  • Page 1 SWIMMING POOL TOP 21 / 30 HEAT PUMP UNIT Installation & Instruction Manual...
  • Page 2 Notice 1.1 In order to use this product better and safer, please read this instruction carefully before installation and operation. Please pay attention to all the notices for operation and maintenance. Keep the manual for future reference. 1.2 Air to water heat pump is a special appliance. Improper installation will cause damage and danger.

  • Page 3: Table Of Contents

    CONTENTS I. Specification ..............1 1.Model Nomenclature ............1 2. Parameter of swimming pool heat pump .......1 3. Product appearance and installation dimension ....2 II. Installation ............... 3 1. Unit installation position ............3 2. Positioning Your Swimming Pool Heat Pump ......4 3.

  • Page 4: Parameter Of Swimming Pool Heat Pump

    Parameter of swimming pool heat pump ‫דגם‬ MUSTANG Top30 MUSTANG Top21 29.4 21.0 ‫יכולת חימום‬ ① 100400 71700 BTU/h ① ‫מדד יעילות במצב‬ ① ‫צריכת חשמל‬ 5.35 3.82 ‫אמפר‬ ① 10.2 24.5 17.5 ‫יכולת חימום‬ ② 83600 59800 BTU/h ②...

  • Page 5: Product Appearance And Installation Dimension

    Product appearance and installation dimension Unit Model Top 30 Top 21 Size...

  • Page 6: Installation

    II. Installation 1. Unit installation position To avoid poor ventilation, the unit air discharge should not be blocked when installation. Please keep enough space around the unit for future maintenance. Right and wrong installations are as below: Wrong Right N o tice : 1.

  • Page 7: Positioning Your Swimming Pool Heat Pump

    Positioning Your Swimming Pool Heat Pump 2.1 For correct operation air must be free to circulate around the heat pump. Do not place the unit in a shed, greenhouse or any other similar place. This unit is designed for outdoor use only. 2.2 Refer to the drawing below for required clearance.
  • Page 8 Fit a union nut onto each pipe. Push the gasket over the pipe until the gasket is about 5 -10mm from the edge of the pipe. You may need to lubricate the gasket. Insert the pipe into the heat pump and tighten the union nut. The union must only be hand tightened.

  • Page 9: Electric Wiring

    (m) assistance line 030ZA/S~040ZA/S 2.5mm 2.5mm 380V/3PH/50Hz Top 21~Top 30 4.0mm 4.0mm 4.0mm Note: 1. Use PVC insulated copper wire for above wiring 2. For installation requires, the line is longer than the maximum line length, please contact the company...

  • Page 10: Wifi Remote Control

    III. WIFI remote control This part is for unit with WIFI control only 1. Control the unit through WIFI signal 2. The binding operation for the unit and mobile phone. 2. 1 Download the software with QR code below. The android version The IOS version 2.
  • Page 11 2. 5 Chinese users can select to register "by mobile phone" or "by email ". For other users, please select “Form of Registration” and operate to register according to instructions on the interface. IOS user register account only by email. Android 2.
  • Page 12 2. 7.2 After login the software, it will enter “configure device” interface if water heater has not been bound. Click “AP Mode” to enter “bind pool device” interface. button at the same time till a sound “beep” is heard, 2. 7.3 Long press button and then there’s symbol “h”...
  • Page 13 2. 7.5 Click on the Wifi network name of the water heater, it will skip to server validation interface after enter WLAN network name and password of the connected internet. And next skip to user login interface after successful validation. If connect with WIFI is not successful, repeat step 2.7.3~2.7.5, and try again.
  • Page 14 2. 8 “Pool Device” Operation Interface Introduction After successful device binding, login the software to enter “Pool Device” operation interface. Click on “Heater” icon to enter “Heater” operation interface. Click on the “SWITCH” icon to turn ON and OFF the Pool Device. Drag this “SWITCH”...
  • Page 15 IV.USE 1. Single unit controller MK6030 interface displays. 23 2221 20 19 18 17 5 678 9 Instructions No . Icon Instructions No . Icon Keyboard lock icon Energy-Saving mode icon Defrost icon Breakdown maintenance icon Hot water mode icon Hour Cold mode icon Minutes...

