CONSTRUCTION HEATERS
Models: TC100VR and TC100VRNG
IMPORTANT: Read and understand this manual before assembling, starting, or servicing heater.
Improper use of heater can cause serious injury. Keep this manual for future reference.
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS
HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE
FROM HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION, CARBON MONOXIDE POISONING
AND/OR ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE OR
SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTIONS MANUAL,
LABELS, ETC. CONTACT THE MANUFACTURER.
PROPANE AND
NATURAL GAS
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC100VR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Desa TC100VR

Summary of Contents for Desa TC100VR

  • Page 1 PROPANE AND NATURAL GAS CONSTRUCTION HEATERS OWNER’S MANUAL Models: TC100VR and TC100VRNG IMPORTANT: Read and understand this manual before assembling, starting, or servicing heater. Improper use of heater can cause serious injury. Keep this manual for future reference. GENERAL HAZARD WARNING:...

  • Page 2: Safety Information

    Code, CAN/CGA B149.2. This instructs on the safe storage and handling of propane gases. • For Model TC100VR, use only propane gas set up for vapor withdrawal. • For Model TC100VRNG, use only natu- ral gas. Do not attempt to use with LP gas.

  • Page 3: Product Identification

    Natural Gas Valve Inlet Hose/Regulator Assembly for Propane PROPANE SUPPLY (FOR MODEL TC100VR) You must provide propane gas and propane tank(s). Use this heater only with a propane vapor withdrawal supply system. See Chapter 5 of the Standard for Storage and Handling of Liquefied Petroleum Gas, ANSI/NFPA 58 and/or CAN/CGA B149.2.

  • Page 4: Specifications

    TC100VR (Propane) and TC100VRNG (Natural Gas) 100,000 BTU CONSTRUCTION HEATERs SPECIFICATIONS PROPANE MODEL TC100VR Rating(Btu/Hr) 40,000 100,000 Fuel Propane Vapor Only Fuel Consumption Gallons/Hour Pounds/Hour 1.86 Supply Pressure (To Regulator) Maximum 200 psi Minimum, for input adjustment 20 psi Manifold Pressure 25.6"...

  • Page 5: Operation

    HI START/ MEDIUM HIGH Piezo Ignitor Button Figure 5 - Control Knob and Piezo Ignitor Button Locations for Propane Model TC100VR Piezo Ignitor Button Position Position START/ MEDIUM HIGH Figure 6 - Control Knob, and Piezo Ignitor Button Locations for Natural Gas Model...

  • Page 6: Maintenance

    TC100VR (Propane) and TC100VRNG (Natural Gas) 100,000 BTU CONSTRUCTION HEATERs STORAGE CAUTION: Disconnect heater from propane supply tank(s) for Model TC100VR. For Model TC100VR, store propane tank(s) in safe manner. Refer to Chapter 5 of Standard for Storage and Handling of Liquefied Petroleum Gases, ANSI/ NFPA 58 and/or CAN/CGA B149.2.

  • Page 7: Troubleshooting

    TROUBLESHOOTING Note: For additional help, call DESA International’s Technical Service Department at 1-800-323-5190 or visit our website at www.desatech.com. SYMPTOM Burner fails to light Burner lights but goes out when automatic control valve button is released Burn rate is low, emitter not glowing...

  • Page 8: Illustrated Parts Breakdown

    TC100VR (Propane) and TC100VRNG (Natural Gas) 100,000 BTU CONSTRUCTION HEATERs ILLUSTRATED PARTS BREAKDOWN For more information, visit www.desatech.com 4" Flame Spreader Model TC100VRNG Only (Natural Gas) Model TC100VRNG Only (Natural Gas) 106179...

  • Page 9: Parts List

    PARTS LIST This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 6 of this manual. 106179 KEY TC100VR TC100VRNG PART NO. PART NO. 103930-02 103930-03 103032-02 103032-03 099393-03...

  • Page 10: Warranty And Repair Service

    Should your heater require service, return it to your nearest authorized service center. Proof of purchase must be presented with the heater. The heater will be inspected. A defect may be caused by faulty materials or workmanship. If so, DESA International will repair or replace the heater without charge.

This manual is also suitable for:

Tc100vrng
