Speaker System - Sherwood ASW-670 Operating Instructions Manual

[AM TUNER SECTION]
• Tuning frequency range | 520~1710 kHz
• Usable sensitivity | 500 µV/m
• Signal to noise ratio | 40 dB
• Selectivity | 25 dB
[GENERAL]
• Power supply | 120 V~60 Hz
• Power consumption | 95 W
• Dimensions(W H D) | 360 102 275 mm(17-1/8 4 10-7/8 inches)
• Weight(Net) | 5.4 kg(11.9 lbs)

SPEAKER SYSTEM

[FRONT SPEAKER(ST-670)]
• Type | 2 way 2 speaker system(magnetic shielding, closed type)
• Unit | 3 inch woofer 1, 1inch soft dome tweeter 1
• Frequency response | 140 Hz~20 kHz
• Power handling | 25~30 W
• Impedance | 6 Ω
• Sound pressure level | 82 dB/W/M
• Dimensions(W H D) | 110 220 100 mm(4-1/4 8-5/8 4 inches)
• Weight(Net.)/unit | 0.94 kg(2.1 lbs)
[ACTIVE SUBWOOER(ASW-670)]
• Type | Bass reflex system(magnetic shielding type)
• Unit | 6 inch woofer 1
• Frequency response | 50 Hz~150 Hz
• Amplifier output | 50 W / 4 Ω
• Power supply | 120 V~60 Hz
• Power consumption | 50 W
• Dimensions(W H D) | 200 300 305 mm(7-7/8 11-7/8 12 inches)
• Weight(Net) | 7.1 kg(15.7 lbs)
Note: Design and specifications are subject to change without notice for improvements.
54
