Welcome!
We know you are excited about your new Pro-Wired Electronics.
Before you jump in,
WARNING!!!
Using the wrong sized, or overly tight knobs,
DAMAGE
will
your Pro-Wired Electronics.
Solid shaft pots - use only US spec ¼" knobs
Split shaft pots - use only US spec 24 spline knobs
