Colour Television
Contents
1. Revision List
2. Technical Specs, Diversity, and Connections
11. Styling Sheets
4900/5000 series 32"
5000 series 40" & 43"
5000 series 48"
Published by YPC/CQZ/SC 1532 Quality
©
2015
TP Vision Netherlands B.V.
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page
Contents
2
2
5
9
9
10
10
23
25
30
37
Drawing PWB
38
39-40
41
43-44
45
50-51
52
68-69
70
71
72
73
74
75
76
Printed in the Netherlands
Chassis
TPM15.5L
Page
Subject to modification
EN 3122 785 19762
LA
Advertisement
Table of Contents
Related Manuals for Philips 32PHG4900/78
Summarization of Contents
Revision List
Manual xxxx xxx xxxx.0 First release
Details the initial release version of the manual.
Manual xxxx xxx xxxx.1
Lists updates for version 1, including chapters 2, 4, 6, 11.
Manual xxxx xxx xxxx.2
Lists updates for version 2, including chapters 2, 4, 6, 11.
Technical Specs, Diversity, and Connections
2.1 Technical Specifications
Details technical specifications and links for product support.
2.2 Directions for Use
Provides links to download user manuals and support documents.
2.3 Connections
Explains rear and side connector layouts and pin assignments.
2.3.1 Side Connections
Details USB 2.0, Headphone, and External Video/Audio In connections.
2.3.2 Rear Connections
Describes TV Antenna input and connection types.
7- HDMI 1: Digital Video - In, Digital Audio with ARC - In/Out
Describes HDMI 1 connector pinout and functions.
8 - Cinch: Digital Audio - Out
Describes the coaxial digital audio output connector.
Precautions, Notes, and Abbreviation List
3.1 Safety Instructions
Outlines safety regulations for repairs and post-repair checks.
3.2 Warnings
Highlights risks of ESD, high voltage, and incorrect component replacement.
3.3 Notes
General information and notes applicable to service procedures.
3.3.1 General
Notes on measuring voltages, waveforms, and using specific test conditions.
3.3.2 Schematic Notes
Explains resistor and capacitor value notations and symbols in schematics.
3.3.3 Spare Parts
Refers to the Philips Spare Parts Web Portal for part information.
3.3.4 BGA (Ball Grid Array) ICs
Provides information on handling BGA devices and temperature profiles.
3.3.5 Lead-free Soldering
Details precautions and techniques for lead-free soldering.
3.3.6 Alternative BOM identification
Explains how the third digit of the serial number identifies the Bill of Materials.
3.4 Abbreviation List
Provides an alphabetical list of abbreviations used in the manual.
Mechanical Instructions
4.1 Cable Dressing
Shows cable routing for 32" 4900/5000 series TVs.
Figure 4-2 Cable dressing (40" & 43" 5000 series)
Illustrates cable routing for 40" and 43" 5000 series TVs.
Figure 4-3 Cable dressing (48" 5000 series)
Shows cable routing for the 48" 5000 series TV.
4.2 Service Positions
Advises on safe and stable positions for servicing the TV.
4.3 Assembly/Panel Removal
Procedures for disassembling the TV and removing components.
4.3.1 Stand
Instructions for removing the TV stand bracket.
4.3.2 Rear Cover
Steps for safely removing the rear cover, including warnings.
4.3.3 Keyboard Control Unit
Steps to release and remove the keyboard control panel.
4.3.4 Small Signal Board (SSB)
Instructions for disconnecting and removing the SSB.
4.3.5 Power Supply Unit (PSU)
Steps for disconnecting and removing the PSU.
4.3.6 Speakers
Instructions for removing the speakers.
4.3.7 IR/LED Board
Steps to remove the IR/LED board.
4.3.8 LCD Panel
Detailed steps for removing the LCD panel.
4.4 Set Re-assembly
General guidance for reassembling the TV in reverse order.
Service Modes, Error Codes, and Fault Finding
5.1 Test Points
Notes on measuring signals with an oscilloscope and using test patterns.
5.2 Service Modes
Overview and access methods for various service modes.
5.2.1 General
General information applicable to all service modes, including Life Timer.
5.2.2 Service Alignment Mode (SAM)
Purpose, specifications, and activation of SAM mode for alignments.
5.2.3 Contents of the Factory mode:
Purpose and contents of the Factory mode for extended alignments.
5.2.4 Customer Service Mode (CSM)
Purpose, specifications, and activation of CSM for customer diagnosis.
5.3 Stepwise Start-up
Illustrates the TV's power-on sequence and states.
5.4 Service Tools
Information on diagnostic tools used for service.
5.4.1 ComPair
Introduction, specifications, and connection details for the ComPair service tool.
5.5 Software Upgrading
Procedure for upgrading the TV's main software via USB.
5.5.1 Description
Explains user software upgrades via USB port.
5.5.2 Introduction
Details requirements for preparing portable memory for software upgrades.
5.5.3 Check the current TV software version
Steps to check the TV's current software version before updating.
5.5.4 Download the latest software
Instructions for downloading software updates from the Philips website.