  • Page 16: Operation Of Wired Controller

    2. Operation of wired controller 2.1 Keyboard lock/unlock If there's no operation within 1 minute, the controller will switch to lock automatically. Please long press for 5s to unlock. Keyboard unlocked Keyboard locked 2.2 Unit ON/OFF Under the stand-by mode, press for 1s to turn on the unit, the current mode would be shown on the wire controller, the unit would run under such mode.
  • Page 17 The above pictures show: Unit timing ON/OFF in Phase 2. Turn on unit on 1:30 and turn off on 23:50. Cancel unit timing ON/OFF setting For example, if the timing 2 is needed to be canceled, short press once, the "1" on the wired controller will flicker, press to select "2"...
  • Page 18 2.7 Switch the current operating mode When unit is ON. Under the main interface long press the key can switch the current running mode. Tank temp. Inlet water temp. Ambient temp. Ambient temp. Hot water mode Heating mode Attention: hot water mode, hot Inlet water temp.

  • Page 19: Check The Unit Running State

    Variable water temperature settings in different time period In certain periods of time, heating demand is less, and in certain periods of time, heating demand is larger. This scheme is very suitable for in such circumstance. It can divide 1 day into 4 periods according to user’s actual demand, and different inlet water temperature can be set for 4 different periods.
  • Page 20 Instructions Parameter Parameter Instructions Water tank temp. System 2 compressor current Water inlet temp. System 2 electronic expansion valve steps Water outlet temp. System 3 discharge temp. Ambient temp. System 3 coil temp. Water supply return temp. System 3 suction temp. System 1 discharge temp.
  • Page 21 Range Instructions Parameter Default 30℃ 20℃~55℃ Water inlet temperature setting for period 3 40℃ 20℃~55℃ Water inlet temperature setting for period 4 Electric heating purposes (Not available for pool heat pump) 5℃ -30~35 Environment temperature setting to turn on electric heating (Not available for pool heat pump) ℃...
  • Page 22 ：Set different models, the highest temperature and the default setting temperature is Attention different, specific as follows: ★ Taken the conventional air-cooled hot and cold water machine the highest set temperature 45 ℃, 40 ℃by default. ★ Taken the conventional single maximum set temperature of 55 ℃ hot water machine, the default 55 ℃.

  • Page 23: Aintenance And Repair

    V. Maintenance and repair 1. Malfunction indicating table Malfunction Reason Resolution CODE The system 1 discharge Failure of system 1 discharge E 01 Check or change the sensor sensor is open or short circuit temperature sensor The system 2 discharge Failure of system 2 discharge E 02 Check or change the sensor...
  • Page 24 Malfunction Reason Resolution CODE 1. Check if the inlet water temp. is too high or if any blockage System 3 high System 3 high pressure 2. Check if the unit fan blade is so dirty that it influences P 04 pressure protection protection switch off the efficiency of the heat exchanger.
  • Page 25 Winter antifreeze Outdoor temperature Unit automatically starts antifreeze protection. P 17 Please leave it on standby without power cut-off. protection under standby lower than 0℃ status 1、Check the electric heating is normal or not Electric heating overheating Electric heating overheating P 18 2、Water flow is normal or not 3、...

  • Page 26: Note

    2. Note 1.1 Check whether the exhaust equipment is normal. Avoid cutting of the water supply and or air entering into the system or it will influence the performance and reliability of the unit. The water filter should be cleaned regularly. Keep the water clean in case of any damage to the unit due to filter's dirty and jam. 1.2 Keep the unit environment dry, clean and well ventilation.
  • Page 27 1. The refrigerant leak out 1. Check the leakage and add refrigerant The compressor run 2. Plate exchanger freezes 2. Check the reason and change the plate exchanger but no refrigeration 3. Compressor failure 3.Change the compressor Low water 1.Clean the water filter and exhaust the air from the 1.Water flow volume is insufficient temperature system...

  • Page 28: Wiring Diagram

    V.Wiring diagram 1. MK6019PCB input and output port definition RY 9 RY 8 RY 7 RY 6 RY 5 RY 4 RY 3 TRAN- SW 1 SW 2 SW 1 O F F 单相 三相 预留 DEBUG RS48 TRAN- W_ COM 12 V GND A B Symbol Meaning...
  • Page 29 The purpose of code-dial switch SW1 State :0000 SW2 State:0110 1 2 3 4 1 2 3 4 Digits State ON:1 single phase Reserved OFF:0 three phase Digits State New transformer ON:1 During the modular centralized control, the selection of address code of the unit Old transformer OFF:0 The address setting of the last four digits of dial code switch.
  • Page 30 Wiring diagram（JXT- MK 6019- EG- 02） Mk6019 Fuse(220V/3.15A) TRAN-IN TRAN-OUT Online signa MK4090 P3 P4 Blue 定时 功能 compressor Transformer Wire controller Blue white capacitance capacitance W_COM orange White Unit power input Water cycle pump ( 220 V/ 1 PH/ 50 power outpur ( 220 V/ 1 PH/ 50 Legend：...
