Installation Manual and User Manual for BYD
Code
2M SOP0007540
Installation Manual and User Manual for
BYD Photovoltaic Modules
BYD COMPANY LIMITED
Project No.
Edition
13
Page
\
3 / 22
BYD COMPANY LIMITED.
ADD: No. 1, Yan'an Road,
Kuichong, Dapeng New District,
518119 Shenzhen, Guangdong,
PEOPLE'S REPUBLIC OF
CHINA
TEL:+86-755-8988 8888
FAX:+86-755-8420 2222
www.byd.com.cn
3
Advertisement
Chapters
Table of Contents
Related Manuals for BYD PHL Series
Summary of Contents for BYD PHL Series
- Page 1 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 3 / 22 Installation Manual and User Manual for BYD Photovoltaic Modules BYD COMPANY LIMITED. ADD: No. 1, Yan’an Road, Kuichong, Dapeng New District,...
-
Page 2: Table Of Contents
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 4 / 22 CONTENT Foreword ..................................................5 1. Product identification ............................................5 1.1 Label ....................................................5 1.2 Barcode ..................................................5 2. Transportation and storage manual ......................................... 6 3. -
Page 3: Foreword
PV modules (hereafter referred to as “module”). Please read this manual carefully before installing and using the modules. Please get in touch with the provider if you have any questions. This manual applies to all the standard modules of BYD Company FIG.1 Bar code Limited. -
Page 4: Transportation And Storage Manual
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 6 / 22 ASEC- ——Engineering Code ,for different shifts, materials etc; tools during electrical work. 001——Number of product components,3 digit sequence 0 to 999 (3) Although the glass surface of the modules is rather durable and for sequential production starting on each new day of production at 001. - Page 5 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 7 / 22 box or on the surface of module. (15)In case of roof top installation, the PV array should fulfill the (10)The user should design and select a metallic bracket for requirements regarding fire resistance of the norm IEC 61730-2.
-
Page 6: Mechanical Installation
FIG.2 P6K series models NOTE: BYD does not limit the materials of the installation as long as they can be used outdoors for at least 25 years 3.2 Mechanical installation 3.2.1 Mounting system Use screws put through the mounting holes according to the following... - Page 7 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 9 / 22 FIG.3 PHL series models FIG.4 PHK series models TAB.1 The size of each code measure Model BYDxxxP6C/K-18 1482 50/40/35...
- Page 8 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 10 / 22 BYDxxxP6C/K-30 BYDxxxM6C/K-36 1645 45/40/35 1360 BYDxxxM6C/K-30 BYDxxxPHC/K-36 2400Pa 2400Pa BYDxxxPHC/K-30 BYDxxxMHC/K-36 1658 40/35 1360 BYDxxxMHC/K-30 Remark: A load of 1600Pa for frontal, a load of 1600Pa for back(IEC61215 BYDxxxPHC/K-30 2016 safety factor 1.5).
-
Page 9: Clamping
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 11 / 22 BYDxxxM6C/K-18 BYDxxxM6C/K-36 5) HEX Stainless Nut BYDxxxP6C/K-24 BYDxxxPHC/K-36 3.2.2 Clamping BYDxxxP6C/K-27 BYDxxxMHC/K-36 BYDxxxP6C/K-30 BYDxxxMIC/K-36 For clamping of the modules, clamps can be used as in the... - Page 10 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 12 / 22 Measure Measure BYDxxxMHC/K-36(L=1978) Model BYDxxxPIC/K-36（2008） BYDxxxP6K-18 BYDxxxMIC/K-36（2008） BYDxxxM6K-18 BYDxxxPIC/K-39(L=2166) BYDxxxP6K-24 BYDxxxMIC/K-39(L=2166) BYDxxxP6K-27 Remark: “A” denotes the distance from the clamp to the edge of the module, BYDxxxP6C/K-30（L=1640）...
-
Page 11: Insertion System
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 13 / 22 3.2.3 Insertion system For the modules to follow an insertion system as depicted below can be used for installation. - Page 12 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 14 / 22 below for installation on the long side of the frame: FIG. 12 Guide rail FIG. 13 The front cannot block the PV...
-
Page 13: Electric Installation
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 15 / 22 √ Note: : Indicates compliance with load bearing installation Long side bolt FIG.2 requirements; X: indicates that the load bearing installation FIG.3... -
Page 14: General Installation
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 16 / 22 follows the items referred in IEC 61730-1.When the modules in a PV system are connected in series or parallel generally, we recommend... - Page 15 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 17 / 22 that produce more current/voltage than reported at STC. Accordingly, 10SQ050 Isc and Voc must be multiplied by 1.25 (for C-Si or non-C-Si) we...
- Page 16 We recommended the maximum number of modules is 3. The fuse cable and 100° C for the connectors. We demand the connection must be matching BYD’s, otherwise BYD don’t protection needs to be determined as well. (5)To prevent the cables and the connectors from overheating, the...
