Specifications
Power Source
Power Consumption
Average use
Standby condition
Display panel
Aspect Ratio
Visible screen size
Number of pixels
Sound
Speaker
Audio Output
Headphones
PC signals
Receiving Systems/Band name
AC 220-240 V, 50 / 60 Hz
341 W
0.7 W
16 : 9
106 cm (diagonal)
922 mm (W) × 518 mm (H)
786,432 (1,024 (W) × 768 (H)) [3,072 × 768 dots]
120 mm × 60 mm × 2 pcs, 8 ohm
20 W [10 W + 10 W] (10 % THD)
M3 (3.5 mm) stereo mini Jack × 1
VGA, SVGA, XGA
SXGA ...... (compressed)
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
TH-42PV70AZ
TH-42PV70H
TH-42PV70M
TH-42PV70MR
TH-42PV70MT
GPH10DA Chassis
© 2007 Matsushita Electric Industrial Co., Ltd. All
rights
reserved.
distribution is a violation of law.
ORDER NO.MD0704001CE
Plasma Television
Unauthorized
copying
and
Advertisement
Table of Contents
Related Manuals for Panasonic TH-42PV70H
Summarization of Contents
Safety Precautions
General Guidelines
Provides general instructions for conducting repairs and servicing.
Touch-Current Check
Details the procedure for measuring touch currents to ensure safety.
Plasma Panel Replacement Method
Remove the Rear Cover
Step-by-step guide for removing the rear cover of the plasma panel.
Remove the P-Board
Procedure for removing the P-Board, including caution for capacitor discharge.
Remove the PA-Board
Steps to remove the PA-Board, including connector disconnection.
Remove the Tuner Unit
Guide for removing the tuner unit from the chassis.
Plasma Panel Replacement Method
Remove the DG-Board
Detailed steps for removing the DG-Board.
Remove the H-Board
Instructions for removing the H-Board.
Remove the D-Board
Procedure for removing the D-Board, including flexible cable disconnection.
Plasma Panel Replacement Method
Remove the SD-Board
Guide for removing the SD-Board.
Remove the SC-Board
Steps for removing the SC-Board.
Remove the SS-Board
Instructions for removing the SS-Board.
Plasma Panel Replacement Method
Remove the C1-Board
Steps to remove the C1-Board.
Remove the C2-Board
Instructions for removing the C2-Board.
Remove the Front Bracket
Procedure for removing the front bracket.
Remove the G-Board
Steps to remove the G-Board.
Plasma Panel Replacement Method
Remove the S-Board
Steps to remove the S-Board.
Remove the Plasma Panel Section
Procedure for removing the plasma panel assembly from the cabinet.
Plasma Panel Replacement Method
Replace the Plasma Panel (Finished)
Final steps for installing the plasma panel and connecting boards.
Caution Statement
Caution Statement
Important safety notice regarding cable assembly and locking.
Location of Lead Wiring
Lead of Wiring (1)
Diagram showing dressing of wires for internal connections.
Self-check Function
Check of the IIC Bus Lines
How to access the self-check function to diagnose IIC bus line issues.
Power LED Blinking Timing
Information on interpreting power LED blinking for fault diagnosis.
Service Mode
How to Enter Service Mode
Instructions for accessing the service mode using remote control commands.
Service Tool Mode
Display of SOS History
How to access and interpret the SOS history.
Adjustment Procedure
Driver Set-up
Preparation and item setup for adjusting driver sections.
Adjustments
Voltage checks and adjustments for driver section voltages.
Adjustment
Sub-Contrast Adjustment
Procedure for adjusting sub-contrast for AV, RF, and HD signals.
Conductor Views
P-Board
Detailed view of the P-Board conductor layout.
Schematic and Block Diagram
Schematic Diagram Note
Notes and symbols used in schematic diagrams for clarity and safety.
Exploded Views & Replacement Parts List
Exploded Views
Visual breakdown of the TV components and their assembly.
