7 Spare parts

A long-lasting reliable operation of the compressor unit is ensured by regular renewal of wear- and tear
parts. Please see the spare parts kits chart below (Standard-Kits are shaded).
Konditionsblatt Ersatzteil-Kits
Öleingespritzte Standardkompressoren
Spare Part Kits for oilinjected standard airends
Typ Zeichnungs-Nr. *
Type Drawing number
CF75D/D3
401-0-003929
CF75D5/D6/D8
22415269
CF75D7
401-1-005707
CF75G1
400-0-028934
CF75G2
401-0-002625
CF75G
22950968
CF90D/LD
400-0-044569
CF90D2/D3/LD1
22549836
CF90G/G2/LG/LG2
400-0-015202
CF90G5/G8/LG3/LG5
22552616
CF90G6
401-0-005253
CF128D/D2/LD
400-1-017757
CF128G/G2/LG/LG2
400-1-016770
CF128R/LR
22483382
CF180D
400-0-039919
CF180R/RB
401-0-003329
CF180G
400-0-039920
CF180G1
400-0-039920
CF180G2
401-0-003580
CF246G
400-0-045266
* please note current revision status
Installation Manual Series CF (excluding encapsulated screw compressors)
Kompressor-Kit SB Kompressor-Kit Light SB
Compressor Kit Compressor Kit Light
83903537 2
83903706 5
83903389 0
83903539 0
83903540 0
83901385 10
83903541 2
83903543 10
83901543 5
83901550 5
83901589 0
83900827 3
83900972 5
C22875272 2
83903545 1
83903548 3
83900812 2
83903547
83903873 1
Getriebe-Kit SB
Gear Kit
C22696058 0
C22696066 0 83901384
C22696074 0
C22696090 0 83901542
C22696330 0 83901549
C22696108 0
C22696116 0 83900826
C22875736 0
83900979
83900979
C22696124 0 83900979
C22784540 0 83903874
