Step 2: Shower Floor Installation
A. Sub-floor Requirements and Support
Ensure a level and supported sub-floor, using plywood if necessary.
B. Drain Opening and Pipe Preparation
Cut a 5-inch square opening for the drain and prepare the pipe.
Shower Floor Placement & Drain Sealing
C. Floor Placement and Leveling
Place and level the shower floor, using additional support if needed.
D. Drain Seal Installation
Seal the drain properly with the gasket and sealant.
Step 3: Shower Wall Installation
A. Drilling for Valve and Showerhead
Drill holes in the side panel for controls and showerhead placement.
Shower Wall Panel Prep & Sealing
B. Mounting Flange Drilling and Support
Pre-drill mounting flanges and utilize all holes for structural support.
C. Utilizing All Mounting Holes
Ensure all pre-marked mounting holes are used to prevent structural issues.
D. Silicone Sealant in Grooves
Apply silicone sealant to panel grooves for a watertight seal.
Shower Wall Assembly & Panel Insertion
E. Securing Side Panels and Corner Panel
Insert and secure side panels into the corner panel with clips.
Step 4: Panel Insertion & Sealing
A. Side Panel Insertion
Insert the side panel blade into the corresponding slot in the corner panel.
Panel Contact & Sealing (Step 4)
B. Applying Silicone Sealant to Contact Points
Apply sealant to panel contact points and edges for vibration and sealing.
Final Unit Installation & Finishing
C. Setting Assembled Unit and Securing
Place the unit, compress silicone, and secure with screws, ensuring plumb.
D. Alcove Finishing with Sheetrock
Finish the alcove area with water-resistant sheetrock.
E. Sealing Holes for Fixtures
Apply silicone sealant around holes for handles and showerhead.
