UNVENTED (VENT-FREE)
CATALYTIC NATURAL GAS
OWNER'S OPERATION AND INSTALLATION MANUAL
VCGF30NR
REMOTE READY
CATALYTIC
GAS FIREPLACE
SYSTEM
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result caus-
ing property damage, personal injury, or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas
supplier's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed by
a qualified installer, service agency, or the gas
supplier.
This appliance may be installed in an aftermarket*, permanently located, manufac-
tured (mobile) home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate.
This appliance is not convertible for use with other gases.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
FIREPLACE
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQQQQ
QQQQQQ
QQQQQQQQQ
QQQQQQ
QQQQQQQQQ
QQQQQQ
Save this manual for future reference.
®
Patent Pending
QQ QQ
Shown with optional
cabinet mantel,
hearth base, and trim
accessories.
WARNING: Improper installa-
tion, adjustment, alteration, ser-
vice, or maintenance can cause
injury or property damage. Re-
fer to this manual for correct
installation and operational pro-
cedures. For assistance or ad-
ditional information consult a
qualified installer, service
agency, or the gas supplier.
WARNING: This is an unvented
gas-fired heater. It uses air (oxy-
gen) from the room in which it is
installed. Provisions for adequate
combustion and ventilation air
must be provided. Refer to Air for
Combustion and Ventilation sec-
tion on page 4 of this manual.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Desa Vanguard VCGF30NR
Summary of Contents for Desa Vanguard VCGF30NR
- Page 1 UNVENTED (VENT-FREE) CATALYTIC NATURAL GAS OWNER’S OPERATION AND INSTALLATION MANUAL VCGF30NR REMOTE READY CATALYTIC GAS FIREPLACE SYSTEM WARNING: If the information in this manual is not followed exactly, a fire or explosion may result caus- ing property damage, personal injury, or loss of life.
-
Page 2: Safety Information
UNVENTED NATURAL GAS FIREPLACE SAFETY INFORMATION WARNINGS IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. Improper use of this fireplace can cause seri- ous injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning. -
Page 3: Product Identification
PRODUCT IDENTIFICATION Optional Remote Control Control Knobs Piezo Ignitor Selector Switch (Optional) Figure 1 - Log Base Assembly Top Louver Assembly Firebox Hood Firebox Support Front Window Assembly Figure 2 - Fireplace 104636 OWNER’S MANUAL One Piece Log Set Top Outer Casing Catalytic Filter... -
Page 4: Product Features
UNVENTED NATURAL GAS FIREPLACE PRODUCT FEATURES OPERATION This vent-free fireplace is clean burning. It requires no outside venting. There is no heat loss out a vent or up a chimney. Heat is generated by both realistic flames and glow- ing embers. When used without the blower, the fireplace requires no electricity making it ideal for emergency backup heat. - Page 5 AIR FOR COMBUSTION AND VENTILATION Continued DETERMINING FRESH-AIR FLOW FOR FIREPLACE LOCATION Determining if You Have a Confined or Unconfined Space Use this work sheet to determine if you have a confined or unconfined space. Space: Includes the room in which you will install fireplace plus any adjoining rooms with doorless passageways or ventilation grills between the rooms.
- Page 6 UNVENTED NATURAL GAS FIREPLACE AIR FOR COMBUSTION AND VENTILATION Continued VENTILATION AIR Ventilation Air From Inside Building This fresh air would come from an adjoining unconfined space. When ventilating to an adjoining unconfined space, you must pro- vide two permanent openings: one within 12"...
