Chassis name
TPM19.1A LA
Published by Doris.zheng /SC 2048 Quality
2019
TP Vision Netherlands B.V.
©
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Platform
MTK5599
Subject to modification
Model name
55PUT7374/98
55PUT7374/56
55PUT7374/67
55PUT7374/79
55PUT7374/75
55PUH7374/96
55PUT7374/68
65PUT7374/98
65PUT7374/56
65PUT7374/67
65PUT7374/79
65PUT7374/75
65PUH7374/96
65PUT7374/68
70PUT7374/98
70PUT7374/56
75PUT7354/56
TPM19.1A
LA
Model name
70PUT7374/67
70PUT7374/79
70PUT7374/75
70PUH7374/96
55OLED804/98
55OLED804/56
55OLED804/67
55OLED804/75
55OLED804/79
55OLED804/71
65OLED804/98
65OLED804/56
65OLED804/67
65OLED804/75
65OLED804/79
65OLED804/71
3122 785 20991
2020-Oct-20
Advertisement
Table of Contents
Related Manuals for Philips 55PUT7374/79
Summarization of Contents
Precautions, Notes, and Abbreviation List
Safety Instructions
Safety regulations for connecting set to mains and replacing components.
Warnings
Susceptibility of ICs to ESD, handling precautions, and high voltage warnings.
Notes
General information about measurements, schematics, and spare parts.
Abbreviation List
List of technical abbreviations used in the manual.
Mechanical Instructions
Cable Dressing
Instructions for routing and securing cables within the TV chassis for various models.
Assembly/Panel Removal
Steps for disassembling the TV, including stand and rear cover removal.
Rear Cover
Procedure for removing the TV's rear cover, including screw and connector details.
IR Board Control Unit
Procedure for removing the IR board control unit.
Small Signal Board (SSB)
Procedure for removing the Small Signal Board (SSB).
Power Supply Unit (PSU)
Procedure for removing the Power Supply Unit (PSU).
Speakers
Procedure for removing the speakers from the TV.
WIFI module
Procedure for removing the WIFI module.
LCD Panel
Steps for removing the LCD panel from the TV bezel.
Service Modes
Service Alignment Mode (SAM)
Mode for TV alignment, calibration, and information display.
Factory mode
Mode for extended alignments, software settings, and test pattern display.
Customer Service Mode (CSM)
Read-only mode for displaying error codes and TV information for service calls.
Software Upgrading, Error code and Panel Code
Software Upgrading
Procedures for updating TV software using USB for .pkg and .upg files.
Error Code
Information on error codes, their meaning, and how to read the error buffer.
Set Option Code
Procedure for setting the option code based on panel type.
Electrical Diagram
Block diagram
High-level overview of the TV's system architecture and component connections.
Power Supply
Details the power architecture of the platform.
IC Data Sheets
MT5599IFEQ (IC U401--Scaler)
Technical data sheet for the MT5599IFEQ IC, functioning as a scaler.
TAS5760LDDCAR (IC U5100--Audio)
Technical data sheet for the TAS5760LDDCAR IC, used for audio processing.
SI2169-D60-GMR (U201)
Technical data sheet for the SI2169-D60-GMR IC, likely a tuner or demodulator.
Circuit Diagrams
A 715GA018 PSU (For 55”/65” 7374 Series)
Schematic diagram for the AC input and power supply unit for specific TV series.
PFC with LD7592S
Schematic diagram for the PFC stage using LD7592S.
LLC with SSC3S927
Schematic diagram for the LLC resonant converter with SSC3S927.
Driver with PF7904
Schematic diagram for the LED driver circuit using PF7904.
A 715GA025 PSU (For 70” 7374 & 75” 7354 Series)
Schematic diagram for the AC input and power supply unit for specific TV series.
PFC with LD7592
Schematic diagram for the PFC stage using LD7592.
LLC with SSC3S927
Schematic diagram for the LLC resonant converter with SSC3S927.
LLC SSC3S931 with PF7302
Schematic diagram for the LLC resonant converter with SSC3S931 and PF7302.