-
Page 17: Maintenance And Care
Excess dirt and dust accumulating on the glass surface of the connection to the components of the equipment and the grounding module can reduce its power output. Therefore BYD recommends system. Check regularly, if the value of the grounding resistance is still... - Page 18 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 20 / 22 check the glass surface of the module for cracks and damages before destroy glass surface. Use cleaning effect to judge whether clean or cleaning.
-
Page 19: 5．Claim
(PV) cleaner should wear appropriate protective clothing and wear helmets products are beyond BYD’s control. BYD does not accept responsibility to avoid causing injury. It is necessary to prohibit the emergence of and expressly disclaims liability for any loss, damage, or expense... - Page 20 Edition Page 22 / 22 The information in this manual is based on BYD’s knowledge and experience and is believed to be reliable. This manual provides reference only, and consumers are free to choose an appropriate way of installation according to place and environment.
- Page 21 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 1 / 19 Installation Manual and User Manual for BYD Photovoltaic Modules BYD COMPANY LIMITED. ADD: Yan An Road, Kuichong, Longgang, 518119 Shenzhen,...
- Page 22 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 2 / 19 CONTENT Foreword ..................................................3 1. Product identification ............................................3 1.1 Label ....................................................3 1.2 Barcode ..................................................3 2. Transportation and storage manual ......................................... 4 3.
-
Page 23: Foreword
Please get in touch with the provider if you have any questions. FIG.1 Bar code This manual applies to all the standard modules of BYD Company Limited. SH 130701 P630 ASEC 001 Keep this guide in a safe place for future reference (care and SH——Manufacturer location, SH:Shanghai;... -
Page 24: Transportation And Storage Manual
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 4 / 19 2. Transportation and storage manual no longer work properly), if it is dropped or hit by tools or other heavy objects. - Page 25 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 5 / 19 brackets should be selected by the user according to their destined should not exceed -40° C ~+85° C. places of installation, such as open land or a rooftop. For safety (17) Do not connect/disconnect modules during load connection.
-
Page 26: Mechanical Installation
FIG.2 P6K/M6K series models NOTE: BYD does not limit the materials of the installation as long as they can be used outdoors for at least 25 years 3.2 Mechanical installation 3.2.1 Mounting system Use screws put through the mounting holes according to the... - Page 27 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 7 / 19 BYDxxxP6K-30 1645 45/40/35 1360 BYDxxxM6K-30 BYDxxxPHK-30 1669 50/40/35 1360 BYDxxxMHK-30 BYDxxxP6K-36 1956 50/40/35 1300 BYDxxxM6K-36 BYDxxxP6K-36 1962 45/40/35 1300...
-
Page 28: Clamping
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 8 / 19 BYDxxxMHC/K-30 TAB.3 The size of each code measure BYDxxxPIC/K-30 BYDxxxMIC/K-30 Mechanical Mechanical load Model load test Installation details: test（Back）... - Page 29 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 9 / 19 BYDxxxP6C/K-30（L=1645） back(IEC61215 2016 safety factor 1.5). If a module is installed with clamps on a long side of the frame, “B”...
-
Page 30: Insertion System
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 10 / 19 FIG. 9 Schematic diagram of short side pressing block FIG. 7 Schematic diagram of long side pressing block We advise users to use an installation method as shown in the two pictures above, as this method renders modules connection rather fast. - Page 31 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 11 / 19 FIG. 10 Installation diagram of long side guide rail under pressure of 3600Pa(IEC61215 2016 safety factor 1.5) FIG. 11 Guide rail installation diagram...
-
Page 32: Electric Installation
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 12 / 19 All the mounting ways above are suitable to roof mounting. And the press FIG.9 module is considered to be in compliance with IEC61215 when the Short side rail FIG.11... -
Page 33: General Installation
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 13 / 19 is to ensure the resulting safety. We recommend one method as 3.3.2 General Installation sketched below: (1)The module was rated for use in the A application class which follows the items referred in IEC 61730-1.When the modules in a PV... - Page 34 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 14 / 19 Type Maximum DC Blocking Voltage Maximum Average Forward Current According to the system voltage (1500V) of the IEC standard.
- Page 35 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 15 / 19 protection needs to be determined as well. ≤26 BYDxxxPHC-36/PHK-36 (5)To prevent the cables and the connectors from overheating, the ≤30...
-
Page 36: Maintenance And Care
Excess dirt and dust accumulating on the glass surface of the connection to the components of the equipment and the grounding module can reduce its power output. Therefore BYD recommends system. Check regularly, if the value of the grounding resistance is still... - Page 37 BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 17 / 19 cooled, and after cleaning PV modules must ensure dry ,next it are soft cloth to clean. connected. Non-professional authorized personnel are not allowed to...
-
Page 38: 5．Claim
BYD COMPANY LIMITED Document Installation Manual and User Manual for BYD Project No. Code 2M SOP0007540 Edition Page 18 / 19 (1) It is forbidden to use bareness fingers or hand without gloves to avoid causing injury. It is necessary to prohibit the emergence of touch or deal with modules glass surface. - Page 39 The information in this manual is based on BYD’s knowledge and experience and is believed to be reliable. This manual provides reference only, and consumers are free to choose an appropriate way of installation according to place and environment.
