Rear View

2
1
110 PUNCH-DOWN BLOCK – For CAT-5
1
intercom cable connection
POTENTIOMETER – Sets speaker volume
2
CAMERA – Angle adjusts to accommodate
3
placement to the left or right of door
BR BR/W G G/W O O/W BL BL/W
MULTIPIN CONNECTOR – Accepts camera
4
power and video adapter cable (included)
DOORBELL TERMINALS – Screw terminals
5
for external doorbell connection
6 GASKET – Seals out moisture and dust
3
4
5
6
5
