- Page 1 CULTI-PACK SEEDER MODELS CP36 - CP42 INSTRUCTION & PARTS MANUAL IMPORTANT - PLEASE READ BEFORE USE...
-
Page 3: Table Of Contents
BLEC CULTI-PACK SEEDER MODELS CP36/CP42 CONTENTS:- SECTION DECLARATION OF CONFORMITY SECTION INTRODUCTION SECTION PRODUCT RECORD SHEET SECTION SAFETY NOTES SECTION DESCRIPTION SECTION CONTROLS SECTION PREPARING FOR USE SECTION OPERATING SECTION MAINTENANCE SECTION STORAGE SECTION MODIFICATIONS/ACCESSORIES SECTION NOTES SECTION PARTS LIST... - Page 4 We hereby certify that the following machinery complies with all the relevant essential Health and Safety Requirements of EEC Machinery Directive 89/392/EEC as amended And the National Laws and Regulations adopting this directive. Machine Description: CULTIPACK SEEDER Make: BLEC Serial Number: Model Number...
- Page 5 SECTION 2 - INTRODUCTION MODELS CP36-CP42 We thank you for choosing a BLEC product. The reliability, efficiency and safe working of this product depends on your care, so it is important to read this instruction book before use. All BLEC equipment has been designed with careful attention directed to operators safety, therefore, it is vital that all safety precautions are carried out when working and maintaining the machinery.
-
Page 6: Product Record Sheet
SECTION 3 PRODUCT RECORD SHEET BLEC CULTIPACK SEEDER MODELS CP36 CP42 Machine Type: BLEC CULTI-PACK SEEDER Serial Number: Delivery Date: Dealers Name & Address: Tel no: Owners Name & Address: Tel no:... -
Page 7: Safety Notes
SECTION 4 SAFETY NOTES BLEC CULTIPACK SEEDER MODELS CP36 CP42 SAFETY NOTES DO NOT USE THIS MACHINE BEFORE READING THIS MANUAL DO NOT ALLOW PERSONS UNDER THE AGE OF 16 TO OPERATE THIS EQUIPMENT DO NOT OPERATE WITHOUT SAFETY CLOTHING/FOOTWEAR... -
Page 8: Description
MODELS CP36- CP42 DESCRIPTION The BLEC range of CULTIPACK SEEDERS have been designed to mount onto Standard type power tillers or two wheel tractors, as they are sometimes known. Before fitting it is important you have the correct model seeder to suit your power Tiller. - Page 9 SECTION 6 CONTROLS BLEC CULTI PACK SEEDER MODELS CP36 CP42 CONTROLS - (See Photo 6) It is important to familiarise yourself with all of the controls. Please read the enclosed power tiller instruction manual (supplied With tiller). The seeder has been designed for the operator to either...
-
Page 10: Controls
SECTION 6 - CONTROLS BLEC CULTI-PACK MODELS: CP36 & CP42 CONTROLS PHOTO: 6 HIGH/LOW GEAR RANGE LEVER ON/OFF SWITCH DRIVE CLUTCH ‘DEAD MANS’ SAFETY LEVERS THROTTLE CONTROL LEVER STEERING CLUTCH LEVER SEED ON/OFF LEVER HANDLE BAR HEIGHT ADJUSTING CLAMP ‘FOLD UP’ FOOT-PLATE... -
Page 11: Preparing For Use
MODELS - CP36/CP42 ASSEMBLY The BLEC CULTI-PACK SEEDER unit will be assembled, lubricated and ready for work if supplied with a recommended power tiller equipped with safety devices. However, if the seeder requires fitting to a power tiller, please follow the directions below:- Step 1. - Page 12 SECTION 7 - PREPARING FOR USE BLEC CULTI-PACK SEEDER MODEL: CP36 & CP42 PHOTO: 2A BEFORE FITTING THE DRUMS MAKE SURE THE AXLE TUBE IS TIGHT. ADJUST THE BOLTS IF NECESSARY. LINE UP HOLE IN AXLE TUBE WITH CAST DRUM HOLE...