5.5.5 Update the TV software
Step-by-step guide for updating the TV software via USB.
5.5.6 Content and Usage of the One-Zip Software File
Explains the contents of the One-Zip software file for service use.
5.6 Error Codes
Explanation of error codes and the error buffer.
5.6.1 Introduction
Explains the purpose of error codes and the error buffer.
5.6.2 How to Read the Error Buffer
Describes methods to read error codes via OSD, blinking LED, or ComPair.
5.6.3 Error codes
Lists defined "layer 2" error codes and their meanings.
5.6.4 How to Clear the Error Buffer
Details methods to clear the error buffer using SAM, Factory mode, or RC sequence.
5.7 The Blinking LED Procedure
Method to diagnose errors using the blinking LED indicator.
5.7.1 Introduction
Explains how the blinking LED indicates different error types.
5.8 Fault Finding and Repair Tips
General advice and tips for troubleshooting and repair.
5.8.1 NVM Editor
Information on using the NVM editor in SAM mode to change NVM contents.
5.8.2 Load Default NVM Values
Explains how to upload default NVM values after SW changes or NVM replacement.
5.8.3 No Picture
Troubleshooting steps for scenarios with no picture, including checking display code.
5.8.4 Unstable Picture via HDMI input
Troubleshooting for unstable pictures via HDMI, checking EDID data.
5.8.5 No Picture via HDMI input
Troubleshooting for no picture via HDMI, checking HDCP key validity.
5.8.6 TV Will Not Start-up from Stand-by
Suggests checking Stand-by Controller failure and re-flashing software.
5.8.7 Audio Amplifier
Notes on replacing the Class D-IC U606 and its powerpad.
5.8.8 CSM
Explains CSM behavior when a USB memory stick is connected.
5.8.9 Loudspeakers
Caution regarding disconnecting speakers while the TV is on to avoid amplifier damage.
5.8.10 Display option code
Emphasizes checking Panel Code in CSM after SSB replacement.
Alignments
6.1 General Alignment Conditions
Specifies conditions for performing electrical adjustments and measurements.
6.2 Hardware Alignments
States that hardware alignments are not applicable.
6.3 Software Alignments
Procedures for adjusting software-controlled parameters.
6.3.1 RGB Alignment
Details how to set picture parameters and align RGB values for white tone.
6.3.2 Display Adjustment
Instructions to set color temperature and RGB values using SAM mode.
6.4 Option Settings
Configuration settings related to hardware and software options.
6.4.1 Introduction
Explains the role of option codes for microprocessor communication with ICs.
6.4.2 Option Code Overview
Guide to checking and editing option codes in SAM mode.
6.4.3 Display Code Overview
Key sequence to set the panel type display code.
6.5 Reset of Repaired SSB
Crucial steps to reset NVM and related data after SSB repair.
6.5.1 Reset of Repaired SSB
Instructions for resetting NVM, MAC address, and production codes after SSB replacement.
Circuit Descriptions
7.1 Introduction
Overview of the TPM15.5L LA chassis and its key components.
7.1.1 Implementation
Lists the key components of the chassis, including SCALER and Tuner.
7.1.2 TPM15.5L LA Architecture Overview
Refers to block diagrams for chassis architecture overview.
7.1.3 SSB Cell Layout
Shows the layout of components on the SSB board.
7.2 Power Supply
Description of the TV's power supply architecture and units.
7.2.1 Power Supply Unit
Details the power supply board as a black box for service and its output voltages.
7.2.2 Diversity
Explains diversity in power supply units based on display types (CCFL, LED).
7.2.3 Connector overview
Provides a table detailing connector pin assignments for different screen sizes.
7.3 DC/DC Converters
Details the DC/DC converters and the voltages they supply.
7.4 Front-End Analogue and DVB-T, DVB-C; ISDB-T reception
Description of tuner and reception circuitry.
7.4.1 Front-End Analogue part
Describes key components for analogue tuner and provides a block diagram.
7.4.2 DTV part
Describes key components for DTV front-end and provides a block diagram.
7.5 HDMI
Details the HDMI connector types and their functions (HDCP, ARC, CEC).
7.6 Video and Audio Processing - MT5561LVNT/B PBGA-329
Lists features of the main audio/video processor and its capabilities.
IC Data Sheets
8.1 Diagram 10-4-2 Peripheral, B02, MT5561LVNT (IC U401B)
Shows the internal block diagram of the MT5561LVNT IC.
Pinning Information MT5561LVNT
Provides pin configuration details for the MT5561LVNT IC.
Pinning Information MT5561LVNT
Continues pin configuration details for the MT5561LVNT IC.
8.2 Diagram 10-4-1 System Power B01, M5723B (IC U703)
Details the M5723B system power IC.
Block diagram
Shows the internal block diagram of the M5723B system power IC.
Pinning information
Provides pin configuration details for the M5723B IC.
8.3 Diagram 10-4-4 Speaker Amp B04, TAS5729MDDCAR (IC U601)
Details the TAS5729MDDCAR speaker amplifier IC.
