Equipment Enclosures
Installation Manual
P/N 270244
Revised 14JUL97
firealarmresources.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MFC and is the answer not in the manual?

Questions and answers

Summary of Contents for EST MFC

  • Page 1 Equipment Enclosures Installation Manual P/N 270244 Revised 14JUL97 firealarmresources.com...
  • Page 2 Edwards Systems Technology, Inc. If you distribute any information contained in this manual to unauthorized persons, you have violated all distributor agreements and we may take legal action. CREDITS This manual was designed and written by the EST Technical Services - Documentation Department, Sarasota. firealarmresources.com...
  • Page 3: Table Of Contents

    Content CAB-2, CAB-3/CAB-3F, CAB-6F Equipment Enclosures Description Application Layout and Dimensions 2 Specifications 4 CB17 / CB31 / CB45 Semi-Flush 19” Rack Enclosures Description Application Layout 6 Specifications 7 Installation MFC Enclosure Description Application Installation BC-1 Battery Cabinet 14 Description Application Specifications 14 Dimensions...
  • Page 4 Jurisdiction is mandatory. EST, Inc. shall not under any circumstances be liable for any incidental or consequential damages arising from loss of property or other damages or losses owing to the failure of EST, Inc. products beyond the cost of repair or replacement of any defective products.
  • Page 5 Document history Equipment Enclosures Installation Manual P/N 270244 Revision Status Revision Date Reason For Change September 1995 Re-write of old manual. July 1997 Major revision of layout and content. Equipment Enclosures Manual firealarmresources.com...
  • Page 6 Equipment Enclosures Manual firealarmresources.com...
  • Page 7: Cab-2, Cab-3/Cab-3F, Cab-6F Equipment Enclosures

    CAB-2, CAB-3/CAB-3F, CAB-6F Equipment Enclosures Description The CAB-2 and 3 are surface mounted enclosures. The CAB 3F and 6F are semi-flush mounted enclosures. All are for the installation of control hardware. All cabinets are UL listed, constructed of 16 gauge welded steel, and feature mounting rails with speed nuts for mounting modules.
  • Page 8: Layout And Dimensions

    Layout and Dimensions CAB-2 3/4" CONDUIT KNOCKOUTS POWER SUPPLY PS4/8B REMOVABLE BACK PANEL CONTROL MODULE CM1 (N) - CM2 (N) 6.5 AH MAX. 6.5 AH MAX. BATTERY BATTERY SIDE SIDE 12.00" [CAB-001.CDR] 4.81" 15.00" CAB-3 POWER SUPPLY PS4/8B REMOVABLE BACK PANEL CONTROL MODULE CM1 (N) - CM2 (N) AA75 SERIES...
  • Page 9 CAB-3F POWER SUPPLY PS4/8B REMOVABLE BACK PANEL CONTROL MODULE CM1(N) - CM2(N) AA75 SERIES AMPLIFIER BATTERY BATTERY SIDE SIDE 12.75" 0.75" 4.25" [CAB-003.CDR] 15.00" FLANGE CAB-6F 3/4" CONDUIT KNOCKOUTS POWER SUPPLY CONTROL MODULE PS4/8B CM2(N) REMOVABLE BACK PANEL REMOVABLE BACK PANEL CONTROL MODULE CONTROL MODULE CM1(N) - CM2(N)
  • Page 10: Specifications

    Specifications Enclosure Dimensions CAB-2 CAB-3 CAB-3F CAB-6F Finished Height 23” 29.25” 31” 31” Finished Width 15” 15” 16-15/16” 30” Finished Depth 4.81” 4.81” .75” .75” Back Box Height 23” 29.25” 29.25” 29.25” Back Box Width 15” 15” 15” 28-5/32” Back Box Depth 4.81”...
  • Page 11: Cb17 / Cb31 / Cb45 Semi-Flush 19" Rack Enclosures

    CB17 / CB31 / CB45 Semi-Flush 19” Rack Enclosures Description The CB17, 31, and 45 semi-flush mounted enclosures are functional and secure cabinets for the installation of control hardware. All cabinets are UL Listed, constructed of 16 gauge steel and feature a space frame 19" rack mount which facilitates equipment installation, wiring and servicing.
  • Page 12: Layout

    Layout CB17 17.5" VERTICAL RACK SPACE 19" RACK MOUNT MOUNTING RAILS BACKBOX NOTE: DASHED LINES INDICATE SEMIFLUSH LINES. [CAB-005.CDR] CB31 31.5" VERTICAL RACK SPACE 19" RACK MOUNT MOUNTING RAILS NOTE: DASHED LINES INDICATE SEMIFLUSH LINES. BACKBOX [CAB-006.CDR] Equipment Enclosures Manual firealarmresources.com...
  • Page 13: Specifications