- Page 13 SECTION 7 - PREPARING FOR USE BLEC CULTI-PACK SEDER MODELS - CP36/CP42 Step 2. Fitment of seeder unit to tiller. The seeder unit is attached to the jaw bracket on the tiller via a mounting bracket (black) which has a scraper bar attached to it.
- Page 14 SECTION 7 - PREPARING FOR USE BLEC CULTI-PACK SEEDER MODELS : CP36 & CP42 PHOTO: 3 DRAWBAR PIN/CLIP BOLT SCRAPER MOUNTING BRACKET PHOTO: 4 LOCKING SCRAPER SECURING BOLTS...
- Page 15 SECTION 7 - PREPARING FOR USE BLEC CULTI-PACK SEEDER MODELS - CP36/CP42 NOTES:...
- Page 16 SECTION 7 - PREPARING FOR USE BLEC CULTI-PACK SEEDER MODELS: CP36 & CP42 PHOTO: 5 SCRAPER LEAVE 6 - 10mm SERRATED CLEARANCE SCRAPER BETWEEN RINGS BOLT ADJUSTER...
- Page 17 SECTION 7 - PREPARING FOR USE BLEC CULTI-PACK SEEDER MODELS - CP36/CP42 TYPE OF SEEDING SYSTEM The Cultipack seed hopper is equipped with an accurate seeding mechanism, which Consists of a stainless steel bottom with two sliding sections which have specially Shaped apertures (holes) inserted in each part.
- Page 18 SECTION 7 - PREPARING FOR USE BLEC CULTI-PACK SEEDER MODELS: CP36 & CP42 LEVER A PHOTO: 5A LEVER B...
- Page 19 SECTION 7 - PREPARING FOR USE BLEC CULTI-PACK SEEDER MODELS: CP36 & CP42 PHOTO 7. WING NUMBERED CAM GAUGE PHOTO: 8 SLIDE IN BLANKING STRIP TO CATCH SEED ** ** REMEMBER: REMOVE AFTER CALIBRATION...
- Page 20 SECTION 7 - PREPARING FOR USE BLEC CULTI-PACK SEEDER MODELS - CP36/CP42 CALIBRATION PROCEDURE FOR CP36 & CP42 For accurate calibration you will require a set of scales and a small sheet. Proceed as follows:- Find out your required seed rate. (Example - 35gms sq metre, 1 1/40ozs sq. yd.
- Page 21 HALF THE SEED RATE. All seed mixes vary in density and flow rates, so it is not possible for BLEC to produce a rate chart for all mixes. So it is advisable to calibrate each mix used.
-
Page 22: Operating
SECTION 8 - OPERATING BLEC CULTI-PACK SEEDER MODELS - CP36/CP42 OPERATING The combination CULTI-PACK SEEDER and POWER TILLER has been designed for the accurate seeding incorporation on top soiled areas, with a clean tilth free from large debris and stones. - Page 23 SECTION 8 - OPERATING BLEC CULTI-PACK SEEDER MODELS - CP36/CP42 STARTING WORK CONTINUED..Position the seeder at required area, switch the seed lever ON and engage the clutch. IMPORTANT When starting to move off, it will be beneficial to stand off the footplate to allow initial traction to take place.
- Page 24 SECTION 9 - MAINTENENCE BLEC CULTI-PACK SEEDER MODELS: CP36 & CP42 CHAIN PHOTO: 9 ADJUSTING LOCK THREADED BOLT KEEP WELL LEAVE 12mm GREASE SIDEPLAY DO NOT OVERTIGHTEN PHOTO: 10 NUTS & BOLTS, HOLDING RETAINING RING IN PLACE WHEN RINGS WEAR AND BECOME...
-
Page 25: Maintenance
SECTION 9 - MAINTENANCE BLEC CULTI-PACK SEEDER MODELS - CP36/CP42 MAINTENANCE To keep your seeder in good condition, regular maintenance should be carried out as follows:- SEED HOPPER Clean out hopper after use. DO NOT allow grit, stones, string, debris to enter the hopper. - Page 26 SECTION 9 - MAINTENANCE BLEC CULTI-PACK SEEDER MODELS - CP36/CP42 SCRAPER PLATES Keep the serrated scrapers adjusted up to within 6 - 10mm from the rings (See Photo 5), on both front and rear rolls. To adjust, slacken off rolls (See Photo 12), and slide desired position, then retighten.
