Summary of Contents for Rolls PT102
- Page 1 BATTERY PT102 Phase Tester • Check the phase integrity of any micro phone or audio system. • Transmitter features a speaker and line level 1/4" output • Receiver features a microphone and line level 1/4" input. • Battery operation Rolls Corporation...
- Page 2 LIMITED WARRANTY This product is warranted to the original consumer purchaser to be free from Thank you for your purchase of the PT102 Phase Tester. The PT102 consists defects in materials and workmanship under normal installation, use and service for a of two units, a transmitter and receiver.
- Page 3 SCHEMATIC DESCRIPTION Transmitter POWER: Push switch - turns the PT102t on and off. LEVEL: Adjusts the amount of test pulse level sent out the OUTPUT jack. OUTPUT: 1/4" unbalanced jack for connection to the input of the device to be tested. PWR: LED indicating power is properly connected to the PT102t and the POWER switch is in the on position.
- Page 4 OPERATION your audio system to check the phase integrity. The PT102 will check the phase of any audio signal source. There are, You may wish to begin at either the microphone, or line input source. Then however, some considerations that must be observed. For balanced applica- check each connection before it enters the next device.