    CB45 45.5" VERTICAL RACK SPACE 19" RACK MOUNT MOUNTING RAILS NOTE: DASHED LINES INDICATE SEMIFLUSH LINES. BACKBOX [CAB-007.CDR] Specifications Enclosure Dimensions CB17 CB31 CB45 Finished Height 27 7/8”, 70.8 cm 41 7/8”/ 106.4 cm 55 7/8”, 141.9 cm Finished Width 27 5/8”, 70.2 cm 27 5/8”, 70.2 cm 27 5/8”, 70.2 cm...
  • Page 14: Installation

    Backplane Module Spaces Side Wall 1/2 Module Mounting 19” Rack Space 17.5”, 44.5 cm 31.5”, 80 cm 45.5”, 115.6 cm 19” Rack Space 5.75”, 14.6 cm 5.75”, 14.6 cm 5.75”, 14.6 cm Installation The following table lists the equipment which may be installed in the CB17, 31, and 45 style enclosures.
  • Page 15 RZB 12-6 w/RZMP 2.5” 5.25” 2.25” UIO-12 / MFC 1.625” CB17 Installation 24.19" Note: Backbox rough-in depth = 5-7/8" 21.19" 3/4" CONDUIT 1 1/2" KNOCKOUTS 6.81" 8.00" TOP AND BOTTOM VIEW 27.62" 3.60" 17.00" 1.25" 2.00" 3/4" CONDUIT KNOCKOUTS CABINET MOUNTING HOLES 9.00"...
  • Page 16 CB31 Installation 24.19" Note: Backbox rough-in depth = 5-7/8" 21.19" 2.00" 3/4" CONDUIT 1 1/2" KNOCKOUTS 6.81" 8.00" TOP AND BOTTOM VIEW 27.62" 3.60" 17.00" 1.25" 3.00" 3/4" CONDUIT KNOCKOUTS CABINET MOUNTING HOLES 12.50" 34.50" 34.50" 30.50" SIDE VIEW INSIDE W/O DOOR 12.50"...
  • Page 17 CB45 Installation 24.19" Note: Backbox rough-in depth = 5-7/8" 21.19" 2.00" 3/4" CONDUIT 1 1/2" KNOCKOUTS 6.81" 8.00" TOP AND BOTTOM VIEW 27.62" 3.60" 17.00" 1.25" 3.00" 3/4" CONDUIT KNOCKOUTS CABINET MOUNTING HOLES 48.50" 48.50" 44.50" 19.50" INSIDE W/O DOOR SIDE VIEW 19.50"...
  • Page 18: Mfc Enclosure

    MFC Enclosure Description The MFC enclosure is a surface mounted cabinet designed for remote mounting of a single module. The MFC is equipped with a quick release cover with captive mounting screws. RZB module mounting studs and conduit knock-outs are provided for easy installation. The cabinet is manufactured from 16 gauge steel, and is painted red.
  • Page 19 RZB/ INSTALLATION RZB P.C. BOARD SLOTTED PAN HEAD SCREW #6-32X3/8 LOCK WASHER #6 MFC ENCLOSURE #240143 QUICK OPENING SCREW #362219 CONDUIT KNOCKOUT TAMPER SWITCH MOUNTING SCREWS [CAB-012.CDR] RZB / MFC Installation NOTE: EXTRUDED PRESS NUTS FACE REAR RZB/RZMP INSTALLATION RZB P.C. BOARD MOUNTING PLATE SLOTTED PAN HEAD SCREW #6-32X3/8 LOCK WASHER #6...
  • Page 20: Bc-1 Battery Cabinet

    BC-1 Battery Cabinet Description The BC-1 battery cabinet is a surface mounted secure enclosure for the installation backup batteries. The cabinet is constructed of 16 gauge steel and features a locking door. A terminal strip and in-line fuse is mounted within the cabinet to facilitate battery wiring. The cabinet has an off-white finish.
  • Page 21: Dimensions

    Dimensions 18.25" 15.75" 1.25" 3/4" CONDUIT 7.25" KNOCKOUTS TOP VIEW 7.25" 16.00" TERMINAL BLOCK 3/4" CONDUIT AND FUSE KNOCKOUTS SIDE VIEW Equipment Enclosures Manual firealarmresources.com...
  • Page 22: Rku-Series 19 Inch Equipment Racks

    RKU-Series 19 Inch Equipment Racks Applicable Racks • RKU-36 (P/N 375004) • RKU-36B (P/N 375004B) • RKU-42 (P/N 375001) • RKU-42B (P/N 375001B) • RKU-61 (P/N 375002) • RKU-61B (P/N 3750002B) • RKU-70 (P/N 375003) • RKU-70-B (P/N 375003B) • RKU-77 (P/N 375005) •...
  • Page 23: Specifications

    Specifications Model P/N * Width Height Depth Rack Space Shipping Weight RKU-36 22.31 in 41.06 in 18.50 in 36.75 in 81 lbs P/N 375004 (56.7 cm) (104.3 cm) (47.0 cm) (93.3 cm) (36.7 kg) RKU-36B 22.31 in 41.06 in 18.50 in 36.75 in 81 lbs P/N 375004B...
  • Page 24 Equipment Enclosures Manual firealarmresources.com...