JUMPER
Diagram showing various jumper configurations and their labels.
A 715G9892 PSU (For 55”/65” OLED Series)
Schematic diagram for the AC input and power supply unit for OLED series TVs.
PFC stage
Schematic diagram for the PFC stage of the power supply.
12V power stage
Schematic diagram for the 12V power stage of the system.
24V power stage
Schematic diagram for the 24V power stage of the system.
SOC-EMMC
EMMC VCC/VCCQ Power
Power supply connections for the EMMC chip.
SOC-DDR4-1-2
DDR4#1 Bypass Cap
Bypass capacitor layout for DDR4#1 memory module.
DDR4#1 Ref Volt.
Reference voltage connections for DDR4#1 memory.
SOC-DDR4-3-4
DRAM#3 Bypass Cap
Bypass capacitor layout for DRAM#3 memory module.
DRAM#4 Bypass Cap
Bypass capacitor layout for DRAM#4 memory module.
FE-TUNER-DEMOD
TUNER
Tuner block diagram and related components.
DEMOD POWER
Power supply connections for the demodulator IC.
SOC-VB1-OUT
V-BY-1 OUTPUT to Display
Signal routing for V-BY-1 output to the display.
DCDC-SOC-VCCK-DVSS
Core Power
Power supply capacitors for the CPU core.
DCDC-SYSTEM-POWER1
STANDBY POWER +3V3-STANDBY
Standby power supply for +3V3 rails.
DCDC-SYSTEM-POWER2
+12V to +5V-SW
Step-down DC-DC converter for +5V-SW from +12V.
DCDC-SYSTEM-POWER3
DDRV DE-CAP.
Decoupling capacitors for the DDRV power supply.
AUDIO-1st-CLASS-D-AMP
MUTE CIRCUIT
Circuitry for muting the audio output.
HEADPHONE
Headphone output circuit.
HDMI-INPUTS
HDMI4 Connected to RX port 0
Connection details for HDMI input port 4.
HDMI3 Connected to RX port 1
Connection details for HDMI input port 3.
HDMI2 Connected to RX port 2
Connection details for HDMI input port 2.
HDMI1 Connected to RX port 3
Connection details for HDMI input port 1.
HDMI-SOC-ARC
Analog Power
Analog power supply circuitry for HDMI and SOC.
CTRL-CONNECTORS
Prevision for SPI from SOC
SPI signal connections from the SOC.
Debug IR receiver
Circuit for debugging the IR receiver.
CTRL-ETHERNET-PHY
USB PORT 0
Signal length and impedance matching for USB port 0.
USB PORT 1
Signal length and impedance matching for USB port 1.
USB PORT 2
Signal length and impedance matching for USB port 2.
SOC-EMMC
EMMC VCC/VCCQ Power
Power supply connections for the EMMC chip.
SOC-DDR4-1-2
DDR4#1 Bypass Cap
Bypass capacitor layout for DDR4#1 memory module.
DDR4#1 Ref Volt.
Reference voltage connections for DDR4#1 memory.
SOC-DDR4-3-4
DRAM#3 Bypass Cap
Bypass capacitor layout for DRAM#3 memory module.
DRAM#4 Bypass Cap
Bypass capacitor layout for DRAM#4 memory module.
FE-TUNER-DEMOD
TUNER
Tuner block diagram and related components.
DEMOD POWER
Power supply connections for the demodulator IC.
SOC-VB1-OUT
V-BY-1 OUTPUT to Display
Signal routing for V-BY-1 output to the display.
DCDC-SOC-VCCK-DVSS
Core Power
Power supply capacitors for the CPU core.
DCDC-SYSTEM-POWER1
STANDBY POWER +3V3-STANDBY
Standby power supply for +3V3 rails.
DCDC-SYSTEM-POWER2
+12V to +5V-SW
Step-down DC-DC converter for +5V-SW from +12V.
DCDC-SYSTEM-POWER3
DDRV DE-CAP.
Decoupling capacitors for the DDRV power supply.
AUDIO-1st-CLASS-D-AMP
MUTE CIRCUIT
Circuitry for muting the audio output.
