Bergen DC-15 User Manual

User Manual DC-15
Before first use, completely charge the battery
Safety precautions
•
Do not use in the immediate vicinity of inflammable
materials or gases.
•
Do not touch LED portion of light after an extended
period of use. Temperature can reach or exceed 40°C
•
Keep the lens and surrounding areas free from
obstructions during use.
•
Recommended to only use the accessories included
with the product for recharging the light.
•
Keep the lamp out of reach of unauthorized persons,
especially children.
•
Do not point the light directly in your own or any
other person's or animal's eyes.
•
Inspect charging cable and port for damage before
use. Do not use if damaged.
•
Keep charging port cover in place when not in
use to keep out water, dirt & dust.
Lamp design and accessories
•
USB power bank
•
Battery life meter
•
IP65 water-resistant
•
LED reflecting bowl
•
Swivel handle and stand
Technical data
•
3.7V – rechargeable battery, Lithium 3.7V 2500mAh
•
10W Chip on Board (COB) LED
•
Lumen Rating: Approx. 1,000LM
•
Ambient temperature: -10° to +45°C
•
Usage period: Approx. 3.0 hours at 100% Brightness
•
Charging period: Approx. 5h (at 25℃)
•
Protection class: III
•
Charging input: 5V max. 1000mA
Recharging
•
Completely charge the battery before first use and
completely discharge the battery before recharging.
•
For ideal battery life expectancy, it is recommended
to charge at least once every 3 months.
•
Charge with a USB port charger or other 5-volt output
USB device (1000 mA maximum, not included) using
included USB cable.
•
Battery charge status can be monitored by viewing
the LED battery status indicator. The battery is fully
charged when all three LEDs are lit.
Usage
On/Off & Brightness Button:
1: Press One time: 100% brightness
2: Press Two times consecutively: 50% brightness
3. Press Three times consecutively: 10% brightness
3: To turn off, press four times consecutively or once if
the light has been on for more than 5 seconds
NOTE:
Be sure to properly dispose of used battery.
