final Assembly and Wiring Notes
Covers closing the panel and important notes on wiring and circuit breakers.
Indoor Unit Pipe Bundling and Mounting
Bundling Pipes and Securing Drain Hose
Guides on bundling pipes, cord, and drain hose, and securing the drain hose properly.
Mounting the Indoor Unit on the Wall
Details the process of hanging the indoor unit on the wall mount and checking stability.
Installation of Outdoor Unit
Outdoor Unit Support and Drain Joint Installation
Covers fixing the support, installing the drain joint, and securing the outdoor unit.
Outdoor Unit Pipe and Electrical Connections
Connecting Outdoor Unit Pipes
Details connecting the refrigerant pipes between indoor and outdoor units with correct torque.
Outdoor Unit Electrical Wiring
Explains how to connect the power and control wires to the outdoor unit's terminal block.
Outdoor Unit Pipe Management
Pipe Bending and Routing Guidelines
Provides guidance on bending pipes, routing them along the wall, and managing the drain hose.
Vacuum Pumping and Leakage Detection
Vacuum Pumping Procedure
Details the steps for vacuum pumping the refrigerant lines using a vacuum pump and piezometer.
Leakage Detection Methods
Explains how to perform leakage detection using a detector or soap water.
Post-Installation Checks and Test Operation
Post-Installation Verification Checklist
Lists items to check after installation and potential malfunctions if not done correctly.
Test Operation Procedure
Guides on preparing for and performing the initial test operation of the unit.
DC Inverter Testing Procedures
Full Load Cooling Test
Details the procedure for performing a full load cooling test on inverter models.
Half Load Cooling Test
Details the procedure for performing a half load cooling test on inverter models.
Configuration of Connection Pipe
Connection Pipe Length and Height Limits
Specifies standard and maximum lengths and heights for connection pipes.
Refrigerant Charging Calculation
Additional Refrigerant Charging Amounts
Provides recommended additional refrigerant charging amounts based on pipe diameter and operating mode.
Safety Operation of Flammable Refrigerant
Installer Qualifications and Installation Safety
Outlines qualifications for technicians and safety notes for installation, including room area.
Maintenance Area Safety and Welding
Details safety checks for the maintenance area and procedures for welding refrigerant pipes.
Flammable Refrigerant Handling Procedures
Refrigerant Recovery and Filling
Details procedures for refrigerant recovery, filling, and safety checks for transportation and storage.
Pipe Expanding Method
Pipe Cutting and Burr Removal
Provides steps for cutting the pipe and removing burrs to prevent leaks.
Pipe Expanding and Inspection
Details the process of expanding pipe ports and inspecting for proper expansion.
IDU Wiring Diagram
Indoor Unit Wiring Diagram (Inverter Models)
Schematic diagram showing the wiring connections for the indoor unit of inverter models.
ODU Wiring Diagram
Outdoor Unit Wiring Diagram (Inverter Models)
Schematic diagram illustrating the wiring connections for the outdoor unit of inverter models.