-
Page 7: Installation
INSTALLATION NOTICE: This heater is intended for use as supplemental heat. Use this heater along with your pri- mary heating system. Do not in- stall this heater as your primary heat source. If you have a central heating system, you may run system’s circulating blower while using heater. -
Page 8: Installation Clearances
UNVENTED NATURAL GAS FIREPLACE INSTALLATION Continued 8. Tighten trim hanging screws (#10-16 with .25 shoulder) into holes in cabi- nets. Place the assembled trim onto fire- place cabinet. Align hanging notches on trim with hanging screws on side of fireplace (see Figure 7). Push trim firmly into place, sliding hanging notches over hanging screws. -
Page 9: Built-In Fireplace Installation
INSTALLATION Continued 10. Carefully insert fireplace into cabinet man- tel. Be careful not to scratch or damage hearth base, cabinet mantel, or any lami- nate trim on hearth base. Remove protec- tive material from top of hearth base and from front of fireplace (if any). Note: You can secure fireplace to hearth or floor. -
Page 10: Installing Gas Piping To Fireplace Location
UNVENTED NATURAL GAS FIREPLACE INSTALLATIONS Continued MANTEL CLEARANCES FOR BUILT-IN INSTALLATION If placing mantel above built-in fireplace, you must meet minimum clearance between mantel shelf and top of fireplace opening. If your installation does not meet the below minimum clearances, you must: •... -
Page 11: Installations
INSTALLATIONS Continued CONNECTING FIREPLACE TO GAS SUPPLY Installation Items Needed • 5/16" hex socket wrench or nut-driver • Phillips screwdriver • sealant (resistant to propane/LP gas, not provided) 1. Remove front window assembly. Lo- cate two phillips-head screws at top corners of front window assembly. -
Page 12: Checking Gas Connections
UNVENTED NATURAL GAS FIREPLACE INSTALLATION Continued CHECKING GAS CONNECTIONS WARNING: Test all gas pip- ing and connections for leaks after installing or servicing. Cor- rect all leaks at once. WARNING: Never use an open flame to check for a leak. Apply a mixture of liquid soap and water to all joints. -
Page 13: Installing Logs
INSTALLATIONS Continued INSTALLING LOGS CAUTION: Do not remove the warning and instruction labels attached to the heater base as- sembly. These markings contain important warranty information. WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this heater may result in property damage or personal injury. -
Page 14: Operating Fireplace
UNVENTED NATURAL GAS FIREPLACE OPERATING FIREPLACE FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not fol- low these instructions exactly, a fire or explosion may result caus- ing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by hand. -
Page 15: To Turn Off Gas To Appliance
OPERATING FIREPLACE Continued 11. Set flame adjustment knob to any level between HI and LO. CAUTION: Do not try to adjust heating levels by using the equip- ment shutoff valve. WARNING: Make sure the selector switch is in the OFF po- sition when you are away from home for long periods of time. -
Page 16: Inspecting Burners
UNVENTED NATURAL GAS FIREPLACE OPERATING FIREPLACE Continued • In the AUTO mode, the thermostat in the hand-held remote unit con- trols the room temperature. To in- crease the room temperature, press the top arrow of the TEMP button. To lower the room temperature, press the bottom arrow of the TEMP button. -
Page 17: Troubleshooting
TROUBLESHOOTING Note: For additional help, visit DESA International’s technical service web site at www.desatech.com. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM When ignitor button is pressed, there is no spark at ODS/pilot When ignitor button is pressed, there is... - Page 18 UNVENTED NATURAL GAS FIREPLACE TROUBLESHOOTING Continued OBSERVED PROBLEM Burner does not light after ODS/pilot is lit Delayed ignition burner Burner backfiring during combustion Slight smoke or odor during initial operation Moisture/condensation noticed on windows Heater produces a whistling noise when burner is lit White powder residue forming within burner box or on adjacent walls or furniture...
- Page 19 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
-
Page 20: Specifications
• model number of your heater • the replacement part number TECHNICAL SERVICE You may have further questions about in- stallation, operation, or troubleshooting. If so, contact DESA International’s Techni- cal Service Department at 1-800-DESA LOG (1-800-337-2564). You can also visit DESA International’s technical services www.desatech.com. -
Page 21: Cleaning And Maintenance
CLEANING AND MAINTENANCE WARNING: Turn off heater and let cool before cleaning. CAUTION: You must keep control areas, burner, and circu- lating air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a quali- fied service person. - Page 22 ACCESSORIES Purchase these fireplace accessories from your local dealer. If they can not supply these accessories, call DESA International’s Sales Department at 1-800-432-2382 for information. You can also write to the ad- dress listed on the back page of this manual.
- Page 23 ACCESSORIES Continued Mantel Trim Hearth Base Trim LAMINATE TRIM FOR HEARTH OR MANTEL G3002J Series - Jade Marble Laminate Mantel Trim G3003J Series - Jade Marble Laminate Hearth Base Trim G3002S Series - Sandstone Marble Laminate Mantel Trim G3003S Series - Sandstone Marble Laminate Hearth Base Trim G3002B Series - Black Onyx...
-
Page 24: Illustrated Parts Breakdown
UNVENTED NATURAL GAS FIREPLACE ILLUSTRATED PARTS BREAKDOWN REMOTE READY CATALYTIC MODEL VCGF30NR ® 104636... -
Page 25: Parts List
PARTS LIST REMOTE READY CATALYTIC MODEL VCGF30NR 104636 This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 20 of this manual. PART NUMBER DESCRIPTION 102785-03 Log, Golden Oak... - Page 26 UNVENTED NATURAL GAS FIREPLACE ILLUSTRATED PARTS BREAKDOWN FIREPLACE VCGF30NR ® 104636...
- Page 27 PARTS LIST FIREPLACE VCGF30NR 104636 This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 20 of this manual. PART NUMBER DESCRIPTION 101357-03 Top Outer Casing 104895-01 Outer Casing...
-
Page 28: Warranty Information
VENT-FREE NATURAL GAS FIREPLACE DESA International warrants this product to be free from defects in materials and components for four (4) years from the date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions.
