INSTRUCTION POUR REGULATEURS ELECTRONIQUES DE VITESSE DES VENTILATEURS
WARTUNGSANLEITUNG FÜR ELEKTRONISCHE DREHZAHLREGLER UND SCHALTSCHRANK
LU-VE S.p.A.
21040 UBOLDO VA ITALIA
Via Caduti della Liberazione, 53
Tel. +39 02 96716.1
www.luve.it
E-mail: sales@luve.it
R2PR - R2TE - RS - RUS - QE
ISTRUZIONE PER REGOLATORI ELETTRONICI
DELLA VELOCITA' DI ROTAZIONE DEI VENTILATORI E QUADRO ELETTRICO
INSTRUCTION FOR ELECTRONIC FAN SPEED CONTROLLERS
Fax +39 02 96780560
AND SWITCH-BOARD
ET ARMOIRE ELECTRIQUE
R2PR
R2TE
RS
RUS
QE
QUADRO ELETTRICO
SWITCH-BOARD
ARMOIRE ELECTRIQUE
SCHALTSCHRANK
S
TUV
SÜDDEUTSCHLAND
EN 60204-1
Advertisement
Related Manuals for LU-VE RUS
Summarization of Contents
General Conformity and Manufacturer's Declaration
Safety Precautions and Warnings
Warnings regarding personal injury or equipment damage due to negligence.
System Configurations and Descriptions
Transport and Installation Guidelines
Guidelines for transporting and installing air cooled condensers and dry coolers.
Fan Power Consumption Data (FE 500/500 PLUS Series)
FE 500/500 PLUS Series Fan Data
Data tables for fan configurations for FE 500/500 PLUS series units.
Fan Power Consumption Data (FC/FE 900/1000 Series)
FC/FE 900/1000 Series Fan Data
Data tables for fan configurations for FC/FE 900/1000 series units.
RUS Fan Power Consumption Data (FE 500/500 PLUS Series)
FE 500/500 PLUS Series RUS Fan Data
Data tables for RUS fan configurations for FE 500/500 PLUS series.
RUS Fan Power Consumption Data (FE 630SPE Series)
FE 630SPE Series RUS Fan Data
Data tables for RUS fan configurations for FE 630SPE series.
RUS Fan Power Consumption Data (FE 800 Series)
FE 800 Series RUS Fan Data
Data tables for RUS fan configurations for FE 800 series units.
RUS Fan Power Consumption Data (FC/FE 900/1000 Series)
FC/FE 900/1000 Series RUS Fan Data
Data tables for RUS fan configurations for FC/FE 900/1000 series.
3-Phase Switch Boards (QE) Overview
Switch Board Casing and Dimensions
Details on switch board casing material, protection rating, and dimensions.
Control Box Component Legend
Component Descriptions and Functions
Detailed explanation of control box components like switches, fuses, transformers, and LEDs.
Wiring Diagram and Layout
Control Box Wiring and Component Connections
Diagram illustrating the wiring of control box components and external connections.
Regulator Unit Internal Components and Specifications
R2PR, R2TE, RS Regulator Features
Details on R2PR, R2TE, RS regulator functions, signals, and input/output types.
R2PR Regulator Wiring Diagram
R2PR Regulator Internal Components and Settings
Wiring diagram and internal component layout for the R2PR regulator.
R2TE Regulator Wiring Diagram
R2TE Regulator Internal Components and Settings
Wiring diagram and internal component layout for the R2TE regulator.
Regulator Alarm Codes and LED Indicators
Alarm Code Definitions
Explanation of alarm codes displayed by the service digit and their meaning.
Wiring and Connections
Set-Point Adjustment Procedure
Instructions for setting the desired temperature or pressure set-points for R2PR and R2TE.
Sensor Location and Wiring Precautions
Sensor Placement Guidelines
Recommended placement for pressure (SPR) and temperature (STE) sensors.
Troubleshooting Guide
Identifying and Resolving Common Problems
Guide to diagnosing and fixing issues like fans not running or fuse blowouts.
RUS Models and Dimensions
RUS Series Overview
General information and dimensional data for RUS series voltage step controllers.
RUS Series Configurations and Features
RUS Series Technical Characteristics
Technical specifications of RUS series, including voltage, current, and environmental ratings.
Regulator Operating Principles and Characteristics
Analog Input Signals and Set-Point Settings
Details on analog input signals, set-point configurations, and parameter ranges.
Regulator Parameter Codes and Settings
Parameter Definitions and Default Values
Table defining parameter codes, their default values, and associated sensor types.
Technical Specifications and Compliance
Protection, Casing, Insulation, and Wiring
Information on electrical protections, casing, insulation, temperature, and wiring standards.
Regulator Operating Principles (FR/DE)
Analog Input Signals and Configuration Modes (FR/DE)
Description of analog input signals and regulator configuration modes in French and German.
Display, LEDs, and Keypad
Alarm Codes and Display Indications
Explanation of visual indicators, alarm codes, and keypad functions for the regulator.
Technical Data and Standards (FR/DE)
Protection, Casing, and Electrical Connections (FR/DE)
Technical specifications regarding protection, casing, insulation, and electrical connections in French and German.
Accessing Configurations Without Service Key
Factory Set-Up and Initial Configuration
Procedure for accessing and selecting factory default configurations without the Service Key.
User Parameter Modification
Modifying Set-Points and Night RPM Limit
Instructions for modifying user-adjustable parameters like Set-Points and Night RPM Limit.
Accessing Menus with Service Key
Configuration Menu (.conF.) Options
Details on accessing and modifying configuration settings via the Service Key.
Service Key Parameter Menu (.PArA.)
Parameter Definitions and Modifications
Table detailing parameters accessible via Service Key and their modification procedures.
RUS 08 Voltage Step Controller Details
RUS 08 Component List and Wiring
List of components and wiring diagram for the RUS 08 voltage step controller.
RUS 16 Voltage Step Controller Details
RUS 16 Component List and Wiring
List of components and wiring diagram for the RUS 16 voltage step controller.
Switch Board and Regulator Electrical Connections
Switch Board Component List
Comprehensive list of electrical components found in the switch board.
