Chassis name
TPM18.6E LA
Published by Liqin.hu /SC 1833 Quality
2018
TP Vision Netherlands B.V.
©
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Platform
MTK5802
Model name
43PUS6503/60
43PUS6503/12
43PUS6503/62
43PUS6523/12
43PUS6703/12
43PUS6753/12
49PUS6803/12
50PUS6203/12
50PUS6503/12
50PUS6503/60
50PUS6503/62
50PUS6523/12
50PUS6703/12
50PUS6753/12
Subject to modification
TPM18.6E
LA
Model name
55PUS6503/12
55PUS6503/60
55PUS6523/12
55PUS6703/12
55PUS6753/12
55PUS6803/12
58PUS6203/12
65PUS6503/12
65PUS6523/12
65PUS6703/12
65PUS6753/12
3122 785 20682
2018-Aug-24
Advertisement
Table of Contents
Related Manuals for Philips 50PUS6703/12 50PUS6753/12
Summarization of Contents
1. Product Information
Display & Input Specifications
Covers screen sizes, resolutions, and supported video inputs.
HDMI & Connectivity Features
Details HDMI, UHD settings, and various connection ports.
Sound & Multimedia Capabilities
Lists audio features and media playback support.
Power & General Specifications
Information on power requirements and general product details.
2. Safety Precautions and Service Notes
Safety Instructions and Warnings
Critical safety guidelines for repair and handling.
General Service Notes & Schematic Conventions
Measurement practices and schematic symbol explanations.
Abbreviation Glossary
Definitions of technical terms used in the manual.
3. Mechanical and Assembly Instructions
Cable Dressing Guidelines
Illustrates cable routing for different TV series.
Disassembly and Panel Removal Procedures
Step-by-step guide for taking the TV apart.
4. Service Modes and Diagnostics
Service Alignment Mode (SAM) Usage
Guide to SAM for TV alignments and adjustments.
Factory and Customer Service Modes (CSM)
Accessing and using Factory and CSM for diagnosis.
5. Software Upgrading, Error Codes, and Panel Codes
Software Upgrading Procedures
Steps for updating TV firmware via USB.
Error Code Interpretation and Buffer Reading
How to read and reset error codes.
Set Option Code Configuration
Setting the option code for the panel type.
6. Trouble Shooting Guide
Picture and Signal Issue Diagnosis
Flowcharts for troubleshooting picture problems.
Audio and System Issue Diagnosis
Flowcharts for sound and general system issues.
7. Electrical Diagrams and Schematics
Block Diagram and Power Tree
High-level overview of system components and power.
SSB Power Layout Details
Specifics on power distribution on the SSB.
8. IC Data Sheets
MT5802VHEJ (Scaler) IC Details
Datasheet for the main scaler chip.
AD82588B-LG48NAY (Audio) IC Details
Datasheet for the audio chip.
Tuner IC Datasheets
Details for tuner ICs like ST42WS-17-E and TDQS-A701F.
9. Circuit Diagrams
Power Supply (PSU) Schematics
Detailed circuit diagrams for various power supplies.
Interface and Component Schematics
Schematics for Ambilight, Audio, Tuner, CI, WiFi, GPIO, DRAM, and interfaces.
10. Styling Sheets (Parts Identification)
Styling Sheets for 43" Series
Visual guide to components for 43" models.
Styling Sheets for 50/55" and 49/55" Series
Visual guide for 50/55" and 49/55" models.
Styling Sheets for 50/58" Series
Visual guide for 50/58" models.
Styling Sheets for 65" Series
Visual guide for 65" models.