HEADPHONE
Headphone output circuit.
HDMI-INPUTS
HDMI4 Connected to RX port 0
Connection details for HDMI input port 4.
HDMI3 Connected to RX port 1
Connection details for HDMI input port 3.
HDMI2 Connected to RX port 2
Connection details for HDMI input port 2.
HDMI1 Connected to RX port 3
Connection details for HDMI input port 1.
HDMI-SOC-ARC
Analog Power
Analog power supply circuitry for HDMI and SOC.
CTRL-CONNECTORS
Prevision for SPI from SOC
SPI signal connections from the SOC.
Debug IR receiver
Circuit for debugging the IR receiver.
CTRL-ETHERNET-PHY
USB PORT 0
Signal length and impedance matching for USB port 0.
USB PORT 1
Signal length and impedance matching for USB port 1.
USB PORT 2
Signal length and impedance matching for USB port 2.
SOC-EMMC
EMMC VCC/VCCQ Power
Power supply connections for the EMMC chip.
SOC-DDR4-1-2
DDR4#1 Bypass Cap
Bypass capacitor layout for DDR4#1 memory module.
DDR4#1 Ref Volt.
Reference voltage connections for DDR4#1 memory.
SOC-DDR4-3-4
DRAM#3 Bypass Cap
Bypass capacitor layout for DRAM#3 memory module.
DRAM#4 Bypass Cap
Bypass capacitor layout for DRAM#4 memory module.
FE-TUNER-DEMOD
TUNER
Tuner block diagram and related components.
DEMOD POWER
Power supply connections for the demodulator IC.
SOC-VB1-OUT
V-BY-1 OUTPUT to Display
Signal routing for V-BY-1 output to the display.
DCDC-SOC-VCCK-DVSS
Core Power
Power supply capacitors for the CPU core.
DCDC-SYSTEM-POWER1
STANDBY POWER +3V3-STANDBY
Standby power supply for +3V3 rails.
DCDC-SYSTEM-POWER2
+12V to +5V-SW
Step-down DC-DC converter for +5V-SW from +12V.
DCDC-SYSTEM-POWER3
DDRV DE-CAP.
Decoupling capacitors for the DDRV power supply.
NT334 POWER
DDR IF power cap
Decoupling capacitors for DDR IF power supply.
NT72315_CONFIG
Slave I2C IF
I2C slave interface configuration for NT72315.
NT334a_CONTROL
FLASH (ICSP) Dedicated GPIO
Dedicated GPIOs for flash programming and factory code.
NT334b_RX_VB1
HTPD LED and LOCK LED circuit
Circuit for HTPD and LOCK LED debugging.
NT334 DDR C-D
DDR Layout notice
Layout guidelines for DDR signals and DDR tester probe connections.
E 715GA039 IR Board
IR&STB LED&Light sensor
Circuit for IR receiver, standby LED, and light sensor.
E 715GA334 Keyboard control panel
Key
Key matrix, joystick circuit, and diversity information.
B 715GA030 AMBI Panel
AMBI Panel
Ambilight panel schematic with component details and diversity.
B 715GA032 AMBI Panel
AMBI Panel
Ambilight panel schematic with component details and diversity.
715GA034 AMBI Panel
AMBI Panel
Ambilight panel schematic with component details and diversity.
715GA034 AMBI Panel
AMBI Panel
Ambilight panel schematic with component details and diversity.
A 715G9946 AMBI Panel
AMBI Panel
Ambilight panel schematic with component details and diversity.
Styling Sheets
7374 series 55"
Exploded view and parts list for the 55" 7374 series TV styling.
7374 series 65"
Exploded view and parts list for the 65" 7374 series TV styling.
7374 series 70"
Exploded view and parts list for the 70" 7374 series TV styling.
OLED804 series 55"
Exploded view and parts list for the 55" OLED804 series TV styling.
OLED804 series 65"
Exploded view and parts list for the 65" OLED804 series TV styling.
7354 series 75"
Exploded view and parts list for the 75" 7354 series TV styling.
