Positive-Negative Pressure Union Filter
Keeping the same usability with vacuum filter "VFU Series"
●
Suitable as pre-filter in positive pressure system.
●
Element can be replaced without any tool, easy maintenance
●
Positive-Negative Pressure Union Filter of Copper alloy free
●
specification is available for the field requiring "No copper
In-line Filter of Easy Maintenance
and usable with positive pressure.
alloy" and "Low level ozone resistance".
pisco.co.jp
pisco.co.jp
http://www.
http://www.
176
Copper
alloy free
Available
