ViewSonic VP2655WB - 26" LCD Monitor Specification Sheet page 2

VP2655wb
26" (25.5" VIEWABLE) PROFESSIONAL LCD WITH IPS PANEL TECHNOLOGY
Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com
*Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete
details. Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Corporate names, trademarks stated herein are the property of
their respective companies. Copyright © 2009 ViewSonic Corporation. All rights reserved. [14573-01B-10/09] VP2655wb-1
For more product information, visit us on the web at ViewSonic.com
LCD
VIDEO INPUT
COMPATIBILITY
CONNECTOR
POWER
CONTROLS
ERGONOMICS
OPERATING
CONDITIONS
DIMENSIONS
(W x H x D)
WEIGHT
VESA MOUNT
®
REGULATIONS
RECYCLE/DISPOSAL
POWER MANAGEMENT
PACKAGE CONTENTS
WARRANTY
ViewSonic Corporation's QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
Type 26" (25.5" viewable) Color TFT active matrix LCD
Display Area 21.7" horizontal x 13.5" vertical; 25.5" diagonal
Optimum Resolution 1920x1200
Contrast Ratio 1000:1 static (typ), 4000:1 dynamic
Viewing Angles 178º horizontal, 178 vertical @ contrast ratio > 10:1
Response Time 5ms (typ)
Light Source Long life, 40,000 hrs. (typ)
Brightness 400 cd/m
Panel Surface Anti-glare
Analog / Digital RGB analog (75 ohms, 0.7/1.0 Vp-p) / DVI (HDCP)
Frequency F h : 24~92kHz, F v : 50~85Hz
Sync H/V separated (TTL), composite, sync-on-green
PC VGA up to 1920x1200 non-interlaced
Mac * G3/G4/G5 up to 1920x1200
®
Analog / Digital 15-pin mini D-sub / DVI-D
USB V2.0, 1-up/4-down
Power Internal power; 3-pin AC plug (CEE22)
Voltage AC 100–240V, 50–60Hz (auto switch)
Consumption 110W (typ)
Basic Power, 2, up, down, 1
OnView Auto image adjust, contrast, brightness, input select
®
(D-SUB, DVI), color adjust (sRGB, 9300K, 7500K, 6500K,
5000K, User color [R, G, B]), information, manual image
adjust (H/V position, horizontal size, fine tune, sharpness,
dynamic contrast, aspect ratio, eco mode), setup menu
(language select, resolution notice, OSD position, OSD
time out, OSD background) memory recall
Height adjustment range 5.4", tilt –3º/+20º,
swivel range 120º, pivot 0–90º
Temperature 32–104ºF (0–40ºC)
Humidity 10–90% (non-condensing)
Physical with stand 23.4" x 18.4" x 15.3" (595mm x 468mm x 388mm)
Physical without stand 23.4" x 15.3" x 3.9" (595mm x 389mm x 100mm)
Packaging 26.9" x 19.1" x 22.0" (683.3mm x 485.1mm x 558.8mm)
Net with stand 24.2 lb. (11.0 kg)
Net without stand 17.0 lb. (7.7 kg)
Gross 30.1 lb. (14.0 kg)
200mm x 100mm
UL, CUL, FCC-B (ICES), CB, CE, TCO'03, ICES-003B,
ISO13406-2, TUV/GS, TUV ERGO(covers ISO13406-2 &
MPRII), TUV-S, NOM, GOST-R, HYGIENIC (20 copies),
CCC, BSMI, PSB, C-TICK, KTL/MIC, SASO, WEEE, RoHS
The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
Meets TCO'03 standards
LCD display, power cable, VGA cable, DVI cable,
USB cable, Quick Start Guide, ViewSonic Wizard CD
Three-year limited warranty on parts, labor and backlight.
2 (typ)
