Summary of Contents for DANE-ELEC Music MY TOUCH
- Page 1 User Guide...
- Page 2 Note: Please recharge the player before using it! Please use your player properly in case of explosion, fire, electric shock, etc. 1. Do not repair the player by yourself, or it will cause damage. 2. Do avoid getting the player wet or drop it in water. 3.
- Page 3 Function features The player supports MP3/WMA /WAV/AAC/APE/FLAC music file formats. Support USB 2.0 capability, much faster than USB 1.1, to enable faster communication with your PC. The player can record outside voice and FM radio. The player has repeat functions. The player has Video Playback, Photo Viewer, E-book, FM transmitter, slide show function, etc.
- Page 4 Components and Button functions 1.【∧】: Previous one/Volume 2. 【 】 : Next one/Volume down ∨ 3. 【 】 : Previous one/Fast < backward 4.【M】: Menu/Confirm/Enter button, In record mode: save button 】: Short press: 5.【 Play/Pause/Confirm/Enter button and in FM mode: manual search/Preset;...
- Page 5 Charging Li –polymer battery safely Connect the PC USB port and the player USB port with the provided USB cable. The power sign is shown dynamic when charging, once full charged, the power sign will stop moving, power is full, please shut off the power. The charging time is approximately 3 hours.
- Page 6 To Pause/Play: Short press button. 】 /【 】button. < > ∧ ∨ To change tracks: Short press【 To turn unit off: Slide and hold the【HOLD】button in the direction of NOTE: Please reset your player by pressing the RESET hole for 2 seconds while failing to power on or hanging up in power on mode.
- Page 7 Delete files from the removable USB storage (use the "Delete" command). Remove the player from PC – please follow the steps in case of damaging the player or data loss. Click the left mouse button on the icon that is on the taskbar at the bottom right corner of the desktop.
- Page 8 CAUTION: Do not remove the player while files within the USB Mass Storage are being played on your computer. Do not disconnect the player from your computer while transferring files, or it will cause damage to the player or data loss. Menu Navigation M button: Enter main menu, submenu, confirm or save button.
- Page 9 Repeat Mode Select “Repeat Mode” and short press M / button to enter. 】/【 】buttons to select your desired option (e.g. Once, < > Short press【 ∧ ∨ Repeat One, Normal, All Repeat, Intro). Short press M / button to confirm. Long Press button to return.
- Page 10 MSEQ, Rock, Pop, Classic, Bass, Jazz, User EQ). Short press M / button to confirm. Long Press button to return. NOTE: EQ mode is not obvious while playing WMA format music files. User EQ Setup You can setup the EQ as your opinion, just need to pitch on the adjustment frame by 】/【...
- Page 11 】button to turn up/turn down the volume, In Video playback mode, press【 ∧ ∨ button to play/pause, and press 【 】 button to turn to previous / next < > press one. Press M button to return. Radio 】/【 】buttons to select “Radio“ mode and <...
- Page 12 Select a photo file and press file to open it, and press M button to enter the submenu: Rotate Right, Rotate Left, Zoom In, Zoom Out, Slide Show, then short press M / button to confirm. Also you can long press button to return to normal display.
- Page 13 Record In main menu, short press【∧ / ∨】/【 】buttons to select “Record” mode and < > enter by pressing M / button. Short press button to start recording, and press button again to pause. Short press M button to save the recorded file. Long press M button to save and exit the record mode.
- Page 14 System Setting, Language, System Information, AutoShut Time, FM Tx. Short press M / button to enter. Display Setting: 】/【 < > 】buttons to select: LightTime, Brightness, Light Mode. Short press【 ∧ ∨ Light Time: Select “Light Time” and press M / button to enter.
- Page 15 System Setting: 】/【 】buttons to select: Upgrade, Restorable. < > ∧ ∨ Short press【 Language: / ∨】 /【 】buttons to select the system language: < > ∧ Short press【 CHI(Simp), English, Deutsch, Italian, Portuguese, Dutch, French, Spanish, Polish, Russian, Turkish, Czech, Denish, Japanese, Swedish, Korean, Hellenic, CHI(Trad), Thai, Hebrew.
- Page 16 Press 【 】/ 【 】buttons to select On/Off, and press M / < > ∧ ∨ buttons to 】/【 < > 】buttons to select Off or On. enter, then press【 ∧ ∨ Short press M / button to confirm, and long press M / button to return.
- Page 17 Format the player The player is “FAT” format. If you wish to format it, right click removable disk and choose “Format” mode, then click “Start” to format in operating system. As following pictures show: Notice Please unlock the button before using the player. Can’t identify the sixth and above sixth level of directory.
- Page 18 Attention should be drawn to the environmental aspects of battery disposal. The user guide is only for reference. It is standard by the sample. Technical Specification Name Description Capacity of Flash Support Micro SD/T-Flash Card, up to 8G; Memory Build-in Flash Memory, up to 8G. USB Interface USB2.0 (High Speed) LCD Display...
- Page 19 Becarefull : exposure to excessive sound level can be have the adverse effects (Product Warranty 1 year, accessories 7 days) MADE IN CHINA...
