- Page 1 V1 & V2 PROJECTOR Installation Guide Halogen Kits HID Kits www.dapperlighting.com (833)-DAPPER-1 / (833)-327-7371 support@dapperlighting.com...
-
Page 2: Table Of Contents
Table of Contents Halogen Kit Install Guide.................... Page 4 Halogen Kit Install Guide: What You’ll Need......................Page 5 Testing Your Headlights…..................Page 12 HID Kit Install Guide…....................Page 14 HID Kit Install Guide: What You’ll Need…..................... Page 15 Testing Your Headlights…..................Page 27 Headlight Aiming Instructions…................ - Page 3 DAPPER LLC WARRANTS TO ITS CUSTOMERS THAT THE COMPANY'S DAPPER LIGHTING BRANDED PRODUCTS ARE FREE FROM DEFECTS IN WORKMANSHIP AND MATERIALS. Dapper LLC will repair or replace its Dapper Lighting branded products which fail to give satisfactory performance due to defective workmanship or materials, based upon the terms and conditions of the following described warranty plans attributed to that specific product.
-
Page 4: Halogen Kit Install Guide
Dapper Lighting today at (833)-DAPPER-1 / (833)-327-7371 support@dapperlighting.com Warning: This guide is for the Dapper Lighting HALOGEN kit install only. If you purchased a Dapper Lighting Projector kit WITH an HID kit, please see STOP! our HID kit install guide on page 14. -
Page 5: Halogen Kit Install Guide
Halogen Kit Install Guide Let’s get started. To begin, make sure you have all necessary Dapper Lighting components as well as a few common tools. Below is a list of what is required: Parts Diagram Tools Diagram 1. Dapper Lighting Projector Headlight x2 1. - Page 6 Halogen Kit Install Guide Currently Installed Headlight Locate mounting screws and/or bracket on your currently installed headlights. Dismounting Headlights Dismount your headlight by loosening the screws. www.dapperlighting.com (833)-DAPPER-1 / (833)-327-7371 support@dapperlighting.com...
- Page 7 Halogen Kit Install Guide Removing Headlight Carefully pull your headlight from its fixed position. Try not to lose any loosened screws! Removing Mounting Brackets You will most likely be reusing the stock headlight mounting brackets, so be careful when removing them.
- Page 8 Headlights by lining up the three tabs with the TOP side of the housing on top. Figure 7 Installing Halogen Bulbs Take your Dapper Lighting halogen bulbs (Part #4) and clip them into your Dapper Lighting projector housing securely. www.dapperlighting.com (833)-DAPPER-1 / (833)-327-7371 support@dapperlighting.com...
- Page 9 Test fit Dapper Headlights Once your HID bulbs are secured inside your Dapper Lighting projector and your extra spade adapters are removed, TEST FIT your headlights to make sure they fit snug just like your OEM headlights.
- Page 10 Halogen Kit Install Guide Securing Dapper Headlights Now that the Dapper Lighting headlights fit correctly, you will need to refasten them. Using the same mounting hardware associated with your OEM headlights, tighten your headlights into place and prepare to start the wiring.
- Page 11 Halogen Kit Install Guide PCU HARNESS Note: For use with Harness Part Number: Your Sevens feature our Power Control H4H1ADS Unit (PCU) which is an automated headlight control system module and no longer needs a diode. Please follow the guides accordingly and contact us if you have any questions.
-
Page 12: Testing Your Headlights
NOT working, double check that you have good connections and correct polarity on all parts of the harness. If you are still having issues, please contact a Dapper Lighting Technician before moving forward. Test High Beams Turn on your high beams and check for a change in output pattern. - Page 13 Dapper Lighting Technician. City Lights/Running Lights/Halo and Angel Eyes(Optional) Most Dapper Lighting Headlights come with either a built in city/running lights below the projector or a built in halo/angel eye around the projector. These do NOT come pre-wired and are open for different uses.
-
Page 14: Hid Kit Install Guide
Universal Projector HID Kit Install Guide Thank you for choosing Dapper Lighting for your projector headlight upgrade! The following is an install guide for our universal projector headlight systems, both 7" round and 7x6" square. If you have any suggestions on how to improve the simplicity of our guide, or if you need more... -
Page 15: Hid Kit Install Guide
Halogen Kit Install Guide Let’s get started. To begin, make sure you have all necessary Dapper Lighting components as well as a few common tools. Below is a list of what is required: Parts Diagram HID Kit Relay Kit 1. Dapper Lighting Projector 6. - Page 16 HID Kit Install Guide Tools Diagram This figure shows common tools which may be used for installation. The recommended tools include: 1. Socket Wrench 2. Phillips Screwdriver 3. Wire Cutters 4. Zip Ties Once you’ve located all necessary components and tools for this install, we can begin! For your safety, please disconnect your battery and prepare to remove your headlights.
- Page 17 HID Kit Install Guide Currently Installed Headlight Locate mounting screws and/or bracket on your currently installed headlights. Dismounting Headlights Dismount your headlight by loosening the screws. www.dapperlighting.com (833)-DAPPER-1 / (833)-327-7371 support@dapperlighting.com...