Block diagram
Shows the block diagram of the TAS5729MDDCAR speaker amplifier IC.
Pinning information
Provides pin configuration details for the TAS5729MDDCAR IC.
8.4 Diagram 10-4-9 TUNER B09, MxL661 (IC U104)
Details the MxL661 tuner IC.
Block diagram
Shows the block diagram of the MxL661 tuner IC.
Pinning information
Provides pin configuration details for the MxL661 tuner IC.
8.5 Diagram 10-4-16 DEMOD_Toshiba TC90537 B16, TC90537FG (IC U101)
Details the TC90537FG demodulator IC.
Block diagram
Shows the block diagram of the TC90537FG demodulator IC.
Pinning information
Provides pin configuration details for the TC90537FG IC.
Block Diagrams
9.1 Block diagram 4900 & 5000 series
Presents a system block diagram for the 4900 and 5000 series TVs.
Circuit Diagrams and PWB Layouts
10.1 A 715G6863 PSU
Circuit diagram for the A 715G6863 Power Supply Unit.
10-1-2 Power layout top
Top-side PWB layout for the A 715G6863 PSU.
10-1-3 Power layout bottom
Bottom-side PWB layout for the A 715G6863 PSU.
10.2 A 715G6934 PSU
Circuit diagram for the A 715G6934 Power Supply Unit.
10-2-1 POWER
Circuit diagram for the A 715G6934 Power Supply Unit.
10-2-2 LED DRIVER
Circuit diagram for the LED driver module.
10-2-3 Power layout top
Top-side PWB layout for the A 715G6934 PSU.
10-2-4 Power layout bottom
Bottom-side PWB layout for the A 715G6934 PSU.
10.3 A 715G6338 PSU
Circuit diagram for the A 715G6338 Power Supply Unit.
10-3-1 AC input
Circuit diagram for the AC input stage of the A 715G6338 PSU.
10-3-2 LED Driver
Circuit diagram for the LED driver for the A 715G6338 PSU.
10-3-3 LLC 36V
Circuit diagram for the LLC 36V section of the A 715G6338 PSU.
10-3-4 Main Power 12V
Circuit diagram for the main power 12V section of the A 715G6338 PSU.
10-3-5 PFC
Circuit diagram for the Power Factor Correction section of the A 715G6338 PSU.
10-3-6 Power layout top
Top-side PWB layout for the A 715G6338 PSU.
10-3-7 Power layout bottom
Bottom-side PWB layout for the A 715G6338 PSU.
10.4 B 715G6836 SSB
Circuit diagrams and PWB layouts for the main SSB board.
10-4-1 System Power
Circuit diagram for the system power section of the SSB.
10-4-2 Peripheral
Circuit diagram for peripheral connections on the SSB.
10-4-3 Audio A-in/I2S/HP
Circuit diagram for audio inputs, I2S, and headphone outputs.
10-4-4 Speaker Amp
Circuit diagram for the speaker amplifier section of the SSB.
10-4-5 VGA
Circuit diagram for the VGA input interface.
10-4-6 Video YPbPr/CVBS
Circuit diagram for YPbPr and CVBS video/audio inputs.
10-4-7 SPDIF/Mute contorl
Circuit diagram for SPDIF output and audio mute control.
10-4-8 LVDS_Keypad_IR
Circuit diagram for LVDS, keypad, and IR interfaces.
10-4-9 TUNER
Circuit diagram for the TV tuner module.
10-4-10 DDR3
Circuit diagram for the DDR3 memory interface.
10-4-11 HDMI/MHL
Circuit diagram for HDMI and MHL interfaces.
10-4-12 GPIO
Circuit diagram illustrating GPIO control and connections.
10-4-13 USB/WiFi
Circuit diagram for USB and WiFi interfaces.
10-4-14 FACTORY DEBUG PORT
Circuit diagram for the factory debug port and its functions.
10-4-15 VCCK & DVSS
Circuit diagram showing VCCK and DVSS power distribution.
10-4-16 DEMOD_Toshiba TC90537
Circuit diagram for the Demodulator IC.
10-4-18 SSB layout bottom
Bottom-side PWB layout for the SSB.
10.5 J 715G6167 IR/LED Panel
Circuit diagrams for the IR/LED panel.
10-5-1 IR/LED panel
Circuit diagram for the IR/LED panel assembly.
10-5-2 IR/LED board layout
Top and bottom side layouts for the IR/LED board.
10.6 E 715G6316 Keyboard control panel
Details of the keyboard control panel.
10-6-1 Key
Explains key functions, resistances, voltages, and joystick circuit.
10-6-2 Key board layout
Top and bottom side layouts for the keyboard control panel.
Styling Sheets
11.1 4900/5000 series 32"
Exploded view of parts for 32" 4900/5000 series TVs.
11.2 5000 series 40" & 43"
Exploded view of parts for 40" and 43" 5000 series TVs.
11.3 5000 series 48"
Exploded view of parts for the 48" 5000 series TV.
Need help?
Do you have a question about the 32PHG4900/78 and is the answer not in the manual?
Questions and answers
