- Page 1 © 2010 Encore Electronics, Inc. All rights reserved.COVER © 2010 Encore Electronics, Inc. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein. All trademarks and brand names are the properties of their respective holders.
-
Page 2: Table Of Contents
Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein. All trademarks and brand names are the properties of their respective holders. © 2010 Encore Electronics, Inc. All rights reserved. www.encore-usa.com... -
Page 3: Chapter 1: Introduction
The truth is, by 2014, analog TV network will be switched off in most countries and old analogue TVs won't work without a signal converter. Encore's ISDB-T/SBTVD Digital TV Converter Box is the solution – just connect the Converter Box between the TV... -
Page 4: Features
No software / driver required when using USB storage devices as direct input 1.2 System Requirements ISDB-T/SBTVD TV signal: over-the-air (RF) signal (a TV antenna is required) TV display unit: CRT, LCD TV, Plasma or DLP USB external hard drive partition format: FAT32 www.encore-usa.com... -
Page 5: Specifications
Picture Format BMP, JPEG Convenience Remote control included Dimensions 260 x 155 x 38 mm (W x D x H) 1.4 Package Contents ENXTV-DIT Digital TV Antenna Full Function Remote control Audio / Video cable YPbPr cable User manual www.encore-usa.com... -
Page 6: Chapter 2: Getting Started
Chapter 2: Getting Started ENXTV-DIT cable connection is easy. The most typical cable connections are shown in this chapter. 2.1 Front Rear panel connector Item Connector Function USB Port USB Host to connect storage 2.2 Rear panel connectors Item Connector... - Page 7 There are 4 kinds of connections: (1) HDMI connector: (2) CVBS connector: www.encore-usa.com...
- Page 8 (3) S-video connector: (4) YPbPr connector: www.encore-usa.com...
-
Page 9: First Launch
Notes: We highly recommend you use the outdoor antenna for better signal reception. 2. 3 First Launch The first time you connect ENXTV-DIT to TV, the setup screen should automatically appear below. OSD Language: Please select the system language from the list. -
Page 10: Chapter 3: Remote Control
Chapter 3: Remote Control The Remote Control allows you to operate ENXTV-DIT remotely. Aim the front of the Remote Control at the Remote Control Receiver window and press the control buttons as you would. 3.1 Installing Batteries Open the back cover of the remote control and put in two AAA batteries (alkaline battery recommended). -
Page 11: Chapter 4: Using The Enxtv-Dit
Chapter 4: Using the ENXTV-DIT In this section the ENXTV-DIT Main Menu and its operations will be discussed here. 4.1 How to use the Main Menu Press the MENU button on the remote control to get to this screen. Use direction buttons on remote control to move the cursor to the desired item. - Page 12 System Setup By selecting “System setup”, you can change the settings of: OSD Language There are three on-screen display languages to choose from: English, Spanish, and Portuguese. (Default: English) Country You can select your country from the list. (Default: Brazil) www.encore-usa.com...
- Page 13 LCN (Local Channel Name): On/Off It will give you an option to scan for local channel names. (Default: Off) Parental Control: On/Off You can protect your children from certain TV channels by setting a password: Change password: You can change password any time. www.encore-usa.com...
- Page 14 System Information: Display system information. Factory Reset: Yes/No Reset to default settings if you would like to eliminate all the above changes you have made. Video Settings By selecting “Video Settings”, you can change the settings of: www.encore-usa.com...
- Page 15 Select the TV system, according to AV output of your TV. (Default: NTSC) HD Output : 1080p, 1080i, 720p, 576p/480p, 576i/480i Select HD Output according to your HDMI or YPbPr output. (Default: 1080i) Screen Ratio: 4:3/16:9 Select the screen ratio based on your TV screen ratio. (Default: 16:9) www.encore-usa.com...
- Page 16 Aspect Conversion: Letter BOX, Pascan or FULL Select a screen display mode according to signal mode. (Default: Letter BOX) Audio Settings By selecting “Audio Settings”, you can change the settings of: LR Mode Set the audio mode to Stereo, Left or Right. (Default: Stereo) www.encore-usa.com...
- Page 17 By selecting “Installation”, you can do the following: Manual Search: If you want to add new channels in list, you can search for channels manually by channel numbers and frequency. Auto Search: Or you can set it to auto search for new channels. www.encore-usa.com...
- Page 18 You can also upgrade the firmware by the following steps: 1. Please download the last firmware from our website (www.encore-usa.com). 2. Unzip this file to a USB storage device or memory card and plug it to the USB port on the front of the TV converter box.
- Page 19 Channel Edit By selecting “Channel Edit”, you can edit your favorite TV channels/ Radio channels. Use the color buttons to make selection: Favorite: Use red color button on remote control to add your favorite channels in favorite groups list. www.encore-usa.com...
- Page 20 And then system will ask you input the password. (Prompt: 1234) Move: Use yellow color button on remote control to arrange the order in channels list. Delete: Use blue color button on remote control to delete the channel from the list. www.encore-usa.com...
-
Page 21: Watching Free-To-Air Digital Tv
You can press REC button on remote control to record TV programs. Note: Please connect your USB storage device to ENXTV-DIT USB port before starting the record. The mpeg4 record file name with “*.pvr” will store on record Path. (Default: //hdd0/pvr) www.encore-usa.com... - Page 22 You can press EPG button on remote control: EPG feature depends on television broadcast used in different regions. You can see the TV broadcast schedules and detail descriptions on TV EPG window. You also can schedule recording and then you will never miss your favorite shows. www.encore-usa.com...
-
Page 23: Running The Radio
(1) You can press the “TV/Radio” button or press the “menu” button and then select “Radio” (2) Use “Up/Down” direction buttons on remote control to move the cursor to the desired Radio channel around the menu screen and click “OK” button on the remote control to confirm. www.encore-usa.com... -
Page 24: Playing Multimedia From Usb Storage Devices
Press red color button on remote control. You can delete the directory or file on USB storage devices. Set Record Path Press green color button on remote control. You can change the path which to save the record files on USB storage devices. (Default: //hdd0/pvr) www.encore-usa.com... - Page 25 Make Dir/File Rename Press yellow color button on remote control. You can make directory on USB storage devices. Or select the file to rename it. www.encore-usa.com...
-
Page 26: Chapter 5: Technical Support
Chapter 5: Technical Support Please visit www.encore-usa.com for the latest product information and downloads. International tech support hotlines are listed on the back cover Appendix A: User’s Notice This manual is provided “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose. - Page 27 * Local tech-support numbers are provided in selectively countries. Service may change without prior notice. Please visit www.encore-usa.com for more details. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
