Rolls MA251 Specifications

MSRP: $150.00 USD
5 + 5 WATT MIXER - AMPLIFIER
MADE IN USA
www.rolls.com
CLASS AMP
5 + 5 WATT MIX/AMP
LEVEL
1 CH
POWER
PHANTOM
OFF - ON
OFF - ON
PHANTOM
POWER
The new MA251 is a compact class D
stereo amplifier with a 4 CH. stereo mixer
built in. It has 5 watts per channel @ 4
Ohms. The class D low heat design gives
the MA251 the ability to be mounted in
very tight applications. It will work great in
ceilings by projectors, or anywhere small
and heat free amplification is required. The
MA251 is in an all metal chassis and
weighs 1 pound. Overall dimension are
6.75" X 3.5" X 1.5". Bottom mounts are
provided for permanent installations. The
MA251 has an included 12 VAC external
power supply. The 4 channel mixer section
consists of 2 separate RCA stereo inputs,
along with an XLR mic input and a 3.5mm
(1/8") stereo input perfect for an ipod or
laptop computer type input. Phantom
power is supplied to the XLR input by a
switch on the back of the MA251.

SPECIFICATIONS

Line Input Impedance: 10K Ohms line
600 Ohms mic
Power Output: 5 watts X 2 @ 4 Ohms.
Voltage Gain: 55 dB mic
30 dB line
Maximum Supply Voltage: 24 VDC
THD: .05% typical
Effi ciency: 85%
Bandwidth: 20Hz - 25 kHz
Size: 6.75" x 3.5" x 1.5"
Weight: 1 lb.
