GRASS VALLEY FIBER MEDIA CONVERTER DEVICES Datasheet

68 Fiber Media Converter Devices
Key Features
SD/HD/3G, AES, MADI
• Add fiber to any
module or other broadcast equipment as
needed
• Flexible choices for transmit and receive
devices
• SMPTE 292M/297M/259M/424M
compatible
• Based on mature industry-standard fiber
optic technology
• Handles pathological test patterns
• Robust housings
• Supports single-mode fiber
• BNC to/from optical LC connector
Specifications
Transmitter Media Converter Table
Data Rates from 143 Mb/s to 2.97 Gb/s
Model Numbers
Parameters
Transmit Channels
Optical Interface
Electrical Interface
Wavelength 1
Power Output at 2.97 Gb/s
Link Distance with MVMC-3G RX
Receiver @ 2.97 Gb/s
Power
NOTE 1: Assumes 0 dB additional external attenuator.
NOTE 2: The maximum distance will be reduced by 15 km if 5 dB additional external attenuator is present to mitigate risk of
0 km receiver overload.
NOTE 3: A 5 dB additional external attenuator will be required to mitigate risk of 0 km receiver overload.
Ordering Information
The media converters are offered as individual
transmit and receiver devices. These fiber optic
media converter devices require one power
supply per device. The media converter frames
support up to 18 transmit or receive media
converters and provide power for all 18 devices.
All of the media converter receivers operate over
a range of 1270 nm > 1610 nm.
Attributes
• Media converters can be attached to any
SD/HD/3G, AES, MADI
destination
• For long-distance connections which
exceed the limits of coaxial cable
• For applications where the size or weight
of cable is an issue
• To provide electrical isolation
• Supports SMPTE 310M/259M/292M/297M/
424M and DVB/ASI
• Line equalized (typical 1694A:
100m @ 2.97 Gb/s, 200m @ 1.485 Gb/s,
and 400m @ 270 Mb/s)
MVMC-3G-TX MVMC-3G-TX1550
@2.97Gb/s (75% Color Bars)
1
LC
75Ω BNC
1310 nm
Min./Max. Min./Max.
-6 dBm / -3 dBm 0 dBm / +3 dBm
(Typical: -4.5 dBm) (Typical: +1.5 dBm)
10 km
Provided by MVMC-PS-1 wall power supply (100V to 200V)
Frames for Media
Converters
VMCR3G-18-R
18-channel media converter rack mount frame
(19" 1 RU) w/power supply
Media Converters
MVMC-3G-RX
LC to BNC simplex SD/HD/3G, AES, MADI
1270 > 1610 nm optical receiver
MVMC-3G-TX
LC to BNC simplex SD/HD/3G, AES, MADI
1310 nm optical transmitter
MVMC-3G-TX1550
LC to BNC simplex SD/HD/3G, AES. MADI
1550 nm optical transmitter
Media converters are small single-channel
optical converters that attach to the BNC
input or output (depending on the model) and
module or source/
convert SD/HD/3G, AES, MADI electrical signals
to/from fiber optic signals. Media converters
support single-mode fiber connections using
robust LC connectors. Using these media
converters, ordinary modules, routers, servers,
and many other broadcast products can be
made fiber-capable.
High-definition signals often require signal
transport above the limit of conventional
cables. Optical connections go further while
providing electrical isolation. These media
converters support single-mode fiber which
carries SD/HD/3G, AES, MADI signals
substantially further than multi-mode.
Receiver Media Converter Table
Data Rates from 143Mb/s to 2.97Gb/s
Model Number
Parameter
1 Receiver Channels
LC Low Wavelength
75Ω BNC High Wavelength
1550 nm Max. Receive Signal
Level
Min. Receive Signal
Level
50 km
General Specifications
Optical connectors: LC
Fiber support: Single-mode fiber
Ordering Information
Data rate: 143 Mb/s to 2.97 Gb/s
Power Supplies
MVMC-PS-1
Media converter universal power supply
For detailed specifications, installation, and setup
instructions see:
www.grassvalley.com/docs/modular
MVMC-3G-RX
@2.97 Gb/s (75% Color Bars)
1
1260 nm
1620 nm
0 dBm
-20 dBm
