GOVI arktik 2000N Operation Manual
  1. Manuals
  2. Brands
  3. GOVI Manuals
  4. Refrigerator
  5. arktik 2000N
  6. Operation manual

GOVI arktik 2000N Operation Manual

Trailer refrigeration unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

| EN | OPERATION MANUAL
DE BETRIEBSANLEITUNG
1600N - 1600 N/T - 2000N - 2500N - 2000P - 2500 N/K - 2000 P/K
Trailer Refrigeration Unit
The cooling diamond

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the arktik 2000N and is the answer not in the manual?

Questions and answers

Related Manuals for GOVI arktik 2000N

Summary of Contents for GOVI arktik 2000N

  • Page 1 | EN | OPERATION MANUAL DE BETRIEBSANLEITUNG 1600N - 1600 N/T - 2000N - 2500N - 2000P - 2500 N/K - 2000 P/K Trailer Refrigeration Unit The cooling diamond...
  • Page 2 After reading the operating manual, keep it in a safe place for future reference. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 3: Table Of Contents

    Safety data sheets 13.4 Installation checklist Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 4: General

    If appropriate, consult professionals or specialists. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 5: Safety Instructions

    Provides useful information and helpful tips. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 6: Safety And Hazard Precautions

    Fire and explosion hazard from flammable operating materials! Avoid open fire, electrical sparks and ignition sources. Do not smoke! Observe measures for fire and explosion protection. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 7 Keep your hands away from rotating fan blades. Accidental contact with fan bladesʼ sharp edges can cause severe personal injury. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 8: Safety Precautions Concerning The Refrigerant

    Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 9: Intended Use

    10 Maintenance. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 10: Technical Data

    Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 11 2500N/K 2000P 2000P/K • • • Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 12 We recommend an insulation with a k value of 0.2 W/m²K Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 13: Package, Transportation And Storage

    4. Check the contents of the box for completeness. 5. Look for loose parts that may be integral part of the delivery, before disposing of the package. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 14: Transport

    • Direct sunlight at the storage location must be avoided. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 15: System Description

    Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 16 They must not be covered or obstructed. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 17: Installation

    15-mm diameter and suitable length. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 18: Preparatory Activities

    6. Verify that the PU seal (1) at the backside of the trailer refrigeration unit is available and intact. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 19: Installation Opening Of Trailer Wall

    2. Carrying rope 3. Spring hook Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 20 Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 21 PU seal (2) does not get damaged. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 22: Installation Of Accessories

    The connected cable for the interior lighting is located on the evaporator side panel. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 23: Operating Elements

    3. Lamp switch The lamp switch (3) enables to switch on and off the light inside the refrigeration unit. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 24: Commissioning

    3. Use the spanner (4) to unlock the latch (5) and open the protection cover. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 25 Bestätigen Sie den Sollwert mit der SET-Taste. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 27: Switching On/Off The Trailer Refrigeration Unit

    50.04.504 / 1.0 gedrückt. Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments. Ein/Ausschalten der Lampe: Drücken Sie kurz die LICHT-Taste.

  • Page 28: Maintenance

    4. Connect again the trailer refrigeration unit to the power supply by inserting the main plug. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 29: Cleaning Parts Outside The Refrigeration Unit

    5. Connect again the trailer refrigeration unit to the power supply by inserting the main plug. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 30: Troubleshooting

    4. Check the power supply to the lights. 5.Call for GOVI service. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 31: Summary

    Tab. 3. 1. Technical data Tab. 11. 1. Troubleshooting Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 32: Appendices

    SET button. mit der SET-Taste. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 33: Wiring Diagrams

    Drain pipe heater Overheatprotector IC974LX Temperature controller Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 34 The wiring diagram is placed inside the main cover of the trailer refrigeration unit. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 35 The wiring diagram is placed inside the main cover of the trailer refrigeration unit. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 36 The wiring diagram is placed inside the main cover of the trailer refrigeration unit. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 37 The wiring diagram is placed inside the main cover of the trailer refrigeration unit. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 38 The wiring diagram is placed inside the main cover of the trailer refrigeration unit. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 39 The wiring diagram is placed inside the main cover of the trailer refrigeration unit. Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 40: Safety Data Sheets

    Seite 3 von 12 Seite 4 von 12 Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 41 Seite 7 von 12 Seite 8 von 12 Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 42 Seite 11 von 12 Seite 12 von 12 Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 43 Seite 3 von 13 Seite 4 von 13 Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 44 Seite 7 von 13 Seite 8 von 13 Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 45 Seite 11 von 13 Seite 12 von 13 Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
  • Page 46 Prod-ID 758265 Seite 13 von 13 Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.

  • Page 47: Installation Checklist

    • The device works perfectly. • Checked by: • Date: Page 50.04.504 / 1.0 Copyright by GOVI GmbH 2021. The reproduction of this document or any part thereof is prohibited. We reserve the right to make technical changes during the course of further developments.
