Summarization of Contents
Install Instructions
Step 1: Connect 12-Wire Cable
Connect the 12-wire cell monitoring/balancing cable to the battery pack.
Step 2: Configure Settings
Configure battery type, cell count, and capacity in settings.
Step 3: Connect 8+2 Pin Connector
Connect the 8+2 pin side connector using CAT5/CAT6 cable for shunts and IOs.
Step 4: Connect Current Shunts
Connect current shunts for battery SOC and PV production monitoring.
Step 5: Connect EXT IO3
Connect EXT IO3 to inverters, DC/DC converters, or Battery Protect for remote ON/OFF.
Step 6: Connect EXT IO4
Connect EXT IO4 to chargers like DSSR20, Victron, or other chargers.
User Interface
Main Menu
Overview of the main menu and its dual function for power and FET control.
Monitoring Menu
Explains the monitoring menu for viewing battery, PV, and load status.
Parameter Settings
Guide to setting battery type, number of cells, and capacity for accurate SOC.
Advanced Parameter Settings
Details on advanced parameters for battery charging/discharging customization.
Time & Date Settings
Setting the time and date for internal data logging to function correctly.
USART Settings
Configuration of USART for data logging, deactivating WiFi.
LCD & TouchKey Settings
Settings for LCD backlight, menu color, time-outs, and color inversion.
WiFi Settings
Configuring the SBMS0's WiFi module as an access point with channel and password.
Internal Data Log Menu
Downloading data from internal flash memory over UART or USB.
Save/Factory Reset Settings
Options to save current settings or perform a factory reset to default.
Automation (EXT IO & ADC)
Setting up EXT IO pins and ADC for automation and calibration.
