ViewSonic VA503B - 15" LCD Monitor Specification page 2

VA503b
1 5 " VA L U E S E R I E S L C D W I T H 1 6 M S V I D E O R E S P O N S E
ViewSonic Corporation's QMS & EMS have been registered to
ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com
*Excluding major U.S. holidays. **Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details. Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Corporate names, trademarks stated
herein are the property of their respective companies. Copyright © 2008 ViewSonic Corporation. All rights reserved. [14178-00B-09/08] VA503b-1
For more product information, visit us on the web at ViewSonic.com
LCD Type
Display Area
Optimum Resolution 1024x768
Contrast Ratio
Viewing Angles
Response Time
Light Source
Brightness
Panel Surface
VIDEO INPUT Analog
Frequency
Sync
COMPATIBILITY PC
Mac ® **
CONNECTOR Analog
Power
POWER Voltage
Consumption
CONTROLS Basic
OnView ®
OPERATING Temperature
CONDITIONS Humidity
DIMENSIONS Physical (mm)
(W x H x D) Physical (in.)
WEIGHT Net
Gross
REGULATIONS
RECYCLE/DISPOSAL
POWER MANAGEMENT
PACKAGE CONTENTS
WARRANTY
15" color TFT active matrix XGA LCD
11.9" horizontal x 8.9" vertical; 15.0" diagonal
500:1 (typ)
160° horizontal, 115° vertical @ contrast ratio > 5:1
16ms (typ)
Long life, 50,000 hrs. (typ)
250 cd/m2 (typ)
Anti-glare
RGB analog (75 ohms, 0.7 Vp-p)
F h : 30~82kHz, F v : 50~85Hz
H/V separated (TTL)
VGA up to 1024x768 non-interlaced
Power Mac™ G3/G4/G5 up to 1024x768
15-pin mini D-sub
3-pin AC plug
AC 100–240V (universal), 50/60Hz (auto switch)
23W (typ)
Power, 1, down, up, 2
Auto image adjust, brightness, contrast, input selection,
ViewMatch ® color adjust (sRGB, 9300K, 6800K, 6500K),
information (mode, model number, serial number), manual
image adjust (H. position, V. position, fine tune, sharpness),
setup menu (language, resolution notice, OSD position,
OSD timeout, OSD background), memory recall
32–104°F (0–40°C)
20–90% (non-condensing)
344mm x 347.5mm x 147mm
13.2" x 13.7" x 5.8"
6.0 lb. (2.7 kg)
8.2 lb. (3.7 kg)
UL, cUL, FCC-B, CB, CE, ENERGY STAR
TUV-S, TCO'99, GOST-R, SASO, BSMI, CCC, PSB, C-TICK,
RoHS
The lamp in this product contains mercury. Please dispose of
in accordance with local, state or federal laws.
Meets TCO'99 and ENERGY STAR ®
LCD display, video cable, power cable, Quick Start Guide,
ViewSonic Wizard
Three-year limited warranty on parts, labor and backlight.
® , NOM, GS, ERGO,
standards