- Page 27 SECTION 9 - MAINTENANCE BLEC CULTI-PACK SEEDER MODELS: CP36 & CP42 PHOTO: 11 TO ADJUST, SLACKEN BOLTS AND SLIDE SCRAPER BAR. KEEP 6 - 10mm (1/4” - 3/8”) GAP BETWEEN RINGS TO ALLOW FOR MOVEMENT OF RINGS. PHOTO: 12 PIVOT GREASE...
-
Page 28: Storage
SECTION 10 - STORAGE BLEC CULTI-PACK SEEDER MODELS - CP36/CP42 STORAGE CULTI-PACK SEEDER should be stored inside a building. All seed should be removed, leaving a clean hopper. Small amounts of seed remaining can germinate when left in store. CLEAN OUT THOROUGHLY. - Page 29 SECTION 11 - MODIFICATIONS AND ACCESSORIES BLEC CULTI-PACK SEEDER MODELS - CP36/42 ACCESSORIES Rear drag brush mounted under foot plate. Ask Sales Department for details. MODIFICATIONS Rear cast ring roll mesh guard, fitted to standard machine from 1st January, 1995.
- Page 30 SECTION 12 - NOTES BLEC CULTI-PACK SEEDER MODELS - CP36/CP42 NOTES Sound pressure level at operators ears 86 dB ( a ) (EN709:1997) Vibration level at hand arm 6.3 m/s2 (EN12096:1997 Annex D EN709:1997)
-
Page 31: Parts List
SECTION 13 PARTS LIST BLEC CULTIPACK SEEDER MODELS CP36 - CP42 PARTS LIST CULTI-PACK SEEDER MODELS CP36 CP42... - Page 32 CULTI-PACK PARTS ILL. NO PART NO. DESCRIPTION CP36 CP42 BL9001 HOPPER BL9301 HOPPER BL9004 BL9302 BL9006 ROTOR BL9303 ROTOR BL9007 SPACER BL9008 BEARING, END BL9305 BEARING, END BL9009 BEARING, CENTRE BL9010 RETAINER BL9307 RETAINER BL9011 BOTTOM ASSEMBLY BL9308 BOTTOM ASSEMBLY BL9012 CAM GAUGE BL9013...
- Page 33 CULTI-PACK PARTS ILL. NO PART NO. DESCRIPTION CP36 CP42 BL9040 SPROCKET, TOP BL9041 CHAIN ASSEMBLY BL9324 CHAIN ASSEMBLY BL9042 SLIPPER, CHAIN TENSIONER 2 BL9043 SPROCKET, BOTTOM BL05141 BEARING BL9045 ADJUSTER BL9046 CARRIER, SCRAPER BL9155 CARRIER, SCRAPER BL9047 SCRAPER, FRONT BL9156 SCRAPER, FRONT BL9048 HITCH, JAW...
- Page 34 CULTI-PACK PARTS ILL. NO. PART NO. DESCRIPTION CP36 CP42 BL9087 SPACER, WASHER BL9088 SPACER, FLAT BL02064 BOLT BL03033 BL9091 BL9095 MESH, GUARD BL9170 MESH, GUARD BL9096 BL9350 BL04102 R CLIP BL9347 STAND ASSEMBLY BL9348...
-
Page 36: Conditions Of Warranty
BLEC (Global) Ltd has not been adhered to. No liability is accepted by BLEC (Global) Ltd in respect of machine or component failure when it can be determined that such failure was the result of using the equipment with one or more attachments not given prior applications approval by them. - Page 37 Fax: 01778 346777 www.blec.co.uk Email: sales@blec.co.uk NB: The aforementioned details in this manual are for general guidance only, and BLEC (Global) Ltd cannot be held responsible misuse, misinterpretation from these details in any way whatsoever. The machine must never be used in any unsuitable conditions or situations.
