OPERATORS' MANUAL
Grinding Helmet and
PAPR System
Part No. 5044
IMPORTANT NOTICE
Please read these instructions carefully before using this unit
Failure to comply with the instructions may void your warranty and adversely affect your
health and safety

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5044 and is the answer not in the manual?

Questions and answers

Related Manuals for SWP 5044

Summary of Contents for SWP 5044

  • Page 1 OPERATORS’ MANUAL Grinding Helmet and PAPR System Part No. 5044 IMPORTANT NOTICE Please read these instructions carefully before using this unit Failure to comply with the instructions may void your warranty and adversely affect your health and safety...
  • Page 3 STEALTH-G GRINDING HELMET & PAPR SYSTEM 1. INTRODUCTION The Stealth-G is designed to provide protection when the wearer is working in a contaminated environment. The system is designed to supply clean air via the blower filter through a breathing tube to the welding faceshield, so that the user can continue working. It is a combined face and powered air purifying respirator (PAPR) system for increased safety and comfort during welding.

  • Page 4: Warnings And Limitations Of Use

    STEALTH-G GRINDING HELMET & PAPR SYSTEM WARNINGS AND LIMITATIONS OF USE Before each use, inspect the Stealth-G for damage and check it is fully operational and test the air flow to verify it is providing an adequate volume of air.
  • Page 5 STEALTH-G GRINDING HELMET & PAPR SYSTEM 4. UNPACKING/ASSEMBLY Check that correct number of components has been supplied as in FIGURE 1. Check that the apparatus is complete, undamaged and correctly assembled. Any damaged or defective parts must be replaced before use.

  • Page 6: Filter Replacement

    STEALTH-G GRINDING HELMET & PAPR SYSTEM 4.1 Filter replacement 4.1.1 Remove the filter cover by pressing 4.1.2 The filter cover is released. in the latch of the filter cover. 4.1.3 Remove the used filter by lifting it out from the filter cover.
  • Page 7 STEALTH-G GRINDING HELMET & PAPR SYSTEM 4.2 Installing the Battery/Charging 4.2.1 Slide the battery towards the back 4.2.2 Make sure the battery is locked in of the filtration unit. position. 4.2.3 The battery can be charged on the filtration unit or separately.
  • Page 8 STEALTH-G GRINDING HELMET & PAPR SYSTEM Battery charge: Connect the battery to the charger. The connector is above the battery. Connect the charger to the mains. The state of charge is displayed via a red LED on the mains charger.
  • Page 9 STEALTH-G GRINDING HELMET & PAPR SYSTEM 4.3.7 Put the buckle back. 4.3.8 Attach the harness to the belt’s 4 Make sure the belt is securely fastened. plastic rings. 4.4 Connecting the tube 4.4.1 Connect the air tube to the 4.4.2 Connect the other end of the tube respiratory system and twist it to the headgear in the same way.

  • Page 10: Air Flow Test

    STEALTH-G GRINDING HELMET & PAPR SYSTEM 5. BEFORE USE/ FITTING 5.1 Air flow test 5.1.2 Insert the flowmeter at the tip of 5.1.1 Connect the breathing tube to the the tube turbo unit and twist it clockwise to lock it.

  • Page 11: Lcd Display Screen

    STEALTH-G GRINDING HELMET & PAPR SYSTEM 5.3 Fitting 5.3.2 Adjust the headgear to suitable tightness (push and turn left to loosen, turn right to tighten) Make sure the face seal is positioned properly, otherwise you cannot 5.3.1 Adjust the tightness of the face achieve sufficient sealing needed to seal and put on the head top.

  • Page 12: Operation

    STEALTH-G GRINDING HELMET & PAPR SYSTEM 6.2 Operation Switch the device on by pressing the ON button once. Press the ON button once again, the air flow is at level 1 (~170L/min). Press the ON button once again, the air flow is at level 2 (~200L/min).

  • Page 13: Parts List

    STEALTH-G GRINDING HELMET & PAPR SYSTEM 7. PARTS LIST Figure Part No. Description 5044HEAD Headtop only including face seal 6044SEAL Face Seal 3044BAND Airduct with Headgear 5024 Outer Protection Lens – Clear 5023 Outer Protection Lens – Shade 3 5024SEAL...
  • Page 14 STEALTH-G GRINDING HELMET & PAPR SYSTEM...

  • Page 15: Maintenance And Storage

    STEALTH-G GRINDING HELMET & PAPR SYSTEM 8. MAINTENANCE & STORAGE Inspect the equipment daily and regularly check for any sign of malfunction. 8.1 Maintenance The blower unit must be checked regularly and must be changed if it is damaged. Filters must be changed if damaged, or blocked and does provide sufficient airflow.

  • Page 16: Toubleshooting

    STEALTH-G GRINDING HELMET & PAPR SYSTEM 9. TOUBLESHOOTING Problem Possible cause Action Fault code «E01» 1. Motor is stuck Check and remove physical 2. Motor is damaged failure and restart the system. 3. Blower structure failure Return to supplier if LCD still...

  • Page 17: Specification

    STEALTH-G GRINDING HELMET & PAPR SYSTEM 10. SPECIFICATION Size (Blower Assembly) 9-2/5 x 6-1/2 x 2-3/4 in. (240 x 165 x 70 mm) Weight 2.4kg Particle Filter 1*TH3 P R SL Air Flow Manufacturer minimum design flow rate: 165L/min Nominal airflow :...
  • Page 18 Warning indication This Stealth-G PAPR has sound and vibration alarm function. Each square equals a period of 100ms. Grey is a beep sound and a blank square is a quiet period.

  • Page 19: Warranty

    STEALTH-G GRINDING HELMET & PAPR SYSTEM 12. WARRANTY The Stealth-G Air Blower unit is guaranteed for a period of 12 months from date of purchase against mechanical or electrical defects. The Stealth-G battery is guaranteed for a period of 6 months from the date of purchase.
  • Page 20 Head Office Unit 1, Farringdon Industrial Centre Farringdon, Nr Alton Hampshire GU34 3DD, UK National Distribution Centre Unit 1, Withins Road Haydock Industrial Estate Haydock WA11 9UD, UK Customer Service T +44 (0)1420 588180 F +44 (0)1420 588184 E sales@swp.uk.net www.specialisedwelding.co.uk...
