Thank you very much for choosing the AOC Color Monitor.
We recommend that you take a few minutes to read carefully
through this brief but comprehensive manual before installing and
switching on the monitor. Please keep this manual in a safe place
for you future reference.
Plug & Play Drivers for the AOC Series Monitors are available at:
www.aocmonitor.com.

CHECKING THE CONTENTS OF THE MONITOR PACKAGE

The product package should include the following items:
1. Pure Flat Color Monitor
2. Owner's Manual

FCC Class B Radio Frequency Interference Statement

WARNING: (FOR FCC CERTIFIED MODELS)
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy, and if not installed and used in accordance with the
instructions,
may
cause
harmful
interference
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for
help.
NOTICE :
1. The changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
2. Shielded interface cables and AC power cord, if any, must be
used in order to comply with the emission limits.
3. The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modification to this
equipment. It is the responsibilities of the user to correct such
interference.
WARNING:
To prevent fire or shock hazard, do not expose the monitor to rain
or moisture. Dangerously high voltages are present inside the
monitor. Do not open the cabinet. Refer servicing to qualified
personnel only.
2

PRECAUTIONS

Do not use the monitor near water, e.g. near a bathtub,
washbowl, kitchen sink, laundry tub, swimming pool or in a wet
basement.
Do not place the monitor on an unstable cart, stand, or table. If
the monitor falls, it can injure a person and cause serious
damage to the appliance. Use only a cart or stand
recommended by the manufacturer or sold with the monitor. If
to
radio
you mount the monitor on a wall or shelf, use a mounting kit
approved by the manufacturer and follow the kit instructions.
Slots and openings in the back and bottom of the cabinet are
provided for ventilation. To ensure reliable operation of the
monitor and to protect it from overheating, be sure these
openings are not blocked or covered. Do not place the monitor
on a bed, sofa, rug, or similar surface. Do not place the monitor
near or over a radiator or heat register. Do not place the monitor
in a bookcase or cabinet unless proper ventilation is provided.
The monitor should be operated only from the type of power
source indicated on the label. If you are not sure of the type of
power supplied to your home, consult your dealer or local power
company.
The monitor is equipped with a three-pronged grounded plug, a
plug with a third (grounding) pin. This plug will fit only into a
grounded power outlet as a safety feature. If your outlet does not
accommodate the three-wire plug, have an electrician install the
correct outlet, or use an adapter to ground the appliance safely.
Do not defeat the safety purpose of the grounded plug.
Unplug the unit during a lightning storm or when it will not be
used for long periods of time. This will protect the monitor from
damage due to power surges.
Do not overload power strips and extension cords. Overloading
can result in fire or electric shock.
Never push any object into the slot on the monitor cabinet. It
could short circuit parts causing a fire or electric shock. Never
spill liquids on the monitor.
Do not attempt to service the monitor yourself; opening or
removing covers can expose you to dangerous voltages and
other hazards. Please refer all servicing to qualified service
personnel.
To ensure satisfactory operation, use the monitor only with UL
listed computers which have appropriate configured receptacles
marked between 100 - 240V AC, Min. 2.5A.
The wall socket shall be installed near the equipment and shall
be easily accessible.
Attention: Disconnect the power cord to stop the power supply to
the monitor.
