Summary of Contents for Adler MMA-220
- Page 2 PARAMETERS: MMA-175 MMA-195 MMA-220 Model 1 phase AC 1 phase AC 1 phase AC Power 230V / 50Hz 230V / 50Hz 230V / 50Hz Max. Power 6,1kW 7,2kW 8,7kW Consumption Welding Current Range 20-160A 20-190A 20-220A 1,6÷4,0 1,6÷5,0 1,6÷5,0 Diameter of Electrodes...
- Page 3 Warnings: Electric Shock Danger of Welding Fumes Danger of Explosion Danger of UV Radiation Eye Protection and Face Shield is Compulsory Personal Protection is Compulsory Wearing of Protective Gloves is Compulsory Users of vital electrical and electronic apparatus must never use the machine Non-Ionizing Radiation separation of electrical and electronic appliances for refuse collection.
- Page 4 WARNING: READ THE MANUAL CAREFULLY BEFORE USING THE WELDING MACHINE This welding machine conforms to technical product standards for exclusive use in an industrial environment and for professional purposes. 1 . GENERAL SAFETY CONSIDERATIONS FOR ARC WELDING The operator should be properly trained to use the welding machine safely and should be informed about the risks related to arc welding procedures, the appropriate protection measures and emergency procedures.
-
Page 5: Welding Operations
- Always protect your eyes with proper filter, mounted on masks or use helmets. Use the relative fire-resistant clothing and welding gloves without exposing the skin to the ultraviolet and infrared rays produced by the arc; the protection must extend to other people who are near the arc by screens or nonreflective sheets. - Always isolate electrode from welded object and possible grounded metal parts nearby. -
Page 6: Optional Accessories
2 . GENERAL INFORMATION 2.1 INTRODUCTION - This welding machine is a power source for arc welding, made specifically for direct current (DC). The specific characteristics of this regulation system (INVERTER), i.e. high speed and precise regulation, mean the welding machine gives excellent results when welding with coated electrodes (rutile, acid, basic). Regulation with the “inverter”... - Page 7 4. DESCRIPTION OF WELDING MACHINE 4.1 The unit is comprised of power modules which have been developed on a specially printed circuit designed to maximize reliability and reduce maintenance. 1- Power supply input (1~), rectifier group and balancing capacitors. 2- Transistors and drivers switching bridge (IGBT). It turns the mains rectified voltage into high frequency alternate voltage and permits power regulation according to the current/ voltage of the weld to be done.
-
Page 8: Installation
5. INSTALLATION WARNING! CARRY OUT ALL INSTALLATION OPERATIONS AND ELECTRICAL CONNECTIONS WITH THE WELDING MACHINE COMPLETELY SWITCHED OFF AND DISCONNECTED FROM THE POWER SUPPLY OUTLET. THE ELECTRICAL CONNECTIONS MUST BE MADE ONLY AND EXCLUSIVELY BY AUTHORISED OR QUALIFIED PERSONNEL. 5.1 Preparation Unpack the welding machine, assemble the separate parts from the package. -
Page 9: Connection Of The Welding Cables
5.4 CONNECTION TO THE MAIN POWER SUPPLY - Before making any electrical connection, make sure the rating data of the welding machine correspond to the mains voltage and frequency available at the place of installation. - The welding machine should only be connected to a power supply system with the neutral conductor connected to earth. -
Page 10: Maintenance
be of 20-30 grades. - At the end of the weld bead, bring the end of the electrode backward, in order to fill the weld crater, quickly lift the electrode from the weld pool to extinguish the arc. 7. MAINTENANCE WARNING! BEFORE CARRYING OUT MAINTENANCE OPERATIONS MAKE SURE THE WELDING MACHINE IS SWITCHED OFF AND DISCONNECTED FROM THE MAIN POWER SUPPLY. - Page 11 In case any of the above does not help you to start the welding machine, please, contact the supplier or authorized service before you dispatch the machine for a repair.