- Page 18 HID Kit Install Guide Removing Headlight Carefully pull your headlight from its fixed position. Try not to lose any loosened screws! Removing Mounting Brackets You will most likely be reusing the stock headlight mounting brackets, so be careful when removing them.
- Page 19 HID Kit Install Guide Reinstalling Mounting Brackets Once your old headlights are out of your mounting brackets, secure your Dapper Headlights by lining up the three tabs with the TOP side of the housing on top. Installing your HID bulbs Unscrew the clear plastic protective case to free your HID bulb and place it inside your new Dapper Lighting projector.
- Page 20 HID Kit Install Guide Properly Seating and Securing Bulbs Once you have installed the bulb, pull the clips across the bulb and secure them onto the locking tabs. Remove Spade Adapters After installing your HID bulbs into your new Dapper Lighting projector housings, completely remove this extra spade adapter from both sides.
- Page 21 OEM headlights. There should be no excessive play or protrusion. Securing Dapper Headlights Now that the Dapper Lighting headlights fit correctly, you will need to refasten them. Using the same mounting hardware associated with your OEM headlights, tighten your headlights into place and prepare to start the wiring.
- Page 22 HID Kit Install Guide Wiring Power Locate your positive (red) terminal on your battery. On your Dapper Lighting Relay Harness (Part #9), locate the two fused (red) terminals. Using a Socket Wrench (Tool #1), connect positive wires to the positive terminal on your battery and secure tightly.
- Page 23 HID Kit Install Guide Merging your H4-H1 Adapter and Dapper Lighting Relay Harness Locate the black relay and connect with white 4-slot connector. Repeat on other side. www.dapperlighting.com (833)-DAPPER-1 / (833)-327-7371 support@dapperlighting.com...
- Page 24 HID Kit Install Guide Wiring Diagram POWER FROM BATTERY ( POWER (Green) GROUND (Black POWER TO HID BALLAST (White) RELAY BATTERY Locate the black and green wires from the H4-H1 Adapter. Plug the green wire’s spade terminal into Power (green) located on the relay connector (Part #8). Plug the black wire’s spade terminal into Ground (black, below power) located on the relay connector.
- Page 25 HID Kit Install Guide Hooking Up Ballasts Locate the HID ballast (Part #6) and the blue plug located on the Dapper Lighting Relay Harness (Part #9). There are two notches located at the base of the ballast socket. One is square shaped and the other is triangle shaped.
- Page 26 HID Kit Install Guide PCU HARNESS For use with Harness Part Number: Note: H4H1ADS Your Sevens feature our Power Control Unit (PCU) which is an automated headlight control system module and no longer needs a diode. Please follow the guides accordingly and contact us if you have any questions.
-
Page 27: Testing Your Headlights
NOT working, double check that you have good connections and correct polarity on all parts of the harness. If you are still having issues, please contact a Dapper Lighting Technician. Test High Beams Turn on your high beams and check for a change in output pattern. - Page 28 If you are still having issues, please contact a Dapper Lighting Technician before moving on. Mounting Ballasts and Wiring Now that you have your Dapper Lighting Universal Projector HID Kit configured correctly and have tested to make sure your low and high beams work, it’s time to secure wiring and ballasts.
- Page 29 HID Kit Install Guide City Lights/Running Lights/ Halo and Angel Eyes Most Dapper Lighting Headlights come with either a built in city/running lights below the projector or a built in halo/angel eye around the projector. These do NOT come pre-wired and are open for different uses.
-
Page 30: Headlight Aiming Instructions
HEADLIGHT AIMING Instructions HEADLIGHT AIMING INSTRUCTIONS The bright light produced by projector headlights can create a dangerous situation if the headlights are not properly aimed. When projector headlights are aimed too high, they can blind oncoming traffic. If they are aimed too low, road visibility is impaired. - Page 31 HEADLIGHT AIMING Instructions STEP 3: These vertical lines need to intersect the slant on Locate the adjusting screws of the the cutoff in order for you’re lights to be headlights on the back of the This is where your centered from left to right. headlights shine when housing assembly.
- Page 32 HEADLIGHT AIMING Instructions STEP 5: Mark two more spots 2" below the spots you first marked. STEP 6: Back up the vehicle 20 feet so that it is 25 feet away from the vertical surface. Check to see if the cuto! point is directly in between the two marks you have made.
-
Page 33: Troubleshooting & Faqs
Older vehicles have more delicate headlight harnesses and may not be supplying the correct voltage or output designed from the factory. Verify that your vehicle is putting out at least 12V to the headlight plugs. Contact a Dapper Lighting Technician if you are still having wiring issues. - Page 34 The blue high/low wires from the headlight aren’t long enough. Should I lengthen them? Some vehicles may need a high/low extension depending on where the harness is installed (Dapper Lighting SKU #HLEXT). It is recommended to use Dapper Lighting wiring to ensure proper function.
